ACE Series Compact Cylinder

Show previous products

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE50X40SBCAT

  Specifications: ACE50X40SBCAT is an AirTAC double-acting cylinder with a 50 mm bore, 40 mm stroke, a magnetic piston, and male-threaded rod end. The CA suffix selects single rear clevis. Product Catalog Download Airtac Product Catalog (PDF) Download AirTAC 2022 Sensor and Mounting Compatibility Guide (PDF) Download 2022 mounting brackets (PDF) Download 2022 rod-end joints and sensor mounts (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 50 50 mm bore X40 40 mm nominal stroke S after stroke Magnetic piston selected B male-threaded rod end CA single rear clevis T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 53.5 mm AB 8 mm AC 45.5 mm AD 14.5 mm B 65.5 mm D 16 mm E M10 × 1.5 EA 20 mm H 13 mm J 11 mm JA 4.5 mm JB 46.5 mm K M8 × 1.25 KA 30.5 mm P G1/8 PA 7.5 mm PB 3 mm R 10.5 mm RA 4.5 mm T 12 mm TA 2.6 mm Male rod AB 30 mm Male rod D 16 mm Male rod E M12 × 1.25 Male rod EA 20 mm Male rod EB 22 mm Male rod F 17 mm Male rod FA 7 mm Male rod H 13 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 40 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. A, AB and the body outline are the catalog reference drawing values. The selected male rod uses the separate male-rod dimensions; do not substitute the female rod projection AB for it. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Plastic magnet 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE50LB (LB) foot bracket for ACE 50 mm bore F-SI50FA (FA) front flange for ACE 50 mm bore F-SI50FA (FB) rear flange for ACE 50 mm bore F-SE50CA (CA) single rear clevis for ACE 50 mm bore F-SE50CB (CB) double rear clevis for ACE 50 mm bore; catalog states the matching pin is included F-SI50CR (CR) rear hinge bracket for ACE 50 mm bore; must be paired with F-SE50CB double clevis F-SI50FTC (FTC) trunnion mounting for ACE 50 mm bore; requires F-SI40TCM2 support F-SI40TCM2 (TCM2) trunnion support for ACE 50 mm bore; pair with F-SI50FTC; mounting position is not freely adjustable F-M12X125I I-type rod joint; matches the selected male rod thread only F-M12X125Y Y clevis; matches the selected male rod thread only F-M12X125F floating joint; matches the selected male rod thread only F-M12X125U spherical rod-end joint; matches the selected male rod thread only CMSE / DMSE E-profile magnetic switches for this magnetic cylinder; order separately and select the electrical variant for the control system Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected CA Mounting Dimensions Parameter Details A 27 mm B 39 mm C 12 mm E 46.5 mm F 31.7 mm G 64 mm N 53.5 mm Letters in this table belong to the CA accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 50 mm Effective flow area at the reference speed 5.1 mm² Tube outside / inside diameter 10 / 6.5 mm Example speed controller PTL02 Example silencer BSL02 Example solenoid valves 5V21008 / 5V22008 Example air-piloted valves 4A21008 / 4A22008 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 725 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $96.97

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE40X20SBT

  Specifications: ACE40X20SBT is an AirTAC double-acting cylinder with a 40 mm bore, 20 mm stroke, a magnetic piston, and male-threaded rod end. Product Catalog Download Airtac Product Catalog (PDF) Download AirTAC 2022 Sensor and Mounting Compatibility Guide (PDF) Download 2022 mounting brackets (PDF) Download 2022 rod-end joints and sensor mounts (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 40 40 mm bore X20 20 mm nominal stroke S after stroke Magnetic piston selected B male-threaded rod end Blank mounting suffix No optional mounting bracket selected T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 52.5 mm AB 7 mm AC 45.5 mm AD 14.5 mm B 55 mm D 12 mm E M8 × 1.25 EA 16 mm H 10 mm J 9 mm JA 4.5 mm JB 38 mm K M6 × 1.0 KA 28.5 mm P G1/8 PA 7.5 mm PB 3 mm R 8.5 mm RA 3.5 mm T 9 mm TA 2.1 mm Male rod AB 26 mm Male rod D 12 mm Male rod E M10 × 1.25 Male rod EA 17 mm Male rod EB 19 mm Male rod F 17 mm Male rod FA 6 mm Male rod H 10 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 20 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. A, AB and the body outline are the catalog reference drawing values. The selected male rod uses the separate male-rod dimensions; do not substitute the female rod projection AB for it. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Plastic magnet 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE40LB (LB) foot bracket for ACE 40 mm bore F-SI40FA (FA) front flange for ACE 40 mm bore F-SI40FA (FB) rear flange for ACE 40 mm bore F-SE40CA (CA) single rear clevis for ACE 40 mm bore F-SE40CB (CB) double rear clevis for ACE 40 mm bore; catalog states the matching pin is included F-SI40CR (CR) rear hinge bracket for ACE 40 mm bore; must be paired with F-SE40CB double clevis F-SI40FTC (FTC) trunnion mounting for ACE 40 mm bore; requires F-SI40TCM2 support F-SI40TCM2 (TCM2) trunnion support for ACE 40 mm bore; pair with F-SI40FTC; mounting position is not freely adjustable F-M10X125I I-type rod joint; matches the selected male rod thread only F-M10X125Y Y clevis; matches the selected male rod thread only F-M10X125F floating joint; matches the selected male rod thread only F-M10X125U spherical rod-end joint; matches the selected male rod thread only CMSE / DMSE E-profile magnetic switches for this magnetic cylinder; order separately and select the electrical variant for the control system Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 40 mm Effective flow area at the reference speed 3.3 mm² Tube outside / inside diameter 8 / 5 mm Example speed controller PTL01 Example silencer BSL01 Example solenoid valves 5V11006 / 5V12006 Example air-piloted valves 4A11006 / 4A12006 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 423.3 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $62.75

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE125X35SBCBT

  Specifications: ACE125X35SBCBT is an AirTAC double-acting cylinder with a 125 mm bore, 35 mm stroke, a magnetic piston, and male-threaded rod end. The CB suffix selects double rear clevis. Product Catalog Download Airtac Product Catalog (PDF) Download AirTAC 2022 Sensor and Mounting Compatibility Guide (PDF) Download 2022 mounting brackets (PDF) Download 2022 rod-end joints and sensor mounts (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 125 125 mm bore X35 35 mm nominal stroke S after stroke Magnetic piston selected B male-threaded rod end CB double rear clevis T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/4 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 92 mm AB 11 mm AC 81 mm AD 20 mm B 134.5 mm D 25 mm E M16 × 2.0 EA 25 mm H 21 mm J Not listed for this size JA Not listed for this size JB 110 mm K M12 × 1.75 KA Not listed for this size P G1/4 PA 10.5 mm PB 8 mm R 16.5 mm RA 7 mm T 12 mm TA 2.6 mm Male rod AB 51 mm Male rod D 25 mm Male rod E M20 × 1.5 Male rod EA 38 mm Male rod EB 40 mm Male rod F 26 mm Male rod FA 10 mm Male rod H 21 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 35 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/4 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. A, AB and the body outline are the catalog reference drawing values. The selected male rod uses the separate male-rod dimensions; do not substitute the female rod projection AB for it. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Plastic magnet 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-SI125FA (FA) front flange for ACE 125 mm bore F-SI125FA (FB) rear flange for ACE 125 mm bore F-SE125CA (CA) single rear clevis for ACE 125 mm bore F-SE125CB (CB) double rear clevis for ACE 125 mm bore; catalog states the matching pin is included F-SI125CR (CR) rear hinge bracket for ACE 125 mm bore; must be paired with F-SE125CB double clevis F-SI125FTC (FTC) trunnion mounting for ACE 125 mm bore; requires F-SI125TCM2 support F-SI125TCM2 (TCM2) trunnion support for ACE 125 mm bore; pair with F-SI125FTC; mounting position is not freely adjustable F-M20X150I I-type rod joint; matches the selected male rod thread only F-M20X150Y Y clevis; matches the selected male rod thread only F-M20X150F floating joint; matches the selected male rod thread only F-M20X150U spherical rod-end joint; matches the selected male rod thread only CMSE / DMSE E-profile magnetic switches for this magnetic cylinder; order separately and select the electrical variant for the control system Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected CB Mounting Dimensions Parameter Details A 50 mm B 74 mm C 25 mm D 70 mm E 110 mm F 130 mm G 134 mm H 139 mm N 92 mm Letters in this table belong to the CB accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250, 275, 300 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Weight Reference Estimated reference weight: 4038 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $362.58

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE63X20BT

  Specifications: ACE63X20BT is an AirTAC double-acting cylinder with a 63 mm bore, 20 mm stroke, no magnetic option in the standard suffix position, and male-threaded rod end. Product Catalog Download Airtac Product Catalog (PDF) Download 2022 mounting brackets (PDF) Download 2022 rod-end joints and sensor mounts (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 63 63 mm bore X20 20 mm nominal stroke Blank magnetic position No magnetic piston selected by the standard order-code position B male-threaded rod end Blank mounting suffix No optional mounting bracket selected T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 57 mm AB 8 mm AC 49 mm AD 15 mm B 75.5 mm D 16 mm E M10 × 1.5 EA 20 mm H 13 mm J 11 mm JA 4.5 mm JB 56.5 mm K M8 × 1.25 KA 30.5 mm P G1/8 PA 7.5 mm PB 4 mm R 10.5 mm RA 4.5 mm T 12 mm TA 2.6 mm Male rod AB 30 mm Male rod D 16 mm Male rod E M12 × 1.25 Male rod EA 20 mm Male rod EB 22 mm Male rod F 17 mm Male rod FA 7 mm Male rod H 13 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 20 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. A, AB and the body outline are the catalog reference drawing values. The selected male rod uses the separate male-rod dimensions; do not substitute the female rod projection AB for it. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Magnetic-option component; not fitted in a non-magnetic configuration 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE63LB (LB) foot bracket for ACE 63 mm bore F-SI63FA (FA) front flange for ACE 63 mm bore F-SI63FA (FB) rear flange for ACE 63 mm bore F-SE63CA (CA) single rear clevis for ACE 63 mm bore F-SE63CB (CB) double rear clevis for ACE 63 mm bore; catalog states the matching pin is included F-SI63CR (CR) rear hinge bracket for ACE 63 mm bore; must be paired with F-SE63CB double clevis F-SI63FTC (FTC) trunnion mounting for ACE 63 mm bore; requires F-SI63TCM2 support F-SI63TCM2 (TCM2) trunnion support for ACE 63 mm bore; pair with F-SI63FTC; mounting position is not freely adjustable F-M12X125I I-type rod joint; matches the selected male rod thread only F-M12X125Y Y clevis; matches the selected male rod thread only F-M12X125F floating joint; matches the selected male rod thread only F-M12X125U spherical rod-end joint; matches the selected male rod thread only Magnetic switch condition This code does not select a magnetic piston. A magnetic switch cannot provide piston-position sensing on a non-magnetic cylinder. Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 63 mm Effective flow area at the reference speed 8.1 mm² Tube outside / inside diameter 10 / 6.5 mm Example speed controller PTL02 Example silencer BSL02 Example solenoid valves 5V21008 / 5V22008 Example air-piloted valves 4A21008 / 4A22008 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 872 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $99.16

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE100X20BFTCT

  Specifications: ACE100X20BFTCT is an AirTAC double-acting cylinder with a 100 mm bore, 20 mm stroke, no magnetic option in the standard suffix position, and male-threaded rod end. The FTC suffix selects trunnion mounting. Product Catalog Download Airtac Product Catalog (PDF) Download 2022 mounting brackets (PDF) Download 2022 rod-end joints and sensor mounts (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 100 100 mm bore X20 20 mm nominal stroke Blank magnetic position No magnetic piston selected by the standard order-code position B male-threaded rod end FTC trunnion mounting T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 76 mm AB 9 mm AC 67 mm AD 19 mm B 113.5 mm D 20 mm E M12 × 1.75 EA 20 mm H 17 mm J 15 mm JA 2.5 mm JB 89 mm K M10 × 1.5 KA Not listed for this size P G1/8 PA 10.5 mm PB 7 mm R 12.5 mm RA 6 mm T 12 mm TA 2.6 mm Male rod AB 37 mm Male rod D 20 mm Male rod E M16 × 1.5 Male rod EA 26 mm Male rod EB 28 mm Male rod F 23 mm Male rod FA 8 mm Male rod H 17 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 20 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. A, AB and the body outline are the catalog reference drawing values. The selected male rod uses the separate male-rod dimensions; do not substitute the female rod projection AB for it. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Magnetic-option component; not fitted in a non-magnetic configuration 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE100LB (LB) foot bracket for ACE 100 mm bore F-SI100FA (FA) front flange for ACE 100 mm bore F-SI100FA (FB) rear flange for ACE 100 mm bore F-SE100CA (CA) single rear clevis for ACE 100 mm bore F-SE100CB (CB) double rear clevis for ACE 100 mm bore; catalog states the matching pin is included F-SI100CR (CR) rear hinge bracket for ACE 100 mm bore; must be paired with F-SE100CB double clevis F-SI100FTC (FTC) trunnion mounting for ACE 100 mm bore; requires F-SI125TCM2 support F-SI125TCM2 (TCM2) trunnion support for ACE 100 mm bore; pair with F-SI100FTC; mounting position is not freely adjustable F-M16X150I I-type rod joint; matches the selected male rod thread only F-M16X150Y Y clevis; matches the selected male rod thread only F-M16X150F floating joint; matches the selected male rod thread only F-M16X150U spherical rod-end joint; matches the selected male rod thread only Magnetic switch condition This code does not select a magnetic piston. A magnetic switch cannot provide piston-position sensing on a non-magnetic cylinder. Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected FTC Mounting Dimensions Parameter Details A 102 mm AA 185 mm B 132 mm C 67 mm CA 25 mm D 89 mm E 114 mm F 35 mm K 16 mm Letters in this table belong to the FTC accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250, 275, 300 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 100 mm Effective flow area at the reference speed 20.4 mm² Tube outside / inside diameter 16 / 11 mm Example speed controller PTL03 Example silencer BSL03 Example solenoid valves 5V31010 / 5V32010 Example air-piloted valves 4A31010 / 4A32010 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 2100 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $231.61

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE63X120SBT

  Specifications: ACE63X120SBT is an AirTAC double-acting cylinder with a 63 mm bore, 120 mm stroke, a magnetic piston, and male-threaded rod end. Product Catalog Download Airtac Product Catalog (PDF) Download AirTAC 2022 Sensor and Mounting Compatibility Guide (PDF) Download 2022 mounting brackets (PDF) Download 2022 rod-end joints and sensor mounts (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 63 63 mm bore X120 120 mm nominal stroke S after stroke Magnetic piston selected B male-threaded rod end Blank mounting suffix No optional mounting bracket selected T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 57 mm AB 8 mm AC 49 mm AD 15 mm B 75.5 mm D 16 mm E M10 × 1.5 EA 20 mm H 13 mm J 11 mm JA 4.5 mm JB 56.5 mm K M8 × 1.25 KA 30.5 mm P G1/8 PA 7.5 mm PB 4 mm R 10.5 mm RA 4.5 mm T 12 mm TA 2.6 mm Male rod AB 30 mm Male rod D 16 mm Male rod E M12 × 1.25 Male rod EA 20 mm Male rod EB 22 mm Male rod F 17 mm Male rod FA 7 mm Male rod H 13 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 120 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. A, AB and the body outline are the catalog reference drawing values. The selected male rod uses the separate male-rod dimensions; do not substitute the female rod projection AB for it. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Plastic magnet 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE63LB (LB) foot bracket for ACE 63 mm bore F-SI63FA (FA) front flange for ACE 63 mm bore F-SI63FA (FB) rear flange for ACE 63 mm bore F-SE63CA (CA) single rear clevis for ACE 63 mm bore F-SE63CB (CB) double rear clevis for ACE 63 mm bore; catalog states the matching pin is included F-SI63CR (CR) rear hinge bracket for ACE 63 mm bore; must be paired with F-SE63CB double clevis F-SI63FTC (FTC) trunnion mounting for ACE 63 mm bore; requires F-SI63TCM2 support F-SI63TCM2 (TCM2) trunnion support for ACE 63 mm bore; pair with F-SI63FTC; mounting position is not freely adjustable F-M12X125I I-type rod joint; matches the selected male rod thread only F-M12X125Y Y clevis; matches the selected male rod thread only F-M12X125F floating joint; matches the selected male rod thread only F-M12X125U spherical rod-end joint; matches the selected male rod thread only CMSE / DMSE E-profile magnetic switches for this magnetic cylinder; order separately and select the electrical variant for the control system Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 63 mm Effective flow area at the reference speed 8.1 mm² Tube outside / inside diameter 10 / 6.5 mm Example speed controller PTL02 Example silencer BSL02 Example solenoid valves 5V21008 / 5V22008 Example air-piloted valves 4A21008 / 4A22008 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 1551.5 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $149.82

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE80X35BT

  Specifications: ACE80X35BT is an AirTAC double-acting cylinder with a 80 mm bore, 35 mm stroke, no magnetic option in the standard suffix position, and male-threaded rod end. Product Catalog Download Airtac Product Catalog (PDF) Download 2022 mounting brackets (PDF) Download 2022 rod-end joints and sensor mounts (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 80 80 mm bore X35 35 mm nominal stroke Blank magnetic position No magnetic piston selected by the standard order-code position B male-threaded rod end Blank mounting suffix No optional mounting bracket selected T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 63 mm AB 9 mm AC 54 mm AD 16 mm B 95.5 mm D 20 mm E M12 × 1.75 EA 20 mm H 17 mm J 15 mm JA 2.5 mm JB 72 mm K M10 × 1.5 KA Not listed for this size P G1/8 PA 8.5 mm PB 6 mm R 12.5 mm RA 6 mm T 12 mm TA 2.6 mm Male rod AB 37 mm Male rod D 20 mm Male rod E M16 × 1.5 Male rod EA 26 mm Male rod EB 28 mm Male rod F 23 mm Male rod FA 8 mm Male rod H 17 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 35 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. A, AB and the body outline are the catalog reference drawing values. The selected male rod uses the separate male-rod dimensions; do not substitute the female rod projection AB for it. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Magnetic-option component; not fitted in a non-magnetic configuration 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE80LB (LB) foot bracket for ACE 80 mm bore F-SI80FA (FA) front flange for ACE 80 mm bore F-SI80FA (FB) rear flange for ACE 80 mm bore F-SE80CA (CA) single rear clevis for ACE 80 mm bore F-SE80CB (CB) double rear clevis for ACE 80 mm bore; catalog states the matching pin is included F-SI80CR (CR) rear hinge bracket for ACE 80 mm bore; must be paired with F-SE80CB double clevis F-SI80FTC (FTC) trunnion mounting for ACE 80 mm bore; requires F-SI63TCM2 support F-SI63TCM2 (TCM2) trunnion support for ACE 80 mm bore; pair with F-SI80FTC; mounting position is not freely adjustable F-M16X150I I-type rod joint; matches the selected male rod thread only F-M16X150Y Y clevis; matches the selected male rod thread only F-M16X150F floating joint; matches the selected male rod thread only F-M16X150U spherical rod-end joint; matches the selected male rod thread only Magnetic switch condition This code does not select a magnetic piston. A magnetic switch cannot provide piston-position sensing on a non-magnetic cylinder. Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250, 275, 300 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 80 mm Effective flow area at the reference speed 13.1 mm² Tube outside / inside diameter 16 / 11 mm Example speed controller PTL03 Example silencer BSL03 Example solenoid valves 5V31010 / 5V32010 Example air-piloted valves 4A31010 / 4A32010 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 1415.5 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $159.08

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE80X15FAT

  Specifications: ACE80X15FAT is an AirTAC double-acting cylinder with a 80 mm bore, 15 mm stroke, no magnetic option in the standard suffix position, and female-threaded rod end. The FA suffix selects front flange. Product Catalog Download Airtac Product Catalog (PDF) Download 2022 mounting brackets (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 80 80 mm bore X15 15 mm nominal stroke Blank magnetic position No magnetic piston selected by the standard order-code position Blank rod-end position female-threaded rod end FA front flange T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 63 mm AB 9 mm AC 54 mm AD 16 mm B 95.5 mm D 20 mm E M12 × 1.75 EA 20 mm H 17 mm J 15 mm JA 2.5 mm JB 72 mm K M10 × 1.5 KA Not listed for this size P G1/8 PA 8.5 mm PB 6 mm R 12.5 mm RA 6 mm T 12 mm TA 2.6 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 15 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Magnetic-option component; not fitted in a non-magnetic configuration 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE80LB (LB) foot bracket for ACE 80 mm bore F-SI80FA (FA) front flange for ACE 80 mm bore F-SI80FA (FB) rear flange for ACE 80 mm bore F-SE80CA (CA) single rear clevis for ACE 80 mm bore F-SE80CB (CB) double rear clevis for ACE 80 mm bore; catalog states the matching pin is included F-SI80CR (CR) rear hinge bracket for ACE 80 mm bore; must be paired with F-SE80CB double clevis F-SI80FTC (FTC) trunnion mounting for ACE 80 mm bore; requires F-SI63TCM2 support F-SI63TCM2 (TCM2) trunnion support for ACE 80 mm bore; pair with F-SI80FTC; mounting position is not freely adjustable Magnetic switch condition This code does not select a magnetic piston. A magnetic switch cannot provide piston-position sensing on a non-magnetic cylinder. Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected FA Mounting Dimensions Parameter Details A 16 mm B 63 mm C 95 mm D 12.5 mm E 72 mm F 126 mm G 150 mm H 45.5 mm N 63 mm Letters in this table belong to the FA accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250, 275, 300 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 80 mm Effective flow area at the reference speed 13.1 mm² Tube outside / inside diameter 16 / 11 mm Example speed controller PTL03 Example silencer BSL03 Example solenoid valves 5V31010 / 5V32010 Example air-piloted valves 4A31010 / 4A32010 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 1176.5 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $151.69

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE40X125SLBT

  Specifications: ACE40X125SLBT is an AirTAC double-acting cylinder with a 40 mm bore, 125 mm stroke, a magnetic piston, and female-threaded rod end. The LB suffix selects foot bracket. Product Catalog Download Airtac Product Catalog (PDF) Download AirTAC 2022 Sensor and Mounting Compatibility Guide (PDF) Download 2022 mounting brackets (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 40 40 mm bore X125 125 mm nominal stroke S after stroke Magnetic piston selected Blank rod-end position female-threaded rod end LB foot bracket T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 52.5 mm AB 7 mm AC 45.5 mm AD 14.5 mm B 55 mm D 12 mm E M8 × 1.25 EA 16 mm H 10 mm J 9 mm JA 4.5 mm JB 38 mm K M6 × 1.0 KA 28.5 mm P G1/8 PA 7.5 mm PB 3 mm R 8.5 mm RA 3.5 mm T 9 mm TA 2.1 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 125 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Plastic magnet 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE40LB (LB) foot bracket for ACE 40 mm bore F-SI40FA (FA) front flange for ACE 40 mm bore F-SI40FA (FB) rear flange for ACE 40 mm bore F-SE40CA (CA) single rear clevis for ACE 40 mm bore F-SE40CB (CB) double rear clevis for ACE 40 mm bore; catalog states the matching pin is included F-SI40CR (CR) rear hinge bracket for ACE 40 mm bore; must be paired with F-SE40CB double clevis F-SI40FTC (FTC) trunnion mounting for ACE 40 mm bore; requires F-SI40TCM2 support F-SI40TCM2 (TCM2) trunnion support for ACE 40 mm bore; pair with F-SI40FTC; mounting position is not freely adjustable CMSE / DMSE E-profile magnetic switches for this magnetic cylinder; order separately and select the electrical variant for the control system Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected LB Mounting Dimensions Parameter Details A 38 mm B 4 mm C 45.5 mm D 81.5 mm E 97.5 mm F 10 mm G 36 mm H 54 mm Letters in this table belong to the LB accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 40 mm Effective flow area at the reference speed 3.3 mm² Tube outside / inside diameter 8 / 5 mm Example speed controller PTL01 Example silencer BSL01 Example solenoid valves 5V11006 / 5V12006 Example air-piloted valves 4A11006 / 4A12006 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 817.9 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $107.02

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE40X150SFBT

  Specifications: ACE40X150SFBT is an AirTAC double-acting cylinder with a 40 mm bore, 150 mm stroke, a magnetic piston, and female-threaded rod end. The FB suffix selects rear flange. Product Catalog Download Airtac Product Catalog (PDF) Download AirTAC 2022 Sensor and Mounting Compatibility Guide (PDF) Download 2022 mounting brackets (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 40 40 mm bore X150 150 mm nominal stroke S after stroke Magnetic piston selected Blank rod-end position female-threaded rod end FB rear flange T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 52.5 mm AB 7 mm AC 45.5 mm AD 14.5 mm B 55 mm D 12 mm E M8 × 1.25 EA 16 mm H 10 mm J 9 mm JA 4.5 mm JB 38 mm K M6 × 1.0 KA 28.5 mm P G1/8 PA 7.5 mm PB 3 mm R 8.5 mm RA 3.5 mm T 9 mm TA 2.1 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 150 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Plastic magnet 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE40LB (LB) foot bracket for ACE 40 mm bore F-SI40FA (FA) front flange for ACE 40 mm bore F-SI40FA (FB) rear flange for ACE 40 mm bore F-SE40CA (CA) single rear clevis for ACE 40 mm bore F-SE40CB (CB) double rear clevis for ACE 40 mm bore; catalog states the matching pin is included F-SI40CR (CR) rear hinge bracket for ACE 40 mm bore; must be paired with F-SE40CB double clevis F-SI40FTC (FTC) trunnion mounting for ACE 40 mm bore; requires F-SI40TCM2 support F-SI40TCM2 (TCM2) trunnion support for ACE 40 mm bore; pair with F-SI40FTC; mounting position is not freely adjustable CMSE / DMSE E-profile magnetic switches for this magnetic cylinder; order separately and select the electrical variant for the control system Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected FB Mounting Dimensions Parameter Details A 10 mm B 36 mm C 53 mm D 9 mm E 38 mm F 72 mm G 90 mm H 35.5 mm N 52.5 mm Letters in this table belong to the FB accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 40 mm Effective flow area at the reference speed 3.3 mm² Tube outside / inside diameter 8 / 5 mm Example speed controller PTL01 Example silencer BSL01 Example solenoid valves 5V11006 / 5V12006 Example air-piloted valves 4A11006 / 4A12006 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 915.9 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $108.42

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE63X55SFTCT

  Specifications: ACE63X55SFTCT is an AirTAC double-acting cylinder with a 63 mm bore, 55 mm stroke, a magnetic piston, and female-threaded rod end. The FTC suffix selects trunnion mounting. Product Catalog Download Airtac Product Catalog (PDF) Download AirTAC 2022 Sensor and Mounting Compatibility Guide (PDF) Download 2022 mounting brackets (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 63 63 mm bore X55 55 mm nominal stroke S after stroke Magnetic piston selected Blank rod-end position female-threaded rod end FTC trunnion mounting T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 57 mm AB 8 mm AC 49 mm AD 15 mm B 75.5 mm D 16 mm E M10 × 1.5 EA 20 mm H 13 mm J 11 mm JA 4.5 mm JB 56.5 mm K M8 × 1.25 KA 30.5 mm P G1/8 PA 7.5 mm PB 4 mm R 10.5 mm RA 4.5 mm T 12 mm TA 2.6 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 55 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Plastic magnet 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE63LB (LB) foot bracket for ACE 63 mm bore F-SI63FA (FA) front flange for ACE 63 mm bore F-SI63FA (FB) rear flange for ACE 63 mm bore F-SE63CA (CA) single rear clevis for ACE 63 mm bore F-SE63CB (CB) double rear clevis for ACE 63 mm bore; catalog states the matching pin is included F-SI63CR (CR) rear hinge bracket for ACE 63 mm bore; must be paired with F-SE63CB double clevis F-SI63FTC (FTC) trunnion mounting for ACE 63 mm bore; requires F-SI63TCM2 support F-SI63TCM2 (TCM2) trunnion support for ACE 63 mm bore; pair with F-SI63FTC; mounting position is not freely adjustable CMSE / DMSE E-profile magnetic switches for this magnetic cylinder; order separately and select the electrical variant for the control system Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected FTC Mounting Dimensions Parameter Details A 77 mm AA 130 mm B 90 mm C 49 mm CA 20 mm D 56.5 mm E 74 mm F 28 mm K 12 mm Letters in this table belong to the FTC accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 63 mm Effective flow area at the reference speed 8.1 mm² Tube outside / inside diameter 10 / 6.5 mm Example speed controller PTL02 Example silencer BSL02 Example solenoid valves 5V21008 / 5V22008 Example air-piloted valves 4A21008 / 4A22008 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 1086.75 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $162.10

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE80X160SBFAT

  Specifications: ACE80X160SBFAT is an AirTAC double-acting cylinder with a 80 mm bore, 160 mm stroke, a magnetic piston, and male-threaded rod end. The FA suffix selects front flange. Product Catalog Download Airtac Product Catalog (PDF) Download AirTAC 2022 Sensor and Mounting Compatibility Guide (PDF) Download 2022 mounting brackets (PDF) Download 2022 rod-end joints and sensor mounts (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 80 80 mm bore X160 160 mm nominal stroke S after stroke Magnetic piston selected B male-threaded rod end FA front flange T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 63 mm AB 9 mm AC 54 mm AD 16 mm B 95.5 mm D 20 mm E M12 × 1.75 EA 20 mm H 17 mm J 15 mm JA 2.5 mm JB 72 mm K M10 × 1.5 KA Not listed for this size P G1/8 PA 8.5 mm PB 6 mm R 12.5 mm RA 6 mm T 12 mm TA 2.6 mm Male rod AB 37 mm Male rod D 20 mm Male rod E M16 × 1.5 Male rod EA 26 mm Male rod EB 28 mm Male rod F 23 mm Male rod FA 8 mm Male rod H 17 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 160 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. A, AB and the body outline are the catalog reference drawing values. The selected male rod uses the separate male-rod dimensions; do not substitute the female rod projection AB for it. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Plastic magnet 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE80LB (LB) foot bracket for ACE 80 mm bore F-SI80FA (FA) front flange for ACE 80 mm bore F-SI80FA (FB) rear flange for ACE 80 mm bore F-SE80CA (CA) single rear clevis for ACE 80 mm bore F-SE80CB (CB) double rear clevis for ACE 80 mm bore; catalog states the matching pin is included F-SI80CR (CR) rear hinge bracket for ACE 80 mm bore; must be paired with F-SE80CB double clevis F-SI80FTC (FTC) trunnion mounting for ACE 80 mm bore; requires F-SI63TCM2 support F-SI63TCM2 (TCM2) trunnion support for ACE 80 mm bore; pair with F-SI80FTC; mounting position is not freely adjustable F-M16X150I I-type rod joint; matches the selected male rod thread only F-M16X150Y Y clevis; matches the selected male rod thread only F-M16X150F floating joint; matches the selected male rod thread only F-M16X150U spherical rod-end joint; matches the selected male rod thread only CMSE / DMSE E-profile magnetic switches for this magnetic cylinder; order separately and select the electrical variant for the control system Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected FA Mounting Dimensions Parameter Details A 16 mm B 63 mm C 95 mm D 12.5 mm E 72 mm F 126 mm G 150 mm H 45.5 mm N 63 mm Letters in this table belong to the FA accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250, 275, 300 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 80 mm Effective flow area at the reference speed 13.1 mm² Tube outside / inside diameter 16 / 11 mm Example speed controller PTL03 Example silencer BSL03 Example solenoid valves 5V31010 / 5V32010 Example air-piloted valves 4A31010 / 4A32010 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 2575 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $250.00

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE125X5FAT

  Specifications: ACE125X5FAT is an AirTAC double-acting cylinder with a 125 mm bore, 5 mm stroke, no magnetic option in the standard suffix position, and female-threaded rod end. The FA suffix selects front flange. Product Catalog Download Airtac Product Catalog (PDF) Download 2022 mounting brackets (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 125 125 mm bore X5 5 mm nominal stroke Blank magnetic position No magnetic piston selected by the standard order-code position Blank rod-end position female-threaded rod end FA front flange T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/4 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 92 mm AB 11 mm AC 81 mm AD 20 mm B 134.5 mm D 25 mm E M16 × 2.0 EA 25 mm H 21 mm J Not listed for this size JA Not listed for this size JB 110 mm K M12 × 1.75 KA Not listed for this size P G1/4 PA 10.5 mm PB 8 mm R 16.5 mm RA 7 mm T 12 mm TA 2.6 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 5 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/4 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Magnetic-option component; not fitted in a non-magnetic configuration 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-SI125FA (FA) front flange for ACE 125 mm bore F-SI125FA (FB) rear flange for ACE 125 mm bore F-SE125CA (CA) single rear clevis for ACE 125 mm bore F-SE125CB (CB) double rear clevis for ACE 125 mm bore; catalog states the matching pin is included F-SI125CR (CR) rear hinge bracket for ACE 125 mm bore; must be paired with F-SE125CB double clevis F-SI125FTC (FTC) trunnion mounting for ACE 125 mm bore; requires F-SI125TCM2 support F-SI125TCM2 (TCM2) trunnion support for ACE 125 mm bore; pair with F-SI125FTC; mounting position is not freely adjustable Magnetic switch condition This code does not select a magnetic piston. A magnetic switch cannot provide piston-position sensing on a non-magnetic cylinder. Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected FA Mounting Dimensions Parameter Details A 20 mm B 90 mm C 139 mm D 16.5 mm E 110 mm F 180 mm G 218 mm H 60.5 mm N 92 mm Letters in this table belong to the FA accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250, 275, 300 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Weight Reference Estimated reference weight: 3522 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $316.63

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE80X45BCRT

  Specifications: ACE80X45BCRT is an AirTAC double-acting cylinder with a 80 mm bore, 45 mm stroke, no magnetic option in the standard suffix position, and male-threaded rod end. The CR suffix selects rear hinge bracket. Product Catalog Download Airtac Product Catalog (PDF) Download 2022 mounting brackets (PDF) Download 2022 rod-end joints and sensor mounts (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 80 80 mm bore X45 45 mm nominal stroke Blank magnetic position No magnetic piston selected by the standard order-code position B male-threaded rod end CR rear hinge bracket T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 63 mm AB 9 mm AC 54 mm AD 16 mm B 95.5 mm D 20 mm E M12 × 1.75 EA 20 mm H 17 mm J 15 mm JA 2.5 mm JB 72 mm K M10 × 1.5 KA Not listed for this size P G1/8 PA 8.5 mm PB 6 mm R 12.5 mm RA 6 mm T 12 mm TA 2.6 mm Male rod AB 37 mm Male rod D 20 mm Male rod E M16 × 1.5 Male rod EA 26 mm Male rod EB 28 mm Male rod F 23 mm Male rod FA 8 mm Male rod H 17 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 45 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. A, AB and the body outline are the catalog reference drawing values. The selected male rod uses the separate male-rod dimensions; do not substitute the female rod projection AB for it. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Magnetic-option component; not fitted in a non-magnetic configuration 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE80LB (LB) foot bracket for ACE 80 mm bore F-SI80FA (FA) front flange for ACE 80 mm bore F-SI80FA (FB) rear flange for ACE 80 mm bore F-SE80CA (CA) single rear clevis for ACE 80 mm bore F-SE80CB (CB) double rear clevis for ACE 80 mm bore; catalog states the matching pin is included F-SI80CR (CR) rear hinge bracket for ACE 80 mm bore; must be paired with F-SE80CB double clevis F-SI80FTC (FTC) trunnion mounting for ACE 80 mm bore; requires F-SI63TCM2 support F-SI63TCM2 (TCM2) trunnion support for ACE 80 mm bore; pair with F-SI80FTC; mounting position is not freely adjustable F-M16X150I I-type rod joint; matches the selected male rod thread only F-M16X150Y Y clevis; matches the selected male rod thread only F-M16X150F floating joint; matches the selected male rod thread only F-M16X150U spherical rod-end joint; matches the selected male rod thread only Magnetic switch condition This code does not select a magnetic piston. A magnetic switch cannot provide piston-position sensing on a non-magnetic cylinder. Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected CR Mounting Dimensions Parameter Details A 63 mm AA 60 mm B 54 mm C 54 mm CC 16 mm CD 93 mm CJ 19 mm D 47 mm E 40 mm F 60 mm G 14 mm H 66 mm I 86 mm K 11 mm L 17 mm Letters in this table belong to the CR accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250, 275, 300 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 80 mm Effective flow area at the reference speed 13.1 mm² Tube outside / inside diameter 16 / 11 mm Example speed controller PTL03 Example silencer BSL03 Example solenoid valves 5V31010 / 5V32010 Example air-piloted valves 4A31010 / 4A32010 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 1505.5 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $183.58

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE80X175FAT

  Specifications: ACE80X175FAT is an AirTAC double-acting cylinder with a 80 mm bore, 175 mm stroke, no magnetic option in the standard suffix position, and female-threaded rod end. The FA suffix selects front flange. Product Catalog Download Airtac Product Catalog (PDF) Download 2022 mounting brackets (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 80 80 mm bore X175 175 mm nominal stroke Blank magnetic position No magnetic piston selected by the standard order-code position Blank rod-end position female-threaded rod end FA front flange T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 63 mm AB 9 mm AC 54 mm AD 16 mm B 95.5 mm D 20 mm E M12 × 1.75 EA 20 mm H 17 mm J 15 mm JA 2.5 mm JB 72 mm K M10 × 1.5 KA Not listed for this size P G1/8 PA 8.5 mm PB 6 mm R 12.5 mm RA 6 mm T 12 mm TA 2.6 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 175 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Magnetic-option component; not fitted in a non-magnetic configuration 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE80LB (LB) foot bracket for ACE 80 mm bore F-SI80FA (FA) front flange for ACE 80 mm bore F-SI80FA (FB) rear flange for ACE 80 mm bore F-SE80CA (CA) single rear clevis for ACE 80 mm bore F-SE80CB (CB) double rear clevis for ACE 80 mm bore; catalog states the matching pin is included F-SI80CR (CR) rear hinge bracket for ACE 80 mm bore; must be paired with F-SE80CB double clevis F-SI80FTC (FTC) trunnion mounting for ACE 80 mm bore; requires F-SI63TCM2 support F-SI63TCM2 (TCM2) trunnion support for ACE 80 mm bore; pair with F-SI80FTC; mounting position is not freely adjustable Magnetic switch condition This code does not select a magnetic piston. A magnetic switch cannot provide piston-position sensing on a non-magnetic cylinder. Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected FA Mounting Dimensions Parameter Details A 16 mm B 63 mm C 95 mm D 12.5 mm E 72 mm F 126 mm G 150 mm H 45.5 mm N 63 mm Letters in this table belong to the FA accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250, 275, 300 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 80 mm Effective flow area at the reference speed 13.1 mm² Tube outside / inside diameter 16 / 11 mm Example speed controller PTL03 Example silencer BSL03 Example solenoid valves 5V31010 / 5V32010 Example air-piloted valves 4A31010 / 4A32010 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 2616.5 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $252.24

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE100X250SBFTCT

  Specifications: ACE100X250SBFTCT is an AirTAC double-acting cylinder with a 100 mm bore, 250 mm stroke, a magnetic piston, and male-threaded rod end. The FTC suffix selects trunnion mounting. Product Catalog Download Airtac Product Catalog (PDF) Download AirTAC 2022 Sensor and Mounting Compatibility Guide (PDF) Download 2022 mounting brackets (PDF) Download 2022 rod-end joints and sensor mounts (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 100 100 mm bore X250 250 mm nominal stroke S after stroke Magnetic piston selected B male-threaded rod end FTC trunnion mounting T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 76 mm AB 9 mm AC 67 mm AD 19 mm B 113.5 mm D 20 mm E M12 × 1.75 EA 20 mm H 17 mm J 15 mm JA 2.5 mm JB 89 mm K M10 × 1.5 KA Not listed for this size P G1/8 PA 10.5 mm PB 7 mm R 12.5 mm RA 6 mm T 12 mm TA 2.6 mm Male rod AB 37 mm Male rod D 20 mm Male rod E M16 × 1.5 Male rod EA 26 mm Male rod EB 28 mm Male rod F 23 mm Male rod FA 8 mm Male rod H 17 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 250 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. A, AB and the body outline are the catalog reference drawing values. The selected male rod uses the separate male-rod dimensions; do not substitute the female rod projection AB for it. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Plastic magnet 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE100LB (LB) foot bracket for ACE 100 mm bore F-SI100FA (FA) front flange for ACE 100 mm bore F-SI100FA (FB) rear flange for ACE 100 mm bore F-SE100CA (CA) single rear clevis for ACE 100 mm bore F-SE100CB (CB) double rear clevis for ACE 100 mm bore; catalog states the matching pin is included F-SI100CR (CR) rear hinge bracket for ACE 100 mm bore; must be paired with F-SE100CB double clevis F-SI100FTC (FTC) trunnion mounting for ACE 100 mm bore; requires F-SI125TCM2 support F-SI125TCM2 (TCM2) trunnion support for ACE 100 mm bore; pair with F-SI100FTC; mounting position is not freely adjustable F-M16X150I I-type rod joint; matches the selected male rod thread only F-M16X150Y Y clevis; matches the selected male rod thread only F-M16X150F floating joint; matches the selected male rod thread only F-M16X150U spherical rod-end joint; matches the selected male rod thread only CMSE / DMSE E-profile magnetic switches for this magnetic cylinder; order separately and select the electrical variant for the control system Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected FTC Mounting Dimensions Parameter Details A 102 mm AA 185 mm B 132 mm C 67 mm CA 25 mm D 89 mm E 114 mm F 35 mm K 16 mm Letters in this table belong to the FTC accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250, 275, 300 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 100 mm Effective flow area at the reference speed 20.4 mm² Tube outside / inside diameter 16 / 11 mm Example speed controller PTL03 Example silencer BSL03 Example solenoid valves 5V31010 / 5V32010 Example air-piloted valves 4A31010 / 4A32010 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 4539.5 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $511.75

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE80X40CAT

  Specifications: ACE80X40CAT is an AirTAC double-acting cylinder with a 80 mm bore, 40 mm stroke, no magnetic option in the standard suffix position, and female-threaded rod end. The CA suffix selects single rear clevis. Product Catalog Download Airtac Product Catalog (PDF) Download 2022 mounting brackets (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 80 80 mm bore X40 40 mm nominal stroke Blank magnetic position No magnetic piston selected by the standard order-code position Blank rod-end position female-threaded rod end CA single rear clevis T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 63 mm AB 9 mm AC 54 mm AD 16 mm B 95.5 mm D 20 mm E M12 × 1.75 EA 20 mm H 17 mm J 15 mm JA 2.5 mm JB 72 mm K M10 × 1.5 KA Not listed for this size P G1/8 PA 8.5 mm PB 6 mm R 12.5 mm RA 6 mm T 12 mm TA 2.6 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 40 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Magnetic-option component; not fitted in a non-magnetic configuration 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE80LB (LB) foot bracket for ACE 80 mm bore F-SI80FA (FA) front flange for ACE 80 mm bore F-SI80FA (FB) rear flange for ACE 80 mm bore F-SE80CA (CA) single rear clevis for ACE 80 mm bore F-SE80CB (CB) double rear clevis for ACE 80 mm bore; catalog states the matching pin is included F-SI80CR (CR) rear hinge bracket for ACE 80 mm bore; must be paired with F-SE80CB double clevis F-SI80FTC (FTC) trunnion mounting for ACE 80 mm bore; requires F-SI63TCM2 support F-SI63TCM2 (TCM2) trunnion support for ACE 80 mm bore; pair with F-SI80FTC; mounting position is not freely adjustable Magnetic switch condition This code does not select a magnetic piston. A magnetic switch cannot provide piston-position sensing on a non-magnetic cylinder. Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected CA Mounting Dimensions Parameter Details A 36 mm B 51.5 mm C 16 mm E 72 mm F 49.7 mm G 93 mm N 63 mm Letters in this table belong to the CA accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250, 275, 300 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 80 mm Effective flow area at the reference speed 13.1 mm² Tube outside / inside diameter 16 / 11 mm Example speed controller PTL03 Example silencer BSL03 Example solenoid valves 5V31010 / 5V32010 Example air-piloted valves 4A31010 / 4A32010 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 1401.5 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $170.84

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE32X15SLBT

  Specifications: ACE32X15SLBT is an AirTAC double-acting cylinder with a 32 mm bore, 15 mm stroke, a magnetic piston, and female-threaded rod end. The LB suffix selects foot bracket. Product Catalog Download Airtac Product Catalog (PDF) Download AirTAC 2022 Sensor and Mounting Compatibility Guide (PDF) Download 2022 mounting brackets (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 32 32 mm bore X15 15 mm nominal stroke S after stroke Magnetic piston selected Blank rod-end position female-threaded rod end LB foot bracket T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 51 mm AB 7 mm AC 44 mm AD 14 mm B 49.5 mm D 12 mm E M8 × 1.25 EA 16 mm H 10 mm J 9 mm JA 4.5 mm JB 32.5 mm K M6 × 1.0 KA 28.5 mm P G1/8 PA 7.5 mm PB 3 mm R 8.5 mm RA 3.5 mm T 9 mm TA 2.1 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 15 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Plastic magnet 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE32LB (LB) foot bracket for ACE 32 mm bore F-SI32FA (FA) front flange for ACE 32 mm bore F-SI32FA (FB) rear flange for ACE 32 mm bore F-SE32CA (CA) single rear clevis for ACE 32 mm bore F-SE32CB (CB) double rear clevis for ACE 32 mm bore; catalog states the matching pin is included F-SI32CR (CR) rear hinge bracket for ACE 32 mm bore; must be paired with F-SE32CB double clevis F-SI32FTC (FTC) trunnion mounting for ACE 32 mm bore; requires F-SI32TCM2 support F-SI32TCM2 (TCM2) trunnion support for ACE 32 mm bore; pair with F-SI32FTC; mounting position is not freely adjustable CMSE / DMSE E-profile magnetic switches for this magnetic cylinder; order separately and select the electrical variant for the control system Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected LB Mounting Dimensions Parameter Details A 33.5 mm B 4 mm C 44 mm D 76 mm E 89 mm F 7 mm G 32 mm H 48 mm Letters in this table belong to the LB accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 32 mm Effective flow area at the reference speed 2.1 mm² Tube outside / inside diameter 6 / 4 mm Example speed controller PTLM5 Example silencer BSLM5 Example solenoid valves 5V110M5 / 5V120M5 Example air-piloted valves 4A110M5 / 4A120M5 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 327.75 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $56.33

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE63X20SFAT

  Specifications: ACE63X20SFAT is an AirTAC double-acting cylinder with a 63 mm bore, 20 mm stroke, a magnetic piston, and female-threaded rod end. The FA suffix selects front flange. Product Catalog Download Airtac Product Catalog (PDF) Download AirTAC 2022 Sensor and Mounting Compatibility Guide (PDF) Download 2022 mounting brackets (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 63 63 mm bore X20 20 mm nominal stroke S after stroke Magnetic piston selected Blank rod-end position female-threaded rod end FA front flange T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 57 mm AB 8 mm AC 49 mm AD 15 mm B 75.5 mm D 16 mm E M10 × 1.5 EA 20 mm H 13 mm J 11 mm JA 4.5 mm JB 56.5 mm K M8 × 1.25 KA 30.5 mm P G1/8 PA 7.5 mm PB 4 mm R 10.5 mm RA 4.5 mm T 12 mm TA 2.6 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 20 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Plastic magnet 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE63LB (LB) foot bracket for ACE 63 mm bore F-SI63FA (FA) front flange for ACE 63 mm bore F-SI63FA (FB) rear flange for ACE 63 mm bore F-SE63CA (CA) single rear clevis for ACE 63 mm bore F-SE63CB (CB) double rear clevis for ACE 63 mm bore; catalog states the matching pin is included F-SI63CR (CR) rear hinge bracket for ACE 63 mm bore; must be paired with F-SE63CB double clevis F-SI63FTC (FTC) trunnion mounting for ACE 63 mm bore; requires F-SI63TCM2 support F-SI63TCM2 (TCM2) trunnion support for ACE 63 mm bore; pair with F-SI63FTC; mounting position is not freely adjustable CMSE / DMSE E-profile magnetic switches for this magnetic cylinder; order separately and select the electrical variant for the control system Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected FA Mounting Dimensions Parameter Details A 12 mm B 50 mm C 75 mm D 9 mm E 56.5 mm F 100 mm G 118 mm H 45.5 mm N 57 mm Letters in this table belong to the FA accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 63 mm Effective flow area at the reference speed 8.1 mm² Tube outside / inside diameter 10 / 6.5 mm Example speed controller PTL02 Example silencer BSL02 Example solenoid valves 5V21008 / 5V22008 Example air-piloted valves 4A21008 / 4A22008 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 857.5 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $109.60

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE63X90BCAT

  Specifications: ACE63X90BCAT is an AirTAC double-acting cylinder with a 63 mm bore, 90 mm stroke, no magnetic option in the standard suffix position, and male-threaded rod end. The CA suffix selects single rear clevis. Product Catalog Download Airtac Product Catalog (PDF) Download 2022 mounting brackets (PDF) Download 2022 rod-end joints and sensor mounts (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 63 63 mm bore X90 90 mm nominal stroke Blank magnetic position No magnetic piston selected by the standard order-code position B male-threaded rod end CA single rear clevis T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 57 mm AB 8 mm AC 49 mm AD 15 mm B 75.5 mm D 16 mm E M10 × 1.5 EA 20 mm H 13 mm J 11 mm JA 4.5 mm JB 56.5 mm K M8 × 1.25 KA 30.5 mm P G1/8 PA 7.5 mm PB 4 mm R 10.5 mm RA 4.5 mm T 12 mm TA 2.6 mm Male rod AB 30 mm Male rod D 16 mm Male rod E M12 × 1.25 Male rod EA 20 mm Male rod EB 22 mm Male rod F 17 mm Male rod FA 7 mm Male rod H 13 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 90 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. A, AB and the body outline are the catalog reference drawing values. The selected male rod uses the separate male-rod dimensions; do not substitute the female rod projection AB for it. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Magnetic-option component; not fitted in a non-magnetic configuration 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE63LB (LB) foot bracket for ACE 63 mm bore F-SI63FA (FA) front flange for ACE 63 mm bore F-SI63FA (FB) rear flange for ACE 63 mm bore F-SE63CA (CA) single rear clevis for ACE 63 mm bore F-SE63CB (CB) double rear clevis for ACE 63 mm bore; catalog states the matching pin is included F-SI63CR (CR) rear hinge bracket for ACE 63 mm bore; must be paired with F-SE63CB double clevis F-SI63FTC (FTC) trunnion mounting for ACE 63 mm bore; requires F-SI63TCM2 support F-SI63TCM2 (TCM2) trunnion support for ACE 63 mm bore; pair with F-SI63FTC; mounting position is not freely adjustable F-M12X125I I-type rod joint; matches the selected male rod thread only F-M12X125Y Y clevis; matches the selected male rod thread only F-M12X125F floating joint; matches the selected male rod thread only F-M12X125U spherical rod-end joint; matches the selected male rod thread only Magnetic switch condition This code does not select a magnetic piston. A magnetic switch cannot provide piston-position sensing on a non-magnetic cylinder. Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected CA Mounting Dimensions Parameter Details A 32 mm B 47 mm C 16 mm E 56.5 mm F 39.7 mm G 75 mm N 57 mm Letters in this table belong to the CA accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 63 mm Effective flow area at the reference speed 8.1 mm² Tube outside / inside diameter 10 / 6.5 mm Example speed controller PTL02 Example silencer BSL02 Example solenoid valves 5V21008 / 5V22008 Example air-piloted valves 4A21008 / 4A22008 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 1330.5 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $148.10

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE63X35BFBT

  Specifications: ACE63X35BFBT is an AirTAC double-acting cylinder with a 63 mm bore, 35 mm stroke, no magnetic option in the standard suffix position, and male-threaded rod end. The FB suffix selects rear flange. Product Catalog Download Airtac Product Catalog (PDF) Download 2022 mounting brackets (PDF) Download 2022 rod-end joints and sensor mounts (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 63 63 mm bore X35 35 mm nominal stroke Blank magnetic position No magnetic piston selected by the standard order-code position B male-threaded rod end FB rear flange T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 57 mm AB 8 mm AC 49 mm AD 15 mm B 75.5 mm D 16 mm E M10 × 1.5 EA 20 mm H 13 mm J 11 mm JA 4.5 mm JB 56.5 mm K M8 × 1.25 KA 30.5 mm P G1/8 PA 7.5 mm PB 4 mm R 10.5 mm RA 4.5 mm T 12 mm TA 2.6 mm Male rod AB 30 mm Male rod D 16 mm Male rod E M12 × 1.25 Male rod EA 20 mm Male rod EB 22 mm Male rod F 17 mm Male rod FA 7 mm Male rod H 13 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 35 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. A, AB and the body outline are the catalog reference drawing values. The selected male rod uses the separate male-rod dimensions; do not substitute the female rod projection AB for it. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Magnetic-option component; not fitted in a non-magnetic configuration 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE63LB (LB) foot bracket for ACE 63 mm bore F-SI63FA (FA) front flange for ACE 63 mm bore F-SI63FA (FB) rear flange for ACE 63 mm bore F-SE63CA (CA) single rear clevis for ACE 63 mm bore F-SE63CB (CB) double rear clevis for ACE 63 mm bore; catalog states the matching pin is included F-SI63CR (CR) rear hinge bracket for ACE 63 mm bore; must be paired with F-SE63CB double clevis F-SI63FTC (FTC) trunnion mounting for ACE 63 mm bore; requires F-SI63TCM2 support F-SI63TCM2 (TCM2) trunnion support for ACE 63 mm bore; pair with F-SI63FTC; mounting position is not freely adjustable F-M12X125I I-type rod joint; matches the selected male rod thread only F-M12X125Y Y clevis; matches the selected male rod thread only F-M12X125F floating joint; matches the selected male rod thread only F-M12X125U spherical rod-end joint; matches the selected male rod thread only Magnetic switch condition This code does not select a magnetic piston. A magnetic switch cannot provide piston-position sensing on a non-magnetic cylinder. Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected FB Mounting Dimensions Parameter Details A 12 mm B 50 mm C 75 mm D 9 mm E 56.5 mm F 100 mm G 118 mm H 45.5 mm N 57 mm Letters in this table belong to the FB accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 63 mm Effective flow area at the reference speed 8.1 mm² Tube outside / inside diameter 10 / 6.5 mm Example speed controller PTL02 Example silencer BSL02 Example solenoid valves 5V21008 / 5V22008 Example air-piloted valves 4A21008 / 4A22008 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 970.25 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $113.82

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE80X15SCBT

  Specifications: ACE80X15SCBT is an AirTAC double-acting cylinder with a 80 mm bore, 15 mm stroke, a magnetic piston, and female-threaded rod end. The CB suffix selects double rear clevis. Product Catalog Download Airtac Product Catalog (PDF) Download AirTAC 2022 Sensor and Mounting Compatibility Guide (PDF) Download 2022 mounting brackets (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 80 80 mm bore X15 15 mm nominal stroke S after stroke Magnetic piston selected Blank rod-end position female-threaded rod end CB double rear clevis T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 63 mm AB 9 mm AC 54 mm AD 16 mm B 95.5 mm D 20 mm E M12 × 1.75 EA 20 mm H 17 mm J 15 mm JA 2.5 mm JB 72 mm K M10 × 1.5 KA Not listed for this size P G1/8 PA 8.5 mm PB 6 mm R 12.5 mm RA 6 mm T 12 mm TA 2.6 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 15 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Plastic magnet 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE80LB (LB) foot bracket for ACE 80 mm bore F-SI80FA (FA) front flange for ACE 80 mm bore F-SI80FA (FB) rear flange for ACE 80 mm bore F-SE80CA (CA) single rear clevis for ACE 80 mm bore F-SE80CB (CB) double rear clevis for ACE 80 mm bore; catalog states the matching pin is included F-SI80CR (CR) rear hinge bracket for ACE 80 mm bore; must be paired with F-SE80CB double clevis F-SI80FTC (FTC) trunnion mounting for ACE 80 mm bore; requires F-SI63TCM2 support F-SI63TCM2 (TCM2) trunnion support for ACE 80 mm bore; pair with F-SI80FTC; mounting position is not freely adjustable CMSE / DMSE E-profile magnetic switches for this magnetic cylinder; order separately and select the electrical variant for the control system Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected CB Mounting Dimensions Parameter Details A 36 mm B 51.5 mm C 16 mm D 60 mm E 72 mm F 90 mm G 93 mm H 97 mm N 63 mm Letters in this table belong to the CB accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250, 275, 300 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 80 mm Effective flow area at the reference speed 13.1 mm² Tube outside / inside diameter 16 / 11 mm Example speed controller PTL03 Example silencer BSL03 Example solenoid valves 5V31010 / 5V32010 Example air-piloted valves 4A31010 / 4A32010 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 1211 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $160.07

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE50X40BCRT

  Specifications: ACE50X40BCRT is an AirTAC double-acting cylinder with a 50 mm bore, 40 mm stroke, no magnetic option in the standard suffix position, and male-threaded rod end. The CR suffix selects rear hinge bracket. Product Catalog Download Airtac Product Catalog (PDF) Download 2022 mounting brackets (PDF) Download 2022 rod-end joints and sensor mounts (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 50 50 mm bore X40 40 mm nominal stroke Blank magnetic position No magnetic piston selected by the standard order-code position B male-threaded rod end CR rear hinge bracket T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 53.5 mm AB 8 mm AC 45.5 mm AD 14.5 mm B 65.5 mm D 16 mm E M10 × 1.5 EA 20 mm H 13 mm J 11 mm JA 4.5 mm JB 46.5 mm K M8 × 1.25 KA 30.5 mm P G1/8 PA 7.5 mm PB 3 mm R 10.5 mm RA 4.5 mm T 12 mm TA 2.6 mm Male rod AB 30 mm Male rod D 16 mm Male rod E M12 × 1.25 Male rod EA 20 mm Male rod EB 22 mm Male rod F 17 mm Male rod FA 7 mm Male rod H 13 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 40 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. A, AB and the body outline are the catalog reference drawing values. The selected male rod uses the separate male-rod dimensions; do not substitute the female rod projection AB for it. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Magnetic-option component; not fitted in a non-magnetic configuration 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE50LB (LB) foot bracket for ACE 50 mm bore F-SI50FA (FA) front flange for ACE 50 mm bore F-SI50FA (FB) rear flange for ACE 50 mm bore F-SE50CA (CA) single rear clevis for ACE 50 mm bore F-SE50CB (CB) double rear clevis for ACE 50 mm bore; catalog states the matching pin is included F-SI50CR (CR) rear hinge bracket for ACE 50 mm bore; must be paired with F-SE50CB double clevis F-SI50FTC (FTC) trunnion mounting for ACE 50 mm bore; requires F-SI40TCM2 support F-SI40TCM2 (TCM2) trunnion support for ACE 50 mm bore; pair with F-SI50FTC; mounting position is not freely adjustable F-M12X125I I-type rod joint; matches the selected male rod thread only F-M12X125Y Y clevis; matches the selected male rod thread only F-M12X125F floating joint; matches the selected male rod thread only F-M12X125U spherical rod-end joint; matches the selected male rod thread only Magnetic switch condition This code does not select a magnetic piston. A magnetic switch cannot provide piston-position sensing on a non-magnetic cylinder. Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected CR Mounting Dimensions Parameter Details A 53.5 mm AA 45 mm B 32 mm C 45.5 mm CC 12 mm CD 68 mm CJ 13 mm D 33 mm E 30 mm F 45 mm G 12 mm H 50 mm I 65 mm K 9 mm L 14 mm Letters in this table belong to the CR accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200, 225, 250 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 50 mm Effective flow area at the reference speed 5.1 mm² Tube outside / inside diameter 10 / 6.5 mm Example speed controller PTL02 Example silencer BSL02 Example solenoid valves 5V21008 / 5V22008 Example air-piloted valves 4A21008 / 4A22008 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 708 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $97.52

  View options

•

  View options

  Airtac ACE series: double-acting compact cylinder - ACE32X5SCBT

  Specifications: ACE32X5SCBT is an AirTAC double-acting cylinder with a 32 mm bore, 5 mm stroke, a magnetic piston, and female-threaded rod end. The CB suffix selects double rear clevis. Product Catalog Download Airtac Product Catalog (PDF) Download AirTAC 2022 Sensor and Mounting Compatibility Guide (PDF) Download 2022 mounting brackets (PDF) Download 2022 cylinder installation and weight tables (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Model Code Explained Code Meaning for This Model ACE double-acting cylinder 32 32 mm bore X5 5 mm nominal stroke S after stroke Magnetic piston selected Blank rod-end position female-threaded rod end CB double rear clevis T Suffix retained; not defined in this family's reviewed ordering chart Configuration Notes The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard. Technical Specifications Parameter Details Action double-acting cylinder Working medium Air filtered through a 40 μm filter or finer Operating pressure 0.15–1 MPa Proof pressure 1.5 MPa; a proof-test rating, not the continuous operating limit Ambient and fluid temperature −20 to 70 °C Piston speed 30–500 mm/s Stroke tolerance +1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm Cushioning Bumper Air connection PT 1/8 (standard catalog reference; suffix is not defined in the order chart) Design standard ISO 21287 Product Features The cylinder body and covers use threaded connections for strength and maintenance access. The precision-finished bore is hard anodized for wear resistance. The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated. The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves. Dimensions for This Bore and Configuration Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship. Parameter Details A 51 mm AB 7 mm AC 44 mm AD 14 mm B 49.5 mm D 12 mm E M8 × 1.25 EA 16 mm H 10 mm J 9 mm JA 4.5 mm JB 32.5 mm K M6 × 1.0 KA 28.5 mm P G1/8 PA 7.5 mm PB 3 mm R 8.5 mm RA 3.5 mm T 9 mm TA 2.1 mm Stroke-dependent Drawing Relationships Parameter Details Reference drawing overall A + stroke AC outline AC + stroke Stroke used in the order code 5 mm P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction. Construction and Materials Parameter Details 1 Screw Carbon steel 2 Rear cover Aluminum alloy 3 Bumper TPU 4 O-ring NBR 5 Wear ring Wear-resistant material 6 Magnet Plastic magnet 7 Piston seal NBR 8 Piston Aluminum alloy 9 Piston rod S45C steel 10 Body Aluminum alloy 11 Front cover Aluminum alloy 12 Bushing Wear-resistant material 13 Rod seal NBR Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities. Matching Accessories and Mounting Parameter Details F-ACE32LB (LB) foot bracket for ACE 32 mm bore F-SI32FA (FA) front flange for ACE 32 mm bore F-SI32FA (FB) rear flange for ACE 32 mm bore F-SE32CA (CA) single rear clevis for ACE 32 mm bore F-SE32CB (CB) double rear clevis for ACE 32 mm bore; catalog states the matching pin is included F-SI32CR (CR) rear hinge bracket for ACE 32 mm bore; must be paired with F-SE32CB double clevis F-SI32FTC (FTC) trunnion mounting for ACE 32 mm bore; requires F-SI32TCM2 support F-SI32TCM2 (TCM2) trunnion support for ACE 32 mm bore; pair with F-SI32FTC; mounting position is not freely adjustable CMSE / DMSE E-profile magnetic switches for this magnetic cylinder; order separately and select the electrical variant for the control system Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities. Selected CB Mounting Dimensions Parameter Details A 22 mm B 32.5 mm C 10 mm D 26 mm E 32.5 mm F 45 mm G 46.5 mm H 51 mm N 51 mm Letters in this table belong to the CB accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths. Stroke and Option Selection Parameter Details Standard strokes for this bore/action 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200 mm Intermediate strokes The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. Magnetic selection Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. Selection, Installation and Operation Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder. Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide. Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication. Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping. Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation. Circuit Selection Reference at 500 mm/s Parameter Details Reference bore 32 mm Effective flow area at the reference speed 2.1 mm² Tube outside / inside diameter 6 / 4 mm Example speed controller PTLM5 Example silencer BSLM5 Example solenoid valves 5V110M5 / 5V120M5 Example air-piloted valves 4A110M5 / 4A120M5 The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions. Weight Reference Estimated reference weight: 292.25 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

  Read more less

  $63.10

  View options

Show more products
