Valve
Product Features
- Direct-acting two-position, two-way solenoid valve with fast and sensitive action.
- Wide operating pressure range, with options for ultra-high pressure (X), high pressure (H), standard, large flow (L), and extra large flow (T).
- Compact, small, lightweight, and easy to assemble and disassemble.
- The valve body is made of brass; the coil has a heat resistance classification of Grade B. The standard seal material is FPM-F (Viton), suitable for various working media. For other seal materials, please consult our company's technical department.
- The coil protection class is IP65, with electrical connection options of direct lead wire or DIN connector.
Specifications
| Model No. | Port Size [Note 1] | Orifice Dia. (mm) | Cv Value | Effective Area (mm²) | Weight (g) [Note 2] | Max. Operating Pressure | Max. Proof Pressure | ||
|---|---|---|---|---|---|---|---|---|---|
| MPa | psi | MPa | psi | ||||||
| 2WX030 | -06 PT1/8 | 1.5 | 0.10 | 1.8 | 305 | 3.0 | 450 | 5.0 | 750 |
| -08 PT1/4 | 295 | ||||||||
| 2WH030 | -06 PT1/8 | 2.0 | 0.18 | 3.0 | 305 | 2.0 | 300 | ||
| -08 PT1/4 | 295 | ||||||||
| 2W030 | -06 PT1/8 | 3.0 | 0.33 | 6.0 | 305 | 1.0 | 150 | ||
| -08 PT1/4 | 295 | ||||||||
| 2WL030 | -06 PT1/8 | 4.0 | 0.55 | 10.0 | 305 | 0.5 | 75 | ||
| -08 PT1/4 | 295 | ||||||||
| 2WT030 | -06 PT1/8 | 6.0 | 1.10 | 12.0 | 305 | 0.1 | 15 | ||
| -08 PT1/4 | 295 | ||||||||
| 2WX050 | -10 PT3/8 | 3.0 | 0.34 | 6.1 | 620 | 3.0 | 450 | ||
| -15 PT1/2 | 600 | ||||||||
| 2WH050 | -10 PT3/8 | 4.0 | 0.55 | 10.0 | 620 | 2.0 | 300 | ||
| -15 PT1/2 | 600 | ||||||||
| 2W050 | -10 PT3/8 | 5.0 | 0.83 | 15.0 | 620 | 1.0 | 150 | ||
| -15 PT1/2 | 600 | ||||||||
| 2WL050 | -10 PT3/8 | 7.0 | 1.40 | 25.0 | 620 | 0.5 | 75 | ||
| -15 PT1/2 | 600 | ||||||||
| 2WT050 | -10 PT3/8 | 10.0 | 2.20 | 40.0 | 620 | 0.1 | 15 | ||
| -15 PT1/2 | 600 | ||||||||
Note 1: G and NPT thread types are available.
Note 2: The weight listed is for the DIN connector type. The lead wire type for the 2W030 series is 10g lighter, and for the 2W050 series, it is 20g lighter.
Note 2: The weight listed is for the DIN connector type. The lead wire type for the 2W030 series is 10g lighter, and for the 2W050 series, it is 20g lighter.
Product Ordering Code
| Position | Description | Options & Values |
|---|---|---|
| 1 | Model Code |
|
| 2 | Pressure Type |
|
| 3 | Series Code |
|
| 4 | Port Size |
|
| 5 | Coil Voltage |
|
| 6 | Connection Type |
|
| 7 | Thread Code |
|
Note 1: The standard length for the lead wire type is 0.5m.
