  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008AIG

  Specifications: 2KW03008AIG is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has G1/4 ports, a 3 mm orifice and a 220 V AC coil. The pressure-condition code selects the standard configuration. The I code selects grommet electrical entry with a 0.5 m wire. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008AIG will be supplied as 2KWA03008AIG under our store's replacement policy. The technical information below documents the legacy 2KW03008AIG; use the new 2KWA catalog for the supplied 2KWA03008AIG. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: G1/4. A Coil supply: 220 V AC. I Grommet electrical entry with a 0.5 m wire. G G thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread G1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 295 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight column describes terminal-entry valves. Its explicit grommet-entry footnote reduces that value by 10 g for this size, giving the 295 g reference above. Catalog weights are reference values, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CLA116 Rated voltage 220 V AC Voltage tolerance ±15% for AC Electrical entry Grommet; 0.5 m wire Protection class IP65 50 Hz power consumption 15 VA 60 Hz power consumption 11 VA Temperature rise at 50 Hz 50°C Temperature rise at 60 Hz 40°C Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the grommet-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 41 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm G 10 mm K 5.3 mm KA 40 mm P G1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008AIT

  Specifications: 2KW03008AIT is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has NPT1/4 ports, a 3 mm orifice and a 220 V AC coil. The pressure-condition code selects the standard configuration. The I code selects grommet electrical entry with a 0.5 m wire. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008AIT will be supplied as 2KWA03008AIT under our store's replacement policy. The technical information below documents the legacy 2KW03008AIT; use the new 2KWA catalog for the supplied 2KWA03008AIT. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: NPT1/4. A Coil supply: 220 V AC. I Grommet electrical entry with a 0.5 m wire. T NPT thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread NPT1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 295 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight column describes terminal-entry valves. Its explicit grommet-entry footnote reduces that value by 10 g for this size, giving the 295 g reference above. Catalog weights are reference values, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CLA116 Rated voltage 220 V AC Voltage tolerance ±15% for AC Electrical entry Grommet; 0.5 m wire Protection class IP65 50 Hz power consumption 15 VA 60 Hz power consumption 11 VA Temperature rise at 50 Hz 50°C Temperature rise at 60 Hz 40°C Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the grommet-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 41 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm G 10 mm K 5.3 mm KA 40 mm P NPT1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008AT

  Specifications: 2KW03008AT is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has NPT1/4 ports, a 3 mm orifice and a 220 V AC coil. The pressure-condition code selects the standard configuration. The blank electrical-entry code selects the terminal version. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008AT will be supplied as 2KWA03008AT under our store's replacement policy. The technical information below documents the legacy 2KW03008AT; use the new 2KWA catalog for the supplied 2KWA03008AT. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: NPT1/4. A Coil supply: 220 V AC. (blank entry code) Terminal electrical entry. T NPT thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread NPT1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 305 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight is the terminal-entry reference. It is a reference value, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CDA116 Rated voltage 220 V AC Voltage tolerance ±15% for AC Electrical entry Terminal Protection class IP65 50 Hz power consumption 15 VA 60 Hz power consumption 11 VA Temperature rise at 50 Hz 50°C Temperature rise at 60 Hz 40°C Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the terminal-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 72.5 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm F 43.5 mm G 10 mm K 5.3 mm KA 40 mm P NPT1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008BG

  Specifications: 2KW03008BG is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has G1/4 ports, a 3 mm orifice and a 24 V DC coil. The pressure-condition code selects the standard configuration. The blank electrical-entry code selects the terminal version. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008BG will be supplied as 2KWA03008BG under our store's replacement policy. The technical information below documents the legacy 2KW03008BG; use the new 2KWA catalog for the supplied 2KWA03008BG. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: G1/4. B Coil supply: 24 V DC. (blank entry code) Terminal electrical entry. G G thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread G1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 305 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight is the terminal-entry reference. It is a reference value, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CDA116 Rated voltage 24 V DC Voltage tolerance ±10% for DC Electrical entry Terminal Protection class IP65 DC power consumption 6.5 W Temperature rise on DC 30°C Supply frequency Not applicable to DC Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the terminal-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 72.5 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm F 43.5 mm G 10 mm K 5.3 mm KA 40 mm P G1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008BI

  Specifications: 2KW03008BI is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has PT1/4 ports, a 3 mm orifice and a 24 V DC coil. The pressure-condition code selects the standard configuration. The I code selects grommet electrical entry with a 0.5 m wire. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008BI will be supplied as 2KWA03008BI under our store's replacement policy. The technical information below documents the legacy 2KW03008BI; use the new 2KWA catalog for the supplied 2KWA03008BI. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: PT1/4. B Coil supply: 24 V DC. I Grommet electrical entry with a 0.5 m wire. (blank thread suffix) PT thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread PT1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 295 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight column describes terminal-entry valves. Its explicit grommet-entry footnote reduces that value by 10 g for this size, giving the 295 g reference above. Catalog weights are reference values, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CLA116 Rated voltage 24 V DC Voltage tolerance ±10% for DC Electrical entry Grommet; 0.5 m wire Protection class IP65 DC power consumption 6.5 W Temperature rise on DC 30°C Supply frequency Not applicable to DC Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the grommet-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 41 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm G 10 mm K 5.3 mm KA 40 mm P PT1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008BIG

  Specifications: 2KW03008BIG is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has G1/4 ports, a 3 mm orifice and a 24 V DC coil. The pressure-condition code selects the standard configuration. The I code selects grommet electrical entry with a 0.5 m wire. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008BIG will be supplied as 2KWA03008BIG under our store's replacement policy. The technical information below documents the legacy 2KW03008BIG; use the new 2KWA catalog for the supplied 2KWA03008BIG. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: G1/4. B Coil supply: 24 V DC. I Grommet electrical entry with a 0.5 m wire. G G thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread G1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 295 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight column describes terminal-entry valves. Its explicit grommet-entry footnote reduces that value by 10 g for this size, giving the 295 g reference above. Catalog weights are reference values, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CLA116 Rated voltage 24 V DC Voltage tolerance ±10% for DC Electrical entry Grommet; 0.5 m wire Protection class IP65 DC power consumption 6.5 W Temperature rise on DC 30°C Supply frequency Not applicable to DC Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the grommet-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 41 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm G 10 mm K 5.3 mm KA 40 mm P G1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008BIT

  Specifications: 2KW03008BIT is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has NPT1/4 ports, a 3 mm orifice and a 24 V DC coil. The pressure-condition code selects the standard configuration. The I code selects grommet electrical entry with a 0.5 m wire. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008BIT will be supplied as 2KWA03008BIT under our store's replacement policy. The technical information below documents the legacy 2KW03008BIT; use the new 2KWA catalog for the supplied 2KWA03008BIT. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: NPT1/4. B Coil supply: 24 V DC. I Grommet electrical entry with a 0.5 m wire. T NPT thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread NPT1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 295 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight column describes terminal-entry valves. Its explicit grommet-entry footnote reduces that value by 10 g for this size, giving the 295 g reference above. Catalog weights are reference values, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CLA116 Rated voltage 24 V DC Voltage tolerance ±10% for DC Electrical entry Grommet; 0.5 m wire Protection class IP65 DC power consumption 6.5 W Temperature rise on DC 30°C Supply frequency Not applicable to DC Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the grommet-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 41 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm G 10 mm K 5.3 mm KA 40 mm P NPT1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008BT

  Specifications: 2KW03008BT is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has NPT1/4 ports, a 3 mm orifice and a 24 V DC coil. The pressure-condition code selects the standard configuration. The blank electrical-entry code selects the terminal version. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008BT will be supplied as 2KWA03008BT under our store's replacement policy. The technical information below documents the legacy 2KW03008BT; use the new 2KWA catalog for the supplied 2KWA03008BT. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: NPT1/4. B Coil supply: 24 V DC. (blank entry code) Terminal electrical entry. T NPT thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread NPT1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 305 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight is the terminal-entry reference. It is a reference value, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CDA116 Rated voltage 24 V DC Voltage tolerance ±10% for DC Electrical entry Terminal Protection class IP65 DC power consumption 6.5 W Temperature rise on DC 30°C Supply frequency Not applicable to DC Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the terminal-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 72.5 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm F 43.5 mm G 10 mm K 5.3 mm KA 40 mm P NPT1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008C

  Specifications: 2KW03008C is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has PT1/4 ports, a 3 mm orifice and a 110 V AC coil. The pressure-condition code selects the standard configuration. The blank electrical-entry code selects the terminal version. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008C will be supplied as 2KWA03008C under our store's replacement policy. The technical information below documents the legacy 2KW03008C; use the new 2KWA catalog for the supplied 2KWA03008C. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: PT1/4. C Coil supply: 110 V AC. (blank entry code) Terminal electrical entry. (blank thread suffix) PT thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread PT1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 305 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight is the terminal-entry reference. It is a reference value, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CDA116 Rated voltage 110 V AC Voltage tolerance ±15% for AC Electrical entry Terminal Protection class IP65 50 Hz power consumption 15 VA 60 Hz power consumption 11 VA Temperature rise at 50 Hz 50°C Temperature rise at 60 Hz 40°C Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the terminal-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 72.5 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm F 43.5 mm G 10 mm K 5.3 mm KA 40 mm P PT1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008CG

  Specifications: 2KW03008CG is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has G1/4 ports, a 3 mm orifice and a 110 V AC coil. The pressure-condition code selects the standard configuration. The blank electrical-entry code selects the terminal version. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008CG will be supplied as 2KWA03008CG under our store's replacement policy. The technical information below documents the legacy 2KW03008CG; use the new 2KWA catalog for the supplied 2KWA03008CG. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: G1/4. C Coil supply: 110 V AC. (blank entry code) Terminal electrical entry. G G thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread G1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 305 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight is the terminal-entry reference. It is a reference value, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CDA116 Rated voltage 110 V AC Voltage tolerance ±15% for AC Electrical entry Terminal Protection class IP65 50 Hz power consumption 15 VA 60 Hz power consumption 11 VA Temperature rise at 50 Hz 50°C Temperature rise at 60 Hz 40°C Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the terminal-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 72.5 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm F 43.5 mm G 10 mm K 5.3 mm KA 40 mm P G1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008CI

  Specifications: 2KW03008CI is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has PT1/4 ports, a 3 mm orifice and a 110 V AC coil. The pressure-condition code selects the standard configuration. The I code selects grommet electrical entry with a 0.5 m wire. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008CI will be supplied as 2KWA03008CI under our store's replacement policy. The technical information below documents the legacy 2KW03008CI; use the new 2KWA catalog for the supplied 2KWA03008CI. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: PT1/4. C Coil supply: 110 V AC. I Grommet electrical entry with a 0.5 m wire. (blank thread suffix) PT thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread PT1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 295 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight column describes terminal-entry valves. Its explicit grommet-entry footnote reduces that value by 10 g for this size, giving the 295 g reference above. Catalog weights are reference values, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CLA116 Rated voltage 110 V AC Voltage tolerance ±15% for AC Electrical entry Grommet; 0.5 m wire Protection class IP65 50 Hz power consumption 15 VA 60 Hz power consumption 11 VA Temperature rise at 50 Hz 50°C Temperature rise at 60 Hz 40°C Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the grommet-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 41 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm G 10 mm K 5.3 mm KA 40 mm P PT1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008CIG

  Specifications: 2KW03008CIG is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has G1/4 ports, a 3 mm orifice and a 110 V AC coil. The pressure-condition code selects the standard configuration. The I code selects grommet electrical entry with a 0.5 m wire. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008CIG will be supplied as 2KWA03008CIG under our store's replacement policy. The technical information below documents the legacy 2KW03008CIG; use the new 2KWA catalog for the supplied 2KWA03008CIG. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: G1/4. C Coil supply: 110 V AC. I Grommet electrical entry with a 0.5 m wire. G G thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread G1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 295 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight column describes terminal-entry valves. Its explicit grommet-entry footnote reduces that value by 10 g for this size, giving the 295 g reference above. Catalog weights are reference values, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CLA116 Rated voltage 110 V AC Voltage tolerance ±15% for AC Electrical entry Grommet; 0.5 m wire Protection class IP65 50 Hz power consumption 15 VA 60 Hz power consumption 11 VA Temperature rise at 50 Hz 50°C Temperature rise at 60 Hz 40°C Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the grommet-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 41 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm G 10 mm K 5.3 mm KA 40 mm P G1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008CIT

  Specifications: 2KW03008CIT is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has NPT1/4 ports, a 3 mm orifice and a 110 V AC coil. The pressure-condition code selects the standard configuration. The I code selects grommet electrical entry with a 0.5 m wire. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008CIT will be supplied as 2KWA03008CIT under our store's replacement policy. The technical information below documents the legacy 2KW03008CIT; use the new 2KWA catalog for the supplied 2KWA03008CIT. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: NPT1/4. C Coil supply: 110 V AC. I Grommet electrical entry with a 0.5 m wire. T NPT thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread NPT1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 295 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight column describes terminal-entry valves. Its explicit grommet-entry footnote reduces that value by 10 g for this size, giving the 295 g reference above. Catalog weights are reference values, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CLA116 Rated voltage 110 V AC Voltage tolerance ±15% for AC Electrical entry Grommet; 0.5 m wire Protection class IP65 50 Hz power consumption 15 VA 60 Hz power consumption 11 VA Temperature rise at 50 Hz 50°C Temperature rise at 60 Hz 40°C Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the grommet-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 41 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm G 10 mm K 5.3 mm KA 40 mm P NPT1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008CT

  Specifications: 2KW03008CT is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has NPT1/4 ports, a 3 mm orifice and a 110 V AC coil. The pressure-condition code selects the standard configuration. The blank electrical-entry code selects the terminal version. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008CT will be supplied as 2KWA03008CT under our store's replacement policy. The technical information below documents the legacy 2KW03008CT; use the new 2KWA catalog for the supplied 2KWA03008CT. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: NPT1/4. C Coil supply: 110 V AC. (blank entry code) Terminal electrical entry. T NPT thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread NPT1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 305 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight is the terminal-entry reference. It is a reference value, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CDA116 Rated voltage 110 V AC Voltage tolerance ±15% for AC Electrical entry Terminal Protection class IP65 50 Hz power consumption 15 VA 60 Hz power consumption 11 VA Temperature rise at 50 Hz 50°C Temperature rise at 60 Hz 40°C Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the terminal-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 72.5 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm F 43.5 mm G 10 mm K 5.3 mm KA 40 mm P NPT1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008E

  Specifications: 2KW03008E is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has PT1/4 ports, a 3 mm orifice and a 24 V AC coil. The pressure-condition code selects the standard configuration. The blank electrical-entry code selects the terminal version. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008E will be supplied as 2KWA03008E under our store's replacement policy. The technical information below documents the legacy 2KW03008E; use the new 2KWA catalog for the supplied 2KWA03008E. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: PT1/4. E Coil supply: 24 V AC. (blank entry code) Terminal electrical entry. (blank thread suffix) PT thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread PT1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 305 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight is the terminal-entry reference. It is a reference value, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CDA116 Rated voltage 24 V AC Voltage tolerance ±15% for AC Electrical entry Terminal Protection class IP65 50 Hz power consumption 15 VA 60 Hz power consumption 11 VA Temperature rise at 50 Hz 50°C Temperature rise at 60 Hz 40°C Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the terminal-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 72.5 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm F 43.5 mm G 10 mm K 5.3 mm KA 40 mm P PT1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008EG

  Specifications: 2KW03008EG is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has G1/4 ports, a 3 mm orifice and a 24 V AC coil. The pressure-condition code selects the standard configuration. The blank electrical-entry code selects the terminal version. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008EG will be supplied as 2KWA03008EG under our store's replacement policy. The technical information below documents the legacy 2KW03008EG; use the new 2KWA catalog for the supplied 2KWA03008EG. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: G1/4. E Coil supply: 24 V AC. (blank entry code) Terminal electrical entry. G G thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread G1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 305 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight is the terminal-entry reference. It is a reference value, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CDA116 Rated voltage 24 V AC Voltage tolerance ±15% for AC Electrical entry Terminal Protection class IP65 50 Hz power consumption 15 VA 60 Hz power consumption 11 VA Temperature rise at 50 Hz 50°C Temperature rise at 60 Hz 40°C Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the terminal-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 72.5 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm F 43.5 mm G 10 mm K 5.3 mm KA 40 mm P G1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008EI

  Specifications: 2KW03008EI is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has PT1/4 ports, a 3 mm orifice and a 24 V AC coil. The pressure-condition code selects the standard configuration. The I code selects grommet electrical entry with a 0.5 m wire. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008EI will be supplied as 2KWA03008EI under our store's replacement policy. The technical information below documents the legacy 2KW03008EI; use the new 2KWA catalog for the supplied 2KWA03008EI. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: PT1/4. E Coil supply: 24 V AC. I Grommet electrical entry with a 0.5 m wire. (blank thread suffix) PT thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread PT1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 295 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight column describes terminal-entry valves. Its explicit grommet-entry footnote reduces that value by 10 g for this size, giving the 295 g reference above. Catalog weights are reference values, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CLA116 Rated voltage 24 V AC Voltage tolerance ±15% for AC Electrical entry Grommet; 0.5 m wire Protection class IP65 50 Hz power consumption 15 VA 60 Hz power consumption 11 VA Temperature rise at 50 Hz 50°C Temperature rise at 60 Hz 40°C Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the grommet-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 41 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm G 10 mm K 5.3 mm KA 40 mm P PT1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008EIG

  Specifications: 2KW03008EIG is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has G1/4 ports, a 3 mm orifice and a 24 V AC coil. The pressure-condition code selects the standard configuration. The I code selects grommet electrical entry with a 0.5 m wire. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008EIG will be supplied as 2KWA03008EIG under our store's replacement policy. The technical information below documents the legacy 2KW03008EIG; use the new 2KWA catalog for the supplied 2KWA03008EIG. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: G1/4. E Coil supply: 24 V AC. I Grommet electrical entry with a 0.5 m wire. G G thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread G1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 295 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight column describes terminal-entry valves. Its explicit grommet-entry footnote reduces that value by 10 g for this size, giving the 295 g reference above. Catalog weights are reference values, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CLA116 Rated voltage 24 V AC Voltage tolerance ±15% for AC Electrical entry Grommet; 0.5 m wire Protection class IP65 50 Hz power consumption 15 VA 60 Hz power consumption 11 VA Temperature rise at 50 Hz 50°C Temperature rise at 60 Hz 40°C Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the grommet-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 41 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm G 10 mm K 5.3 mm KA 40 mm P G1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008EIT

  Specifications: 2KW03008EIT is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has NPT1/4 ports, a 3 mm orifice and a 24 V AC coil. The pressure-condition code selects the standard configuration. The I code selects grommet electrical entry with a 0.5 m wire. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008EIT will be supplied as 2KWA03008EIT under our store's replacement policy. The technical information below documents the legacy 2KW03008EIT; use the new 2KWA catalog for the supplied 2KWA03008EIT. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: NPT1/4. E Coil supply: 24 V AC. I Grommet electrical entry with a 0.5 m wire. T NPT thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread NPT1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 295 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight column describes terminal-entry valves. Its explicit grommet-entry footnote reduces that value by 10 g for this size, giving the 295 g reference above. Catalog weights are reference values, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CLA116 Rated voltage 24 V AC Voltage tolerance ±15% for AC Electrical entry Grommet; 0.5 m wire Protection class IP65 50 Hz power consumption 15 VA 60 Hz power consumption 11 VA Temperature rise at 50 Hz 50°C Temperature rise at 60 Hz 40°C Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the grommet-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 41 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm G 10 mm K 5.3 mm KA 40 mm P NPT1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008ET

  Specifications: 2KW03008ET is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has NPT1/4 ports, a 3 mm orifice and a 24 V AC coil. The pressure-condition code selects the standard configuration. The blank electrical-entry code selects the terminal version. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008ET will be supplied as 2KWA03008ET under our store's replacement policy. The technical information below documents the legacy 2KW03008ET; use the new 2KWA catalog for the supplied 2KWA03008ET. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: NPT1/4. E Coil supply: 24 V AC. (blank entry code) Terminal electrical entry. T NPT thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread NPT1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 305 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight is the terminal-entry reference. It is a reference value, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CDA116 Rated voltage 24 V AC Voltage tolerance ±15% for AC Electrical entry Terminal Protection class IP65 50 Hz power consumption 15 VA 60 Hz power consumption 11 VA Temperature rise at 50 Hz 50°C Temperature rise at 60 Hz 40°C Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the terminal-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 72.5 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm F 43.5 mm G 10 mm K 5.3 mm KA 40 mm P NPT1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008F

  Specifications: 2KW03008F is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has PT1/4 ports, a 3 mm orifice and a 12 V DC coil. The pressure-condition code selects the standard configuration. The blank electrical-entry code selects the terminal version. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008F will be supplied as 2KWA03008F under our store's replacement policy. The technical information below documents the legacy 2KW03008F; use the new 2KWA catalog for the supplied 2KWA03008F. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: PT1/4. F Coil supply: 12 V DC. (blank entry code) Terminal electrical entry. (blank thread suffix) PT thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread PT1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 305 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight is the terminal-entry reference. It is a reference value, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CDA116 Rated voltage 12 V DC Voltage tolerance ±10% for DC Electrical entry Terminal Protection class IP65 DC power consumption 6.5 W Temperature rise on DC 30°C Supply frequency Not applicable to DC Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the terminal-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 72.5 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm F 43.5 mm G 10 mm K 5.3 mm KA 40 mm P PT1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008FG

  Specifications: 2KW03008FG is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has G1/4 ports, a 3 mm orifice and a 12 V DC coil. The pressure-condition code selects the standard configuration. The blank electrical-entry code selects the terminal version. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008FG will be supplied as 2KWA03008FG under our store's replacement policy. The technical information below documents the legacy 2KW03008FG; use the new 2KWA catalog for the supplied 2KWA03008FG. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: G1/4. F Coil supply: 12 V DC. (blank entry code) Terminal electrical entry. G G thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread G1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 305 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight is the terminal-entry reference. It is a reference value, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CDA116 Rated voltage 12 V DC Voltage tolerance ±10% for DC Electrical entry Terminal Protection class IP65 DC power consumption 6.5 W Temperature rise on DC 30°C Supply frequency Not applicable to DC Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the terminal-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 72.5 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm F 43.5 mm G 10 mm K 5.3 mm KA 40 mm P G1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008FI

  Specifications: 2KW03008FI is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has PT1/4 ports, a 3 mm orifice and a 12 V DC coil. The pressure-condition code selects the standard configuration. The I code selects grommet electrical entry with a 0.5 m wire. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008FI will be supplied as 2KWA03008FI under our store's replacement policy. The technical information below documents the legacy 2KW03008FI; use the new 2KWA catalog for the supplied 2KWA03008FI. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: PT1/4. F Coil supply: 12 V DC. I Grommet electrical entry with a 0.5 m wire. (blank thread suffix) PT thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread PT1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 295 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight column describes terminal-entry valves. Its explicit grommet-entry footnote reduces that value by 10 g for this size, giving the 295 g reference above. Catalog weights are reference values, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CLA116 Rated voltage 12 V DC Voltage tolerance ±10% for DC Electrical entry Grommet; 0.5 m wire Protection class IP65 DC power consumption 6.5 W Temperature rise on DC 30°C Supply frequency Not applicable to DC Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the grommet-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 41 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm G 10 mm K 5.3 mm KA 40 mm P PT1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options

•

  View options

  Airtac 2KW series: two-way fluid solenoid valve - 2KW03008FIG

  Specifications: 2KW03008FIG is an AirTAC 2KW series direct-acting, normally open 2/2-way fluid-control valve. It has G1/4 ports, a 3 mm orifice and a 12 V DC coil. The pressure-condition code selects the standard configuration. The I code selects grommet electrical entry with a 0.5 m wire. Product Catalogs Download Legacy 2KW Catalog (PDF) Download New 2KWA Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Legacy-to-New Model and Ordering Information Orders placed for legacy 2KW03008FIG will be supplied as 2KWA03008FIG under our store's replacement policy. The technical information below documents the legacy 2KW03008FIG; use the new 2KWA catalog for the supplied 2KWA03008FIG. Compare the correct terminal or grommet drawing before installation. The replacement policy does not establish identical dimensions, mounting geometry or interchangeable coils. 2KW vs 2KWA: Length, Dimensions and Replacement Guide Model Code Explained Code Meaning for this model 2KW 2KW series 2/2-way fluid-control valve; normally open. (blank pressure code) Standard option. 030 030 size series; the pressure-condition code determines its orifice and flow data. 08 1/4 in port size; selected thread: G1/4. F Coil supply: 12 V DC. I Grommet electrical entry with a 0.5 m wire. G G thread standard. Technical Specifications - 2KW The following values are from 2KW PDF page 1 and describe the listed configuration. Pressure differential is the inlet-to-outlet pressure difference; proof pressure is a separate test value. Parameter Details Valve function 2/2-way: two ports and two operating positions Actuation Direct acting Initial state Normally open Media Air, water and oil Body material Brass Standard seal material FPM-F; contact the supplier if another seal material is required Viscosity limit Below 20 cSt Port thread G1/4 Orifice diameter 3 mm Flow coefficient Cv 0.33 Effective area / section 6 mm² Pressure differential 0.7 MPa maximum operating pressure differential Proof pressure 3.0 MPa Catalog reference weight 295 g Water temperature 1 to 80°C Air temperature -20 to 90°C; the catalog specifies an air dew point of -20°C or lower Oil temperature -10 to 80°C; the catalog footnote states 50 cSt or less at the lower-temperature condition Ambient temperature -20 to 70°C The catalog weight column describes terminal-entry valves. Its explicit grommet-entry footnote reduces that value by 10 g for this size, giving the 295 g reference above. Catalog weights are reference values, not a recorded weighing of this individual item. The general viscosity limit and the lower-temperature oil footnote are retained as separate catalog statements. Check the actual medium and temperature against both before selection. Electrical Specifications Parameter Details Coil designation for this entry CLA116 Rated voltage 12 V DC Voltage tolerance ±10% for DC Electrical entry Grommet; 0.5 m wire Protection class IP65 DC power consumption 6.5 W Temperature rise on DC 30°C Supply frequency Not applicable to DC Insulation class Class B Coil temperature rise is distinct from the ambient and fluid-temperature limits. The power figures are the values tabulated for the selected AC or DC supply. Features and Operation This 2/2-way valve is normally open when not energized. The 030 and 050 branches use direct-acting construction. The compact brass body is intended for air, water and oil within the catalog limits. The catalog describes rapid response, easy installation and dismantling. Terminal and grommet electrical entries are separate order-code choices. The grommet option includes the catalog-specified 0.5 m wire. The illustrated mounting bracket is optional. It is not included merely because it appears in a dimensional drawing. External and Mounting Dimensions These are the grommet-entry drawing values in the 2KW PDF, page 2. Each letter below refers to its own dimension line; do not combine unrelated spans into an assumed overall length × width × height. Drawing letter Dimension / specification A 41 mm AB 40 mm B 29.5 mm C 76 mm D 20 mm E 49 mm G 10 mm K 5.3 mm KA 40 mm P G1/4 PA 10 mm Q M5 QA 16 mm The drawing marks two holes as 2-ØK (K = 5.3 mm), two threaded locations as 2-Q (Q = M5), and the bracket as optional. P is the valve port thread. Use the original views to locate QA, KA and the bracket outline; a listed hole diameter alone does not prove interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Reference Parameter Details Air chart vertical axis Downstream pressure P2, 0-1.0 MPa; curves identify upstream pressure P1 and sonic / subsonic regions Air chart flow axis Orifice Ø3 mm: Q in L/min (ANR); marked values 100-600, in steps of 100 Water chart vertical axis Flow Q in L/min, logarithmic scale; visible reference labels from 0.1 to 50 Water chart horizontal axis Pressure differential ΔP = P1 - P2, in MPa; visible labels 0.001-0.6 The original flow charts are on 2KW PDF page 2. Chart axes are reading scales, not guaranteed flow ratings. Use the curve for the correct orifice and medium; do not substitute a value estimated from a graph for a tabulated Cv or effective area. Internal Components - Catalog Reference The following numbered key is the catalog illustration for 2KW030 (grommet), on PDF page 1. It is a drawing reference, not an included-parts quantity list or a list of independent ordering codes. Other size and entry versions must be checked against their own assembly. Drawing number Component 1 Body 2 Airtight ring 3 Spring 4 Bead flange 5 O-ring 6 Fixed plate 7 Fixed cap 8 Electromagnet 9 Mandrel 10 Coil assembly 11 E-clip 12 Position ring 13 Washer 14 Spring 15 Screw 16 Airtight bush 17 Filter Mounting Accessory Reference The 2KW catalog directs accessory orders to the 2S accessory ordering information (printed page 194). That shared ordering table identifies F-2S030LB for this size. The bracket is optional. The supplied catalog does not tabulate a separate bracket weight or a package-component count. Select the bracket for the actual valve family and drawing; legacy and new bracket compatibility must not be inferred from a similar listing name. Series Ordering Options These are alternative series choices, not additional configurations included with this order. The Model Code Explained table above states the actual selection. Ordering category Available catalog options Size / port combinations 030: 06 (1/8 in) or 08 (1/4 in); 050: 10 (3/8 in) or 15 (1/2 in) Pressure-condition codes X = extra high pressure; H = high pressure; blank = standard; L = large flow Voltage codes A = 220 V AC; B = 24 V DC; C = 110 V AC; E = 24 V AC; F = 12 V DC Electrical-entry code Blank = terminal; I = grommet with a 0.5 m wire Thread suffix Blank = PT; G = G thread; T = NPT

  Read more less

  $62.20

  View options
