TR / TN Series Twin Rod Cylinder
Product Features
TR Series (High Precision)
- JIS Standard: Implements JIS standards for high-level guidance.
- High Precision: Non-rotating accuracy is high with minimal rod deflection.
- Long Guide: Uses extended sliding bearings; no additional lubrication required.
- Flexible Mounting: Mounting holes on three sides for versatile installation.
- Dual Ports: Inlet/outlet ports on both sides for flexible piping.
TN Series (Compact / Adjustable)
- Enterprise Standard: Implements reliable enterprise production standards.
- Space-Saving: Compact body fixed installation saves valuable setup space.
- Lateral Load: High anti-bending and anti-torsion capabilities for lateral loads.
- Stroke Adjustment: Front bumper allows adjustment (-5 ~ 0 mm) to mitigate impact.
- Magnet: Standard configuration includes a built-in magnet.
Specifications
1. TR Series Specifications
| Bore Size (mm) | 6 | 10 | 16 | 20 | 25 | 32 |
|---|---|---|---|---|---|---|
| Action Type | Double Acting | |||||
| Fluid | Air (Filtered 40μm) | |||||
| Pressure | 0.15 ~ 1.0 MPa (22 ~ 145 psi) | |||||
| Temp | -20 ~ 70°C | |||||
| Non-rotating | ± 0.2° | ± 0.15° | ± 0.1° | |||
| Port Size | M5 x 0.8 | PT 1/8 | ||||
2. TN Series Specifications
| Bore Size (mm) | 10 | 16 | 20 | 25 | 32 |
|---|---|---|---|---|---|
| Pressure | 0.15 ~ 1.0 MPa | ||||
| Stroke Adj. | -5 ~ 0 mm | ||||
| Non-rotating | ± 0.4° | ± 0.3° | |||
| Port Size | M5 x 0.8 | PT 1/8 | |||
Stroke Specifications
| Model | Bore (mm) | Standard Strokes (mm) | Max Stroke |
|---|---|---|---|
| TR | 6 | 10, 20, 30, 40, 50 | 50 |
| TR/TN | 10 | 10, 20, 30, 40, 50, 60, 70, 80, 90, 100 | 100 |
| TR/TN | 16~32 | 10, 20, 30, 40, 50, 60, 70, 80, 90, 100, 125, 150, 175, 200 | 200 |
Note: Non-standard strokes within the 100mm range are produced at 5mm intervals.
Product Ordering Code
| No. | Item | Code | Description |
|---|---|---|---|
| 1 | Model | TR / TN | Twin Rod Cylinder |
| 2 | Bore Size | 6 ~ 32 | 6, 10, 16, 20, 25, 32 |
| 3 | Stroke | - | Refer to Stroke Table |
| 4 | Magnet | S | With Magnet (Standard) |
| 5 | Thread | Blank / G / T | PT / G / NPT |
