GF Series Air Filter
Product Features
- Unique Diversion: The unique diversion structure spins the flowing air to effectively separate liquid from gas and reliably filter solid particles.
- High Efficiency: Features low pressure loss, high water separation efficiency, and a large capacity bowl.
- Filtering Grades: 5μm and 40μm filtering grades are available to meet various precision needs.
- Drain Options: Three drain types available: Manual, Differential, and Automatic drain for flexible maintenance.
- Installation: Can be easily installed using a dedicated fixed bracket.
Specifications
| Model | GF200 | GF300 | GF400 | GF600 |
|---|---|---|---|---|
| Fluid | Air | |||
| Port Size | 1/8", 1/4" | 1/4", 3/8", 1/2" | 3/8", 1/2" | 3/4", 1" |
| Filtering Grade | 40μm or 5μm | |||
| Operating Pressure | Auto/Differential: 0.15~1.0MPa | Manual: 0~0.9MPa | |||
| Proof Pressure | 1.5 MPa (215 psi) | |||
| Temperature | -5 ~ 70°C (No freezing) | |||
| Bowl Capacity | 10 CC | 40 CC | 80 CC | 230 CC |
| Weight | 135g | 360g | 680g | 1440g |
Product Ordering Code
Example: GF200 08 M W G
Ordering Key
| No. | Item | Options / Description |
|---|---|---|
| 1 | Series Code | GF200, GF300, GF400, GF600 |
| 2 | Port Size | 06: 1/8", 08: 1/4", 10: 3/8", 15: 1/2", 20: 3/4", 25: 1" |
| 3 | Drain Type | Blank: Differential, M: Manual, A: Automatic Drain |
| 4 | Bracket | Blank: With Bracket, J: No Bracket |
| 5 | Filter Grade | Blank: 40μm, W: 5μm |
| 6 | Thread Type | Blank: PT, G: G Thread, T: NPT |
Note: Standard configuration typically includes the bracket unless specified with "J".
