  Airtac UCS series: coiled polyurethane air tubing - UCS120080CE150MA3

  Specifications: UCS120080CE150MA3 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear orange, with 15 m material length. One straight end 30 cm long and the other 10 cm long; two male couplings. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CE Clear orange 150M Material length: 15 m A One straight end 30 cm long and the other 10 cm long 3 Two male couplings Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 15 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 12–13.5 m. This is not the unstretched coil length. Color Clear orange Estimated Weight Reference Parameter Details Estimated reference weight 1234 g, excluding packaging Tubing calculation 75.60 g/m × 15.0 m = 1134.000 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 50 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement One straight end 30 cm long and the other 10 cm long Material length 15 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form Two male couplings Catalog-listed compatible male part GX-400-40PP Coupling count for the complete hose Two male Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $103.57

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS080050CY060MA1

  Specifications: UCS080050CY060MA1 is UCS ester-based polyurethane coiled tubing, 8 × 5 mm OD × ID, clear yellow, with 6 m material length. One straight end 30 cm long and the other 10 cm long; without couplings. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 080 Outside diameter: 8 mm 050 Inside diameter: 5 mm CY Clear yellow 060M Material length: 6 m A One straight end 30 cm long and the other 10 cm long 1 Without couplings Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 8 × 5 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 38 mm Material length 6 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 4.8–5.4 m. This is not the unstretched coil length. Color Clear yellow Estimated Weight Reference Parameter Details Estimated reference weight 220 g, excluding packaging Tubing calculation 36.60 g/m × 6.0 m = 219.600 g; based on same-size ester-based US98A tubing This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 8 / 5 mm Bending radius 38 mm Straight-end arrangement One straight end 30 cm long and the other 10 cm long Material length 6 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form Without couplings Included couplings None; form 1 identifies the tubing without couplings Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table. Matching Accessory Codes and Conditions This UCS order has coupling form 1 and is supplied without couplings. The listed male and female GX parts are optional, separately ordered tube-end choices; select only the type and quantity required by the verified assembly. They do not change the ordered supply configuration or include any host equipment. Straight-end code A retains the original 30 cm / 10 cm arrangement; it is independent of coupling form 1, 2 or 3. Do not treat the list as a mandatory male/female pair or as approval for arbitrary external mating components. The UCS tube is rated 1 MPa working pressure at 23°C, with 3 MPa burst pressure that is not an operating rating. Apply the PU temperature-derating curve within the tube’s −20–70°C range and every stricter system limit. The 8 × 5 mm tube has a 38 mm catalogue bending radius. Support the coiled tube and its ends against twisting, pull and kinking; the published working-state length of 0.8–0.9 times material length is not a guarantee of permissible installation tension or an overall assembly dimension. The pipe-end table does not publish separate GX body dimensions, thread specifications, materials, pressure, temperature or fluid ratings. Confirm these and the required tube-end retention, sealing and assembly method with the supplier before use; the tube’s air/water statement and pressure rating do not establish the rating of the coupling or finished assembly. Verify compatibility with the actual fluid, lubricant, contaminants and environment; retain the tube restrictions on acids, alkalis, solvents, seawater, corrosive gases, prolonged sunlight and excessive heat. Isolate and verify zero pressure before assembling, removing or servicing the connection. No vacuum, zero-leak isolation, cross-series interchangeability, current-stock or retail-pack quantity is established here. Item Complete codes and use Optional male tube-end quick coupling Catalog-listed male GX quick coupling for the UCS 8 mm OD × 5 mm ID tube end. Both tube dimensions must match; the male designation describes the quick-coupling end, not a published pipe-thread standard. This is a separately selected tube-end option, not an included part or a verified external-equipment interface.GX-400-20PP Optional female tube-end quick coupling Catalog-listed female GX quick coupling for the UCS 8 mm OD × 5 mm ID tube end. Both tube dimensions must match; the female designation describes the quick-coupling end, not a published pipe-thread standard. This is a separately selected tube-end option, not an included part or a verified external-equipment interface.GX-230-20SP

  Read more less

  $11.99

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS060040CY060MC2

  Specifications: UCS060040CY060MC2 is UCS ester-based polyurethane coiled tubing, 6 × 4 mm OD × ID, clear yellow, with 6 m material length. Both straight ends 0 cm long; one female and one male coupling. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 060 Outside diameter: 6 mm 040 Inside diameter: 4 mm CY Clear yellow 060M Material length: 6 m C Both straight ends 0 cm long 2 One female and one male coupling Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 6 × 4 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 38 mm Material length 6 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 4.8–5.4 m. This is not the unstretched coil length. Color Clear yellow Estimated Weight Reference Parameter Details Estimated reference weight 263 g, excluding packaging Tubing calculation 19.30 g/m × 6.0 m = 115.800 g; based on same-size ester-based US98A tubing Coupling mass allowance 30 g + 117 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 6 / 4 mm Bending radius 38 mm Straight-end arrangement Both straight ends 0 cm long Material length 6 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form One female and one male coupling Catalog-listed compatible male part GX-400-10PP Catalog-listed compatible female part GX-230-10SP Coupling count for the complete hose One male and one female Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 3 m, 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $17.65

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CE150MC3

  Specifications: UCS120080CE150MC3 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear orange, with 15 m material length. Both straight ends 0 cm long; two male couplings. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CE Clear orange 150M Material length: 15 m C Both straight ends 0 cm long 3 Two male couplings Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 15 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 12–13.5 m. This is not the unstretched coil length. Color Clear orange Estimated Weight Reference Parameter Details Estimated reference weight 1234 g, excluding packaging Tubing calculation 75.60 g/m × 15.0 m = 1134.000 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 50 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement Both straight ends 0 cm long Material length 15 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form Two male couplings Catalog-listed compatible male part GX-400-40PP Coupling count for the complete hose Two male Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $103.57

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CE120MB2

  Specifications: UCS120080CE120MB2 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear orange, with 12 m material length. Both straight ends 10 cm long; one female and one male coupling. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CE Clear orange 120M Material length: 12 m B Both straight ends 10 cm long 2 One female and one male coupling Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 12 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 9.6–10.8 m. This is not the unstretched coil length. Color Clear orange Estimated Weight Reference Parameter Details Estimated reference weight 1077 g, excluding packaging Tubing calculation 75.60 g/m × 12.0 m = 907.200 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 120 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement Both straight ends 10 cm long Material length 12 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form One female and one male coupling Catalog-listed compatible male part GX-400-40PP Catalog-listed compatible female part GX-230-40SP Coupling count for the complete hose One male and one female Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $94.68

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CE120MA3

  Specifications: UCS120080CE120MA3 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear orange, with 12 m material length. One straight end 30 cm long and the other 10 cm long; two male couplings. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CE Clear orange 120M Material length: 12 m A One straight end 30 cm long and the other 10 cm long 3 Two male couplings Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 12 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 9.6–10.8 m. This is not the unstretched coil length. Color Clear orange Estimated Weight Reference Parameter Details Estimated reference weight 1007 g, excluding packaging Tubing calculation 75.60 g/m × 12.0 m = 907.200 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 50 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement One straight end 30 cm long and the other 10 cm long Material length 12 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form Two male couplings Catalog-listed compatible male part GX-400-40PP Coupling count for the complete hose Two male Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $86.08

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CE120MA2

  Specifications: UCS120080CE120MA2 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear orange, with 12 m material length. One straight end 30 cm long and the other 10 cm long; one female and one male coupling. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CE Clear orange 120M Material length: 12 m A One straight end 30 cm long and the other 10 cm long 2 One female and one male coupling Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 12 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 9.6–10.8 m. This is not the unstretched coil length. Color Clear orange Estimated Weight Reference Parameter Details Estimated reference weight 1077 g, excluding packaging Tubing calculation 75.60 g/m × 12.0 m = 907.200 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 120 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement One straight end 30 cm long and the other 10 cm long Material length 12 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form One female and one male coupling Catalog-listed compatible male part GX-400-40PP Catalog-listed compatible female part GX-230-40SP Coupling count for the complete hose One male and one female Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $94.68

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CE090MA3

  Specifications: UCS120080CE090MA3 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear orange, with 9 m material length. One straight end 30 cm long and the other 10 cm long; two male couplings. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CE Clear orange 090M Material length: 9 m A One straight end 30 cm long and the other 10 cm long 3 Two male couplings Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 9 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 7.2–8.1 m. This is not the unstretched coil length. Color Clear orange Estimated Weight Reference Parameter Details Estimated reference weight 780 g, excluding packaging Tubing calculation 75.60 g/m × 9.0 m = 680.400 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 50 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement One straight end 30 cm long and the other 10 cm long Material length 9 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form Two male couplings Catalog-listed compatible male part GX-400-40PP Coupling count for the complete hose Two male Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $57.05

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CE060MC2

  Specifications: UCS120080CE060MC2 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear orange, with 6 m material length. Both straight ends 0 cm long; one female and one male coupling. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CE Clear orange 060M Material length: 6 m C Both straight ends 0 cm long 2 One female and one male coupling Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 6 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 4.8–5.4 m. This is not the unstretched coil length. Color Clear orange Estimated Weight Reference Parameter Details Estimated reference weight 624 g, excluding packaging Tubing calculation 75.60 g/m × 6.0 m = 453.600 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 120 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement Both straight ends 0 cm long Material length 6 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form One female and one male coupling Catalog-listed compatible male part GX-400-40PP Catalog-listed compatible female part GX-230-40SP Coupling count for the complete hose One male and one female Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $48.90

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CY150MB2

  Specifications: UCS120080CY150MB2 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear yellow, with 15 m material length. Both straight ends 10 cm long; one female and one male coupling. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CY Clear yellow 150M Material length: 15 m B Both straight ends 10 cm long 2 One female and one male coupling Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 15 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 12–13.5 m. This is not the unstretched coil length. Color Clear yellow Estimated Weight Reference Parameter Details Estimated reference weight 1304 g, excluding packaging Tubing calculation 75.60 g/m × 15.0 m = 1134.000 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 120 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement Both straight ends 10 cm long Material length 15 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form One female and one male coupling Catalog-listed compatible male part GX-400-40PP Catalog-listed compatible female part GX-230-40SP Coupling count for the complete hose One male and one female Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $113.39

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CY150MA2

  Specifications: UCS120080CY150MA2 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear yellow, with 15 m material length. One straight end 30 cm long and the other 10 cm long; one female and one male coupling. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CY Clear yellow 150M Material length: 15 m A One straight end 30 cm long and the other 10 cm long 2 One female and one male coupling Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 15 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 12–13.5 m. This is not the unstretched coil length. Color Clear yellow Estimated Weight Reference Parameter Details Estimated reference weight 1304 g, excluding packaging Tubing calculation 75.60 g/m × 15.0 m = 1134.000 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 120 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement One straight end 30 cm long and the other 10 cm long Material length 15 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form One female and one male coupling Catalog-listed compatible male part GX-400-40PP Catalog-listed compatible female part GX-230-40SP Coupling count for the complete hose One male and one female Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $113.39

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CY120MB2

  Specifications: UCS120080CY120MB2 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear yellow, with 12 m material length. Both straight ends 10 cm long; one female and one male coupling. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CY Clear yellow 120M Material length: 12 m B Both straight ends 10 cm long 2 One female and one male coupling Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 12 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 9.6–10.8 m. This is not the unstretched coil length. Color Clear yellow Estimated Weight Reference Parameter Details Estimated reference weight 1077 g, excluding packaging Tubing calculation 75.60 g/m × 12.0 m = 907.200 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 120 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement Both straight ends 10 cm long Material length 12 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form One female and one male coupling Catalog-listed compatible male part GX-400-40PP Catalog-listed compatible female part GX-230-40SP Coupling count for the complete hose One male and one female Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $94.68

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CY120MA3

  Specifications: UCS120080CY120MA3 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear yellow, with 12 m material length. One straight end 30 cm long and the other 10 cm long; two male couplings. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CY Clear yellow 120M Material length: 12 m A One straight end 30 cm long and the other 10 cm long 3 Two male couplings Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 12 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 9.6–10.8 m. This is not the unstretched coil length. Color Clear yellow Estimated Weight Reference Parameter Details Estimated reference weight 1007 g, excluding packaging Tubing calculation 75.60 g/m × 12.0 m = 907.200 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 50 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement One straight end 30 cm long and the other 10 cm long Material length 12 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form Two male couplings Catalog-listed compatible male part GX-400-40PP Coupling count for the complete hose Two male Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $86.08

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CY120MA1

  Specifications: UCS120080CY120MA1 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear yellow, with 12 m material length. One straight end 30 cm long and the other 10 cm long; without couplings. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CY Clear yellow 120M Material length: 12 m A One straight end 30 cm long and the other 10 cm long 1 Without couplings Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 12 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 9.6–10.8 m. This is not the unstretched coil length. Color Clear yellow Estimated Weight Reference Parameter Details Estimated reference weight 907 g, excluding packaging Tubing calculation 75.60 g/m × 12.0 m = 907.200 g; based on same-size ester-based US98A tubing This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement One straight end 30 cm long and the other 10 cm long Material length 12 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form Without couplings Included couplings None; form 1 identifies the tubing without couplings Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table. Matching Accessory Codes and Conditions This UCS order has coupling form 1 and is supplied without couplings. The listed male and female GX parts are optional, separately ordered tube-end choices; select only the type and quantity required by the verified assembly. They do not change the ordered supply configuration or include any host equipment. Straight-end code A retains the original 30 cm / 10 cm arrangement; it is independent of coupling form 1, 2 or 3. Do not treat the list as a mandatory male/female pair or as approval for arbitrary external mating components. The UCS tube is rated 1 MPa working pressure at 23°C, with 3 MPa burst pressure that is not an operating rating. Apply the PU temperature-derating curve within the tube’s −20–70°C range and every stricter system limit. The 12 × 8 mm tube has a 60 mm catalogue bending radius. Support the coiled tube and its ends against twisting, pull and kinking; the published working-state length of 0.8–0.9 times material length is not a guarantee of permissible installation tension or an overall assembly dimension. The pipe-end table does not publish separate GX body dimensions, thread specifications, materials, pressure, temperature or fluid ratings. Confirm these and the required tube-end retention, sealing and assembly method with the supplier before use; the tube’s air/water statement and pressure rating do not establish the rating of the coupling or finished assembly. Verify compatibility with the actual fluid, lubricant, contaminants and environment; retain the tube restrictions on acids, alkalis, solvents, seawater, corrosive gases, prolonged sunlight and excessive heat. Isolate and verify zero pressure before assembling, removing or servicing the connection. No vacuum, zero-leak isolation, cross-series interchangeability, current-stock or retail-pack quantity is established here. Item Complete codes and use Optional male tube-end quick coupling Catalog-listed male GX quick coupling for the UCS 12 mm OD × 8 mm ID tube end. Both tube dimensions must match; the male designation describes the quick-coupling end, not a published pipe-thread standard. This is a separately selected tube-end option, not an included part or a verified external-equipment interface.GX-400-40PP Optional female tube-end quick coupling Catalog-listed female GX quick coupling for the UCS 12 mm OD × 8 mm ID tube end. Both tube dimensions must match; the female designation describes the quick-coupling end, not a published pipe-thread standard. This is a separately selected tube-end option, not an included part or a verified external-equipment interface.GX-230-40SP

  Read more less

  $55.40

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CY090MA3

  Specifications: UCS120080CY090MA3 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear yellow, with 9 m material length. One straight end 30 cm long and the other 10 cm long; two male couplings. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CY Clear yellow 090M Material length: 9 m A One straight end 30 cm long and the other 10 cm long 3 Two male couplings Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 9 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 7.2–8.1 m. This is not the unstretched coil length. Color Clear yellow Estimated Weight Reference Parameter Details Estimated reference weight 780 g, excluding packaging Tubing calculation 75.60 g/m × 9.0 m = 680.400 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 50 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement One straight end 30 cm long and the other 10 cm long Material length 9 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form Two male couplings Catalog-listed compatible male part GX-400-40PP Coupling count for the complete hose Two male Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $57.05

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CG150MA3

  Specifications: UCS120080CG150MA3 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear green, with 15 m material length. One straight end 30 cm long and the other 10 cm long; two male couplings. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CG Clear green 150M Material length: 15 m A One straight end 30 cm long and the other 10 cm long 3 Two male couplings Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 15 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 12–13.5 m. This is not the unstretched coil length. Color Clear green Estimated Weight Reference Parameter Details Estimated reference weight 1234 g, excluding packaging Tubing calculation 75.60 g/m × 15.0 m = 1134.000 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 50 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement One straight end 30 cm long and the other 10 cm long Material length 15 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form Two male couplings Catalog-listed compatible male part GX-400-40PP Coupling count for the complete hose Two male Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $103.57

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CG120MB3

  Specifications: UCS120080CG120MB3 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear green, with 12 m material length. Both straight ends 10 cm long; two male couplings. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CG Clear green 120M Material length: 12 m B Both straight ends 10 cm long 3 Two male couplings Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 12 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 9.6–10.8 m. This is not the unstretched coil length. Color Clear green Estimated Weight Reference Parameter Details Estimated reference weight 1007 g, excluding packaging Tubing calculation 75.60 g/m × 12.0 m = 907.200 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 50 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement Both straight ends 10 cm long Material length 12 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form Two male couplings Catalog-listed compatible male part GX-400-40PP Coupling count for the complete hose Two male Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $86.08

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CG120MA3

  Specifications: UCS120080CG120MA3 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear green, with 12 m material length. One straight end 30 cm long and the other 10 cm long; two male couplings. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CG Clear green 120M Material length: 12 m A One straight end 30 cm long and the other 10 cm long 3 Two male couplings Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 12 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 9.6–10.8 m. This is not the unstretched coil length. Color Clear green Estimated Weight Reference Parameter Details Estimated reference weight 1007 g, excluding packaging Tubing calculation 75.60 g/m × 12.0 m = 907.200 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 50 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement One straight end 30 cm long and the other 10 cm long Material length 12 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form Two male couplings Catalog-listed compatible male part GX-400-40PP Coupling count for the complete hose Two male Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $86.08

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CG090MC3

  Specifications: UCS120080CG090MC3 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear green, with 9 m material length. Both straight ends 0 cm long; two male couplings. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CG Clear green 090M Material length: 9 m C Both straight ends 0 cm long 3 Two male couplings Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 9 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 7.2–8.1 m. This is not the unstretched coil length. Color Clear green Estimated Weight Reference Parameter Details Estimated reference weight 780 g, excluding packaging Tubing calculation 75.60 g/m × 9.0 m = 680.400 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 50 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement Both straight ends 0 cm long Material length 9 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form Two male couplings Catalog-listed compatible male part GX-400-40PP Coupling count for the complete hose Two male Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $57.05

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CG090MB3

  Specifications: UCS120080CG090MB3 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear green, with 9 m material length. Both straight ends 10 cm long; two male couplings. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CG Clear green 090M Material length: 9 m B Both straight ends 10 cm long 3 Two male couplings Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 9 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 7.2–8.1 m. This is not the unstretched coil length. Color Clear green Estimated Weight Reference Parameter Details Estimated reference weight 780 g, excluding packaging Tubing calculation 75.60 g/m × 9.0 m = 680.400 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 50 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement Both straight ends 10 cm long Material length 9 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form Two male couplings Catalog-listed compatible male part GX-400-40PP Coupling count for the complete hose Two male Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $57.05

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CG090MA2

  Specifications: UCS120080CG090MA2 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear green, with 9 m material length. One straight end 30 cm long and the other 10 cm long; one female and one male coupling. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CG Clear green 090M Material length: 9 m A One straight end 30 cm long and the other 10 cm long 2 One female and one male coupling Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 9 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 7.2–8.1 m. This is not the unstretched coil length. Color Clear green Estimated Weight Reference Parameter Details Estimated reference weight 850 g, excluding packaging Tubing calculation 75.60 g/m × 9.0 m = 680.400 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 120 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement One straight end 30 cm long and the other 10 cm long Material length 9 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form One female and one male coupling Catalog-listed compatible male part GX-400-40PP Catalog-listed compatible female part GX-230-40SP Coupling count for the complete hose One male and one female Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $66.29

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CG060MB3

  Specifications: UCS120080CG060MB3 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear green, with 6 m material length. Both straight ends 10 cm long; two male couplings. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CG Clear green 060M Material length: 6 m B Both straight ends 10 cm long 3 Two male couplings Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 6 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 4.8–5.4 m. This is not the unstretched coil length. Color Clear green Estimated Weight Reference Parameter Details Estimated reference weight 554 g, excluding packaging Tubing calculation 75.60 g/m × 6.0 m = 453.600 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 50 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement Both straight ends 10 cm long Material length 6 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form Two male couplings Catalog-listed compatible male part GX-400-40PP Coupling count for the complete hose Two male Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $42.37

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CG060MA3

  Specifications: UCS120080CG060MA3 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear green, with 6 m material length. One straight end 30 cm long and the other 10 cm long; two male couplings. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CG Clear green 060M Material length: 6 m A One straight end 30 cm long and the other 10 cm long 3 Two male couplings Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 6 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 4.8–5.4 m. This is not the unstretched coil length. Color Clear green Estimated Weight Reference Parameter Details Estimated reference weight 554 g, excluding packaging Tubing calculation 75.60 g/m × 6.0 m = 453.600 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 50 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement One straight end 30 cm long and the other 10 cm long Material length 6 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form Two male couplings Catalog-listed compatible male part GX-400-40PP Coupling count for the complete hose Two male Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $42.37

  View options

•

  View options

  Airtac UCS series: coiled polyurethane air tubing - UCS120080CR150MC2

  Specifications: UCS120080CR150MC2 is UCS ester-based polyurethane coiled tubing, 12 × 8 mm OD × ID, clear red, with 15 m material length. Both straight ends 0 cm long; one female and one male coupling. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning UCS Ester-based polyurethane coiled tubing 120 Outside diameter: 12 mm 080 Inside diameter: 8 mm CR Clear red 150M Material length: 15 m C Both straight ends 0 cm long 2 One female and one male coupling Technical Specifications Parameter Details Series UCS Pressure branch Standard pressure Tube OD × ID 12 × 8 mm Material Ester-based polyurethane Applicable media Air and water, per the Chinese catalog Working pressure at 23°C 1 MPa Burst pressure at 23°C 3 MPa; not a working-pressure rating Temperature range −20 to 70°C Bending radius 60 mm Material length 15 m Working-state length Catalog formula: 0.8–0.9 × material length; for this item, 12–13.5 m. This is not the unstretched coil length. Color Clear red Estimated Weight Reference Parameter Details Estimated reference weight 1304 g, excluding packaging Tubing calculation 75.60 g/m × 15.0 m = 1134.000 g; based on same-size ester-based US98A tubing Coupling mass allowance 50 g + 120 g using comparable quick-coupling weight references This is a reference estimate, not a published AirTAC mass or a measured weight of the supplied product. The coupling benchmark estimates mass only and does not establish dimensional or functional interchangeability. Features and Operation Thermoplastic polyurethane material is described in the catalog as meeting RoHS environmental requirements. High elasticity and a small bending radius help route the tubing through confined spaces. The catalog describes improved kink resistance compared with other plastic tubing. Good flexibility supports repeated extension and contraction. Abrasion resistance supports use where the tubing is exposed to wear. Low gas permeability helps reduce leakage and contamination. Resistance to dissolution and low compression help maintain the material’s physical properties. The Chinese catalog identifies air and water as applicable media. Avoid acidic or alkaline environments, chemical agents, organic solvents, seawater, corrosive gases, and prolonged exposure to sunlight or heat. The catalog warns that these conditions can cause cracking or damage. External and Installation Dimensions Parameter Details Tube outside / inside diameter 12 / 8 mm Bending radius 60 mm Straight-end arrangement Both straight ends 0 cm long Material length 15 m Dimension reference The catalog’s illustration shows the straight-end arrangement; material length is not an assembled outside dimension. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Assembly and Compatible Couplings Parameter Details Current coupling form One female and one male coupling Catalog-listed compatible male part GX-400-40PP Catalog-listed compatible female part GX-230-40SP Coupling count for the complete hose One male and one female Pressure and Hardness Reference Charts The pressure-retention chart plots temperature at 23, 37, 51 and 65°C against 0–100% of reference working pressure. Curves compare nylon, PU, PE and PVC; use the PU curve for this material. It is a graphical comparison and does not replace the size-specific pressure table. The adjacent hardness comparison uses Shore A, Shore D and Rockwell R scales. Visible ranges are approximately Shore A 20–100, Shore D 40–90 and Rockwell R 50–150. This comparison chart does not assign a numerical hardness to the UCS model. The catalog includes a nominal 3:1 pressure safety-factor note. The lower-pressure table lists 0.8 MPa working and 2.0 MPa burst pressure; these values are reproduced as printed rather than recalculated. Series Ordering Options Parameter Details Tube size branches 6 × 4, 8 × 5, 10 × 6.5 and 12 × 8 mm standard-pressure tubing; 8 × 5.5 mm lower-pressure tubing Material lengths for this size 6 m, 9 m, 12 m, 15 m Straight-end codes A: 30 cm / 10 cm; B: 10 cm / 10 cm; C: 0 cm / 0 cm Coupling form codes 1: none; 2: female–male; 3: male–male Documented color codes BU = Blue; BK = Black; GE = Orange; C = Clear; WH = White; CB = Clear blue; R = Red; Y = Yellow; GN = Green; BR = Brown; CR = Clear red; CG = Clear green; CY = Clear yellow; CE = Clear orange Lower-pressure color note The catalog also mentions gray in the nine-color lower-pressure note, but does not assign its ordering-code token in the UCS color table.

  Read more less

  $113.39

  View options
