Product Features

Direct-acting two-position, two-way solenoid valve with sensitive and fast direction change.
Compact, small, lightweight, and easy to assemble and disassemble.
The valve body is made of brass; the coil has a heat resistance classification of Grade B. The standard seal material is VITON, which is suitable for various working media.
The valve body is made of brass; the coil has a heat resistance classification of Grade B. The seal material is NBR, featuring low cost and a wide application range. The maximum operating pressure is 0.05MPa.

Specifications

Model	2V025-06	2V025-08	2V130-10	2V130-15	2V250-20	2V250-25
Working Medium	Air, Water, Oil
Action Type	Direct Acting		Pilot Operated
Initial State	Normally Closed
Orifice Diameter (Φmm)	2.5	2.5	13.0	13.0	25.0	25.0
Cv Value	0.23	0.25	6.20	6.20	13.00	13.00
Port Size [Note 1]	PT1/8	PT1/4	PT3/8	PT1/2	PT3/4	PT1
Operating Fluid Viscosity	20CST or less
Operating Pressure Range	0–1.0MPa (0–145psi)		0.05–1.0MPa (7–145psi)
Proof Pressure	1.5MPa (215psi)
Body Material	Brass (Surface Pickling)		Brass
Seal Material	VITON		NBR
Break Time	0.05s or less

Note 1: G and NPT thread types are available.

Product Ordering Code

Position	Description	Options & Values
1	Model Code	2V: 2/2 Way Solenoid Valve
2	Nominal Diameter	025: Φ2.5mm 130: Φ13mm 250: Φ25mm
3	Port Size	06: 1/8" 08: 1/4" 10: 3/8" 15: 1/2" 20: 3/4" 25: 1"
4	Coil Voltage	A: AC220V B: DC24V C: AC110V E: AC24V F: DC12V
5	Connection Type	Blank: DIN connector type I: Lead wire type [Note 1]
6	Thread Code	Blank: PT thread G: G thread T: NPT thread

Note 1: The standard length for the lead wire type is 0.5m.
