Filter Regulator Combination

Show previous products

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC4000LN

  Specifications: BFC4000LN is an AirTAC BFC filter-regulator and lubricator combination with PT 1/2 ports, a 40 µm filter and semi-automatic drain with manual drainage, the 0.4 MPa lower-pressure regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 4000 1/2-inch nominal port size Blank drain code semi-automatic drain with manual drainage L Lower-pressure type: maximum adjustable pressure 0.4 MPa N No pressure gauge Blank filter code 40 µm filter element Blank thread code PT connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC4000LN Working medium Air Main ports PT 1/2; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.4 MPa; the selected lower-pressure type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 40 µm Drain type semi-automatic drain with manual drainage Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR4000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL4000 lubricator Drain and Service Notes The selected drain is semi-automatic drain with manual drainage. The semi-automatic drain also allows manual drainage. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection PT 1/2 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 4000 differs from the reference; low-pressure option L; gauge option N. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $61.65

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC4000NWT

  Specifications: BFC4000NWT is an AirTAC BFC filter-regulator and lubricator combination with NPT 1/2 ports, a 5 µm filter and semi-automatic drain with manual drainage, the 0.9 MPa standard regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 4000 1/2-inch nominal port size Blank drain code semi-automatic drain with manual drainage Blank type code Standard type: maximum adjustable pressure 0.9 MPa N No pressure gauge W 5 µm filter element T NPT connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC4000NWT Working medium Air Main ports NPT 1/2; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.9 MPa; the selected standard type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 5 µm Drain type semi-automatic drain with manual drainage Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR4000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL4000 lubricator Drain and Service Notes The selected drain is semi-automatic drain with manual drainage. The semi-automatic drain also allows manual drainage. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection NPT 1/2 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 4000 differs from the reference; gauge option N; filter option W; thread option T. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $61.65

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC4000NWG

  Specifications: BFC4000NWG is an AirTAC BFC filter-regulator and lubricator combination with G 1/2 ports, a 5 µm filter and semi-automatic drain with manual drainage, the 0.9 MPa standard regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 4000 1/2-inch nominal port size Blank drain code semi-automatic drain with manual drainage Blank type code Standard type: maximum adjustable pressure 0.9 MPa N No pressure gauge W 5 µm filter element G G connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC4000NWG Working medium Air Main ports G 1/2; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.9 MPa; the selected standard type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 5 µm Drain type semi-automatic drain with manual drainage Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR4000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL4000 lubricator Drain and Service Notes The selected drain is semi-automatic drain with manual drainage. The semi-automatic drain also allows manual drainage. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection G 1/2 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 4000 differs from the reference; gauge option N; filter option W; thread option G. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $61.65

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC4000NW

  Specifications: BFC4000NW is an AirTAC BFC filter-regulator and lubricator combination with PT 1/2 ports, a 5 µm filter and semi-automatic drain with manual drainage, the 0.9 MPa standard regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 4000 1/2-inch nominal port size Blank drain code semi-automatic drain with manual drainage Blank type code Standard type: maximum adjustable pressure 0.9 MPa N No pressure gauge W 5 µm filter element Blank thread code PT connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC4000NW Working medium Air Main ports PT 1/2; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.9 MPa; the selected standard type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 5 µm Drain type semi-automatic drain with manual drainage Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR4000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL4000 lubricator Drain and Service Notes The selected drain is semi-automatic drain with manual drainage. The semi-automatic drain also allows manual drainage. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection PT 1/2 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 4000 differs from the reference; gauge option N; filter option W. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $61.65

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC4000NT

  Specifications: BFC4000NT is an AirTAC BFC filter-regulator and lubricator combination with NPT 1/2 ports, a 40 µm filter and semi-automatic drain with manual drainage, the 0.9 MPa standard regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 4000 1/2-inch nominal port size Blank drain code semi-automatic drain with manual drainage Blank type code Standard type: maximum adjustable pressure 0.9 MPa N No pressure gauge Blank filter code 40 µm filter element T NPT connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC4000NT Working medium Air Main ports NPT 1/2; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.9 MPa; the selected standard type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 40 µm Drain type semi-automatic drain with manual drainage Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR4000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL4000 lubricator Drain and Service Notes The selected drain is semi-automatic drain with manual drainage. The semi-automatic drain also allows manual drainage. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection NPT 1/2 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 4000 differs from the reference; gauge option N; thread option T. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $61.65

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC4000NG

  Specifications: BFC4000NG is an AirTAC BFC filter-regulator and lubricator combination with G 1/2 ports, a 40 µm filter and semi-automatic drain with manual drainage, the 0.9 MPa standard regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 4000 1/2-inch nominal port size Blank drain code semi-automatic drain with manual drainage Blank type code Standard type: maximum adjustable pressure 0.9 MPa N No pressure gauge Blank filter code 40 µm filter element G G connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC4000NG Working medium Air Main ports G 1/2; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.9 MPa; the selected standard type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 40 µm Drain type semi-automatic drain with manual drainage Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR4000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL4000 lubricator Drain and Service Notes The selected drain is semi-automatic drain with manual drainage. The semi-automatic drain also allows manual drainage. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection G 1/2 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 4000 differs from the reference; gauge option N; thread option G. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $61.65

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC4000N

  Specifications: BFC4000N is an AirTAC BFC filter-regulator and lubricator combination with PT 1/2 ports, a 40 µm filter and semi-automatic drain with manual drainage, the 0.9 MPa standard regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 4000 1/2-inch nominal port size Blank drain code semi-automatic drain with manual drainage Blank type code Standard type: maximum adjustable pressure 0.9 MPa N No pressure gauge Blank filter code 40 µm filter element Blank thread code PT connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC4000N Working medium Air Main ports PT 1/2; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.9 MPa; the selected standard type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 40 µm Drain type semi-automatic drain with manual drainage Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR4000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL4000 lubricator Drain and Service Notes The selected drain is semi-automatic drain with manual drainage. The semi-automatic drain also allows manual drainage. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection PT 1/2 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 4000 differs from the reference; gauge option N. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $61.65

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC3000ALNWT

  Specifications: BFC3000ALNWT is an AirTAC BFC filter-regulator and lubricator combination with NPT 3/8 ports, a 5 µm filter and automatic drain, the 0.4 MPa lower-pressure regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 3000 3/8-inch nominal port size A automatic drain L Lower-pressure type: maximum adjustable pressure 0.4 MPa N No pressure gauge W 5 µm filter element T NPT connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC3000ALNWT Working medium Air Main ports NPT 3/8; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.4 MPa; the selected lower-pressure type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 5 µm Drain type automatic drain Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR3000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL3000 lubricator Drain and Service Notes The selected drain is automatic drain. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection NPT 3/8 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 3000 differs from the reference; selected drain A; low-pressure option L; gauge option N; filter option W; thread option T. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $92.06

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC3000ALNWG

  Specifications: BFC3000ALNWG is an AirTAC BFC filter-regulator and lubricator combination with G 3/8 ports, a 5 µm filter and automatic drain, the 0.4 MPa lower-pressure regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 3000 3/8-inch nominal port size A automatic drain L Lower-pressure type: maximum adjustable pressure 0.4 MPa N No pressure gauge W 5 µm filter element G G connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC3000ALNWG Working medium Air Main ports G 3/8; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.4 MPa; the selected lower-pressure type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 5 µm Drain type automatic drain Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR3000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL3000 lubricator Drain and Service Notes The selected drain is automatic drain. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection G 3/8 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 3000 differs from the reference; selected drain A; low-pressure option L; gauge option N; filter option W; thread option G. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $92.06

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC3000ALNW

  Specifications: BFC3000ALNW is an AirTAC BFC filter-regulator and lubricator combination with PT 3/8 ports, a 5 µm filter and automatic drain, the 0.4 MPa lower-pressure regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 3000 3/8-inch nominal port size A automatic drain L Lower-pressure type: maximum adjustable pressure 0.4 MPa N No pressure gauge W 5 µm filter element Blank thread code PT connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC3000ALNW Working medium Air Main ports PT 3/8; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.4 MPa; the selected lower-pressure type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 5 µm Drain type automatic drain Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR3000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL3000 lubricator Drain and Service Notes The selected drain is automatic drain. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection PT 3/8 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 3000 differs from the reference; selected drain A; low-pressure option L; gauge option N; filter option W. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $92.06

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC3000ALNT

  Specifications: BFC3000ALNT is an AirTAC BFC filter-regulator and lubricator combination with NPT 3/8 ports, a 40 µm filter and automatic drain, the 0.4 MPa lower-pressure regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 3000 3/8-inch nominal port size A automatic drain L Lower-pressure type: maximum adjustable pressure 0.4 MPa N No pressure gauge Blank filter code 40 µm filter element T NPT connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC3000ALNT Working medium Air Main ports NPT 3/8; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.4 MPa; the selected lower-pressure type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 40 µm Drain type automatic drain Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR3000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL3000 lubricator Drain and Service Notes The selected drain is automatic drain. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection NPT 3/8 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 3000 differs from the reference; selected drain A; low-pressure option L; gauge option N; thread option T. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $92.06

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC3000ALNG

  Specifications: BFC3000ALNG is an AirTAC BFC filter-regulator and lubricator combination with G 3/8 ports, a 40 µm filter and automatic drain, the 0.4 MPa lower-pressure regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 3000 3/8-inch nominal port size A automatic drain L Lower-pressure type: maximum adjustable pressure 0.4 MPa N No pressure gauge Blank filter code 40 µm filter element G G connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC3000ALNG Working medium Air Main ports G 3/8; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.4 MPa; the selected lower-pressure type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 40 µm Drain type automatic drain Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR3000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL3000 lubricator Drain and Service Notes The selected drain is automatic drain. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection G 3/8 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 3000 differs from the reference; selected drain A; low-pressure option L; gauge option N; thread option G. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $92.06

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC3000ALN

  Specifications: BFC3000ALN is an AirTAC BFC filter-regulator and lubricator combination with PT 3/8 ports, a 40 µm filter and automatic drain, the 0.4 MPa lower-pressure regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 3000 3/8-inch nominal port size A automatic drain L Lower-pressure type: maximum adjustable pressure 0.4 MPa N No pressure gauge Blank filter code 40 µm filter element Blank thread code PT connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC3000ALN Working medium Air Main ports PT 3/8; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.4 MPa; the selected lower-pressure type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 40 µm Drain type automatic drain Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR3000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL3000 lubricator Drain and Service Notes The selected drain is automatic drain. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection PT 3/8 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 3000 differs from the reference; selected drain A; low-pressure option L; gauge option N. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $92.06

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC3000ANWT

  Specifications: BFC3000ANWT is an AirTAC BFC filter-regulator and lubricator combination with NPT 3/8 ports, a 5 µm filter and automatic drain, the 0.9 MPa standard regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 3000 3/8-inch nominal port size A automatic drain Blank type code Standard type: maximum adjustable pressure 0.9 MPa N No pressure gauge W 5 µm filter element T NPT connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC3000ANWT Working medium Air Main ports NPT 3/8; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.9 MPa; the selected standard type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 5 µm Drain type automatic drain Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR3000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL3000 lubricator Drain and Service Notes The selected drain is automatic drain. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection NPT 3/8 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 3000 differs from the reference; selected drain A; gauge option N; filter option W; thread option T. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $74.53

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC3000ANWG

  Specifications: BFC3000ANWG is an AirTAC BFC filter-regulator and lubricator combination with G 3/8 ports, a 5 µm filter and automatic drain, the 0.9 MPa standard regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 3000 3/8-inch nominal port size A automatic drain Blank type code Standard type: maximum adjustable pressure 0.9 MPa N No pressure gauge W 5 µm filter element G G connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC3000ANWG Working medium Air Main ports G 3/8; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.9 MPa; the selected standard type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 5 µm Drain type automatic drain Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR3000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL3000 lubricator Drain and Service Notes The selected drain is automatic drain. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection G 3/8 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 3000 differs from the reference; selected drain A; gauge option N; filter option W; thread option G. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $74.53

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC3000ANW

  Specifications: BFC3000ANW is an AirTAC BFC filter-regulator and lubricator combination with PT 3/8 ports, a 5 µm filter and automatic drain, the 0.9 MPa standard regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 3000 3/8-inch nominal port size A automatic drain Blank type code Standard type: maximum adjustable pressure 0.9 MPa N No pressure gauge W 5 µm filter element Blank thread code PT connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC3000ANW Working medium Air Main ports PT 3/8; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.9 MPa; the selected standard type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 5 µm Drain type automatic drain Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR3000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL3000 lubricator Drain and Service Notes The selected drain is automatic drain. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection PT 3/8 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 3000 differs from the reference; selected drain A; gauge option N; filter option W. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $74.53

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC3000ANT

  Specifications: BFC3000ANT is an AirTAC BFC filter-regulator and lubricator combination with NPT 3/8 ports, a 40 µm filter and automatic drain, the 0.9 MPa standard regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 3000 3/8-inch nominal port size A automatic drain Blank type code Standard type: maximum adjustable pressure 0.9 MPa N No pressure gauge Blank filter code 40 µm filter element T NPT connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC3000ANT Working medium Air Main ports NPT 3/8; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.9 MPa; the selected standard type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 40 µm Drain type automatic drain Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR3000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL3000 lubricator Drain and Service Notes The selected drain is automatic drain. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection NPT 3/8 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 3000 differs from the reference; selected drain A; gauge option N; thread option T. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $74.53

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC3000ANG

  Specifications: BFC3000ANG is an AirTAC BFC filter-regulator and lubricator combination with G 3/8 ports, a 40 µm filter and automatic drain, the 0.9 MPa standard regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 3000 3/8-inch nominal port size A automatic drain Blank type code Standard type: maximum adjustable pressure 0.9 MPa N No pressure gauge Blank filter code 40 µm filter element G G connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC3000ANG Working medium Air Main ports G 3/8; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.9 MPa; the selected standard type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 40 µm Drain type automatic drain Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR3000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL3000 lubricator Drain and Service Notes The selected drain is automatic drain. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection G 3/8 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 3000 differs from the reference; selected drain A; gauge option N; thread option G. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $74.53

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC3000AN

  Specifications: BFC3000AN is an AirTAC BFC filter-regulator and lubricator combination with PT 3/8 ports, a 40 µm filter and automatic drain, the 0.9 MPa standard regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 3000 3/8-inch nominal port size A automatic drain Blank type code Standard type: maximum adjustable pressure 0.9 MPa N No pressure gauge Blank filter code 40 µm filter element Blank thread code PT connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC3000AN Working medium Air Main ports PT 3/8; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.15–0.9 MPa; the selected standard type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 40 µm Drain type automatic drain Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR3000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL3000 lubricator Drain and Service Notes The selected drain is automatic drain. The B Series semi-automatic/automatic drain detail shows a G1/8 outlet and an 11 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection PT 3/8 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 3000 differs from the reference; selected drain A; gauge option N. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $74.53

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC3000MLNWT

  Specifications: BFC3000MLNWT is an AirTAC BFC filter-regulator and lubricator combination with NPT 3/8 ports, a 5 µm filter and manual drain, the 0.4 MPa lower-pressure regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 3000 3/8-inch nominal port size M manual drain L Lower-pressure type: maximum adjustable pressure 0.4 MPa N No pressure gauge W 5 µm filter element T NPT connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC3000MLNWT Working medium Air Main ports NPT 3/8; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.05–0.4 MPa; the selected lower-pressure type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 5 µm Drain type manual drain Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR3000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL3000 lubricator Drain and Service Notes The selected drain is manual drain. The B Series manual-drain drawing identifies a 2.5 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection NPT 3/8 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 3000 differs from the reference; selected drain M; low-pressure option L; gauge option N; filter option W; thread option T. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $61.65

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC3000MLNWG

  Specifications: BFC3000MLNWG is an AirTAC BFC filter-regulator and lubricator combination with G 3/8 ports, a 5 µm filter and manual drain, the 0.4 MPa lower-pressure regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 3000 3/8-inch nominal port size M manual drain L Lower-pressure type: maximum adjustable pressure 0.4 MPa N No pressure gauge W 5 µm filter element G G connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC3000MLNWG Working medium Air Main ports G 3/8; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.05–0.4 MPa; the selected lower-pressure type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 5 µm Drain type manual drain Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR3000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL3000 lubricator Drain and Service Notes The selected drain is manual drain. The B Series manual-drain drawing identifies a 2.5 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection G 3/8 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 3000 differs from the reference; selected drain M; low-pressure option L; gauge option N; filter option W; thread option G. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $61.65

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC3000MLNW

  Specifications: BFC3000MLNW is an AirTAC BFC filter-regulator and lubricator combination with PT 3/8 ports, a 5 µm filter and manual drain, the 0.4 MPa lower-pressure regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 3000 3/8-inch nominal port size M manual drain L Lower-pressure type: maximum adjustable pressure 0.4 MPa N No pressure gauge W 5 µm filter element Blank thread code PT connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC3000MLNW Working medium Air Main ports PT 3/8; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.05–0.4 MPa; the selected lower-pressure type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 5 µm Drain type manual drain Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR3000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL3000 lubricator Drain and Service Notes The selected drain is manual drain. The B Series manual-drain drawing identifies a 2.5 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection PT 3/8 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 3000 differs from the reference; selected drain M; low-pressure option L; gauge option N; filter option W. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $61.65

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC3000MLNT

  Specifications: BFC3000MLNT is an AirTAC BFC filter-regulator and lubricator combination with NPT 3/8 ports, a 40 µm filter and manual drain, the 0.4 MPa lower-pressure regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 3000 3/8-inch nominal port size M manual drain L Lower-pressure type: maximum adjustable pressure 0.4 MPa N No pressure gauge Blank filter code 40 µm filter element T NPT connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC3000MLNT Working medium Air Main ports NPT 3/8; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.05–0.4 MPa; the selected lower-pressure type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 40 µm Drain type manual drain Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR3000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL3000 lubricator Drain and Service Notes The selected drain is manual drain. The B Series manual-drain drawing identifies a 2.5 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection NPT 3/8 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 3000 differs from the reference; selected drain M; low-pressure option L; gauge option N; thread option T. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $61.65

  View options

•

  View options

  Airtac BFC series: filter regulator and lubricator unit - BFC3000MLN

  Specifications: BFC3000MLN is an AirTAC BFC filter-regulator and lubricator combination with PT 3/8 ports, a 40 µm filter and manual drain, the 0.4 MPa lower-pressure regulating option, and no pressure gauge. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Product BFC B Series filter-regulator and lubricator combination 3000 3/8-inch nominal port size M manual drain L Lower-pressure type: maximum adjustable pressure 0.4 MPa N No pressure gauge Blank filter code 40 µm filter element Blank thread code PT connection thread Product Features The compact construction is designed for pneumatic air preparation. The pressure adjustment mechanism has a push-in self-locking feature to prevent accidental changes to the setting. The filter separates condensed water and solid particles with low pressure loss and efficient water separation. The lubricator has a transparent oil-drop viewing dome, allowing the oil supply to be observed during adjustment. Technical Specifications Parameter Details Current model BFC3000MLN Working medium Air Main ports PT 3/8; inlet and outlet as indicated by the flow direction Proof pressure 1.5 MPa (215 psi) Adjustable pressure range 0.05–0.4 MPa; the selected lower-pressure type is determined by the ordering code Maximum inlet pressure 1.0 MPa (145 psi) Temperature range −5 to 70 °C, non-freezing Filtration 40 µm Drain type manual drain Drain bowl capacity 60 cc Oil bowl capacity 90 cc Recommended lubricant ISO VG 32 or equivalent Pressure gauge Not included Gauge connection 1/4-inch catalog gauge port Catalog reference weight 700 g for the standard family model in this linked catalog. This is a catalog reference, not a measured weight of this individual option combination or a shipping weight. Series Ordering Options The code table above identifies the selected configuration. These are the other choices published for this same family; they are not additional items included with this product. Parameter Details Port-size choices in this family 2000: 1/4; 3000: 3/8; 4000: 1/2 Thread choices Blank: PT; G: G; T: NPT Drain choices Blank: semi-automatic; M: manual; A: automatic Filter choices Blank: 40 µm; W: 5 µm Regulating choices Blank: 0.9 MPa standard; L: 0.4 MPa lower-pressure Gauge choices Blank gauge option supplies a gauge; N omits the gauge. Scale codes are 1: MPa, 2: psi, 3: bar, 4: kgf/cm² and psi. PT uses scale 1 or 4, G uses scale 3, and NPT uses scale 2. Assembly and Catalog Callouts This is a complete air-preparation combination. Its filter/regulator and lubricator functions are included; the following numbered items identify the assembly drawing, not a separately priced repair kit or a declaration of spare-part quantities. Drawing Reference Component Drawing item 1 BFR3000 filter-regulator Drawing item 2 B Series bracket Drawing item 3 B Series gasket Drawing item 4 B Series fixing kit Drawing item 5 Screw Drawing item 6 BL3000 lubricator Drain and Service Notes The selected drain is manual drain. The B Series manual-drain drawing identifies a 2.5 mm local projection. Performance Curves Parameter Details Flow-characteristic plot The BFC family plot uses flow in L/min on the horizontal axis and outlet pressure in MPa on the vertical axis. The shown flow axis spans 0–1600 L/min and the outlet-pressure axis 0–0.6 MPa. How to use the curves Select a curve for the required operating condition and read it in the PDF. An axis endpoint is not a rated flow or a guarantee at every pressure. Flow-plot inlet pressure 0.7 MPa, as stated beside the linked catalog plot Pressure-regulation plot Inlet-pressure axis: 0–0.9 MPa. Outlet-pressure axis: 0.18–0.22 MPa. The illustrated setpoint is around 0.20 MPa; this is a test curve, not the entire adjustable range. Dimensions and Mounting Dimensions are in millimeters unless stated otherwise. The catalog shows the standard family outline and separate drain details. Local callouts remain grouped by the original view; do not add them to create an unpublished overall size. Options can change the gauge, bracket or drain outline. Parameter Details Main connection PT 3/8 at both flow ports Front overall span 154 mm Front local callouts 15; 23; 11; 31; 37 mm Overall height in illustrated configuration 201.5 mm Front vertical callouts 176; 139 mm Side width / depth 40 / 63 mm Bowl diameter Ø64 mm Gauge outside diameter Ø52 mm Gauge shown in dimension drawing Gauge dimensions are reference only; this N version is supplied without a gauge. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Weight Reference and Catalog Edition Approximate reference weight: 789 g. The 2022 comprehensive catalog, printed page 300, lists BFC2000 at this value. This same-family / same-size reference is used for the current listing; it is not a published weight for the complete current option code. Differences not individually mass-adjusted: the current port-size code 3000 differs from the reference; selected drain M; low-pressure option L; gauge option N. This is a reference estimate, not an individual measurement or packaged shipping weight. The linked family catalog separately gives 700 g as its general family reference. The two source values have different published scopes; the selected weight-field reference follows the 2022 table.

  Read more less

  $61.65

  View options
