  Airtac 2L series: two-way fluid solenoid valve - 2L20020EG

  Specifications: 2L20020EG is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 200 identifies the orifice-size branch; port code 20 selects G3/4; voltage code E selects AC24V; electrical entry is terminal connector. Thread suffix G selects G threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L20020EG will be supplied as 2LA20020EG (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L20020EG in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 200 — 20 mm orifice Port-size code 20 — G3/4 Voltage code E — AC24V Electrical-entry code Omitted — terminal Thread code G — G Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 20 mm Flow coefficient Cv 9.50 Effective flow area 170 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 875 g; terminal version. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage AC24V Electrical entry terminal connector Coil family listed for this valve CDA116 Supply tolerance ±15% Supply frequency 50 or 60 Hz; consumption differs with frequency. Power consumption 10 VA at 50 Hz; 8 VA at 60 Hz Catalog temperature rise 35°C at 50 Hz; 30°C at 60 Hz Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L terminal drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 78.5 mm AB — body span AB 82 mm B — drawing width B 53 mm BA — port-side span BA 33.5 mm C — drawing height C 115.5 mm D — drawing dimension D 90 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 75 mm EC — drawing dimension EC 40 mm F — drawing dimension F 34 mm P — fluid port thread P G3/4 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. Drawing check required: the source table lists A=78.5 mm and AB=82 mm for this terminal version. These values are reproduced exactly, although the drawing makes their relationship unclear. Confirm the approved drawing before using this combination for installation or interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 20 mm orifice, Cv 9.50 and 170 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S200LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $122.07

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L20020EI

  Specifications: 2L20020EI is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 200 identifies the orifice-size branch; port code 20 selects PT3/4; voltage code E selects AC24V; electrical entry is grommet / flying lead with a 0.5 m lead. The omitted thread suffix selects PT threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L20020EI will be supplied as 2LA20020EI (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L20020EI in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 200 — 20 mm orifice Port-size code 20 — PT3/4 Voltage code E — AC24V Electrical-entry code I — grommet / flying lead, 0.5 m Thread code Omitted — PT Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 20 mm Flow coefficient Cv 9.50 Effective flow area 170 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 865 g = 875 g terminal value − 10 g grommet reduction. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage AC24V Electrical entry grommet / flying lead with a 0.5 m lead Coil family listed for this valve CLA116 Supply tolerance ±15% Supply frequency 50 or 60 Hz; consumption differs with frequency. Power consumption 10 VA at 50 Hz; 8 VA at 60 Hz Catalog temperature rise 35°C at 50 Hz; 30°C at 60 Hz Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L grommet / flying-lead drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 82 mm B — drawing width B 53 mm BA — port-side span BA 33.5 mm C — drawing height C 115.5 mm D — drawing dimension D 90 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 75 mm EC — drawing dimension EC 40 mm F — drawing dimension F 34 mm P — fluid port thread P PT3/4 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 20 mm orifice, Cv 9.50 and 170 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S200LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $122.07

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L20020EIG

  Specifications: 2L20020EIG is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 200 identifies the orifice-size branch; port code 20 selects G3/4; voltage code E selects AC24V; electrical entry is grommet / flying lead with a 0.5 m lead. Thread suffix G selects G threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L20020EIG will be supplied as 2LA20020EIG (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L20020EIG in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 200 — 20 mm orifice Port-size code 20 — G3/4 Voltage code E — AC24V Electrical-entry code I — grommet / flying lead, 0.5 m Thread code G — G Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 20 mm Flow coefficient Cv 9.50 Effective flow area 170 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 865 g = 875 g terminal value − 10 g grommet reduction. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage AC24V Electrical entry grommet / flying lead with a 0.5 m lead Coil family listed for this valve CLA116 Supply tolerance ±15% Supply frequency 50 or 60 Hz; consumption differs with frequency. Power consumption 10 VA at 50 Hz; 8 VA at 60 Hz Catalog temperature rise 35°C at 50 Hz; 30°C at 60 Hz Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L grommet / flying-lead drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 82 mm B — drawing width B 53 mm BA — port-side span BA 33.5 mm C — drawing height C 115.5 mm D — drawing dimension D 90 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 75 mm EC — drawing dimension EC 40 mm F — drawing dimension F 34 mm P — fluid port thread P G3/4 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 20 mm orifice, Cv 9.50 and 170 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S200LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $122.07

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L20020EIT

  Specifications: 2L20020EIT is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 200 identifies the orifice-size branch; port code 20 selects NPT3/4; voltage code E selects AC24V; electrical entry is grommet / flying lead with a 0.5 m lead. Thread suffix T selects NPT threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L20020EIT will be supplied as 2LA20020EIT (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L20020EIT in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 200 — 20 mm orifice Port-size code 20 — NPT3/4 Voltage code E — AC24V Electrical-entry code I — grommet / flying lead, 0.5 m Thread code T — NPT Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 20 mm Flow coefficient Cv 9.50 Effective flow area 170 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 865 g = 875 g terminal value − 10 g grommet reduction. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage AC24V Electrical entry grommet / flying lead with a 0.5 m lead Coil family listed for this valve CLA116 Supply tolerance ±15% Supply frequency 50 or 60 Hz; consumption differs with frequency. Power consumption 10 VA at 50 Hz; 8 VA at 60 Hz Catalog temperature rise 35°C at 50 Hz; 30°C at 60 Hz Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L grommet / flying-lead drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 82 mm B — drawing width B 53 mm BA — port-side span BA 33.5 mm C — drawing height C 115.5 mm D — drawing dimension D 90 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 75 mm EC — drawing dimension EC 40 mm F — drawing dimension F 34 mm P — fluid port thread P NPT3/4 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 20 mm orifice, Cv 9.50 and 170 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S200LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $122.07

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L20020ET

  Specifications: 2L20020ET is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 200 identifies the orifice-size branch; port code 20 selects NPT3/4; voltage code E selects AC24V; electrical entry is terminal connector. Thread suffix T selects NPT threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L20020ET will be supplied as 2LA20020ET (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L20020ET in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 200 — 20 mm orifice Port-size code 20 — NPT3/4 Voltage code E — AC24V Electrical-entry code Omitted — terminal Thread code T — NPT Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 20 mm Flow coefficient Cv 9.50 Effective flow area 170 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 875 g; terminal version. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage AC24V Electrical entry terminal connector Coil family listed for this valve CDA116 Supply tolerance ±15% Supply frequency 50 or 60 Hz; consumption differs with frequency. Power consumption 10 VA at 50 Hz; 8 VA at 60 Hz Catalog temperature rise 35°C at 50 Hz; 30°C at 60 Hz Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L terminal drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 78.5 mm AB — body span AB 82 mm B — drawing width B 53 mm BA — port-side span BA 33.5 mm C — drawing height C 115.5 mm D — drawing dimension D 90 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 75 mm EC — drawing dimension EC 40 mm F — drawing dimension F 34 mm P — fluid port thread P NPT3/4 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. Drawing check required: the source table lists A=78.5 mm and AB=82 mm for this terminal version. These values are reproduced exactly, although the drawing makes their relationship unclear. Confirm the approved drawing before using this combination for installation or interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 20 mm orifice, Cv 9.50 and 170 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S200LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $122.07

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L20020F

  Specifications: 2L20020F is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 200 identifies the orifice-size branch; port code 20 selects PT3/4; voltage code F selects DC12V; electrical entry is terminal connector. The omitted thread suffix selects PT threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L20020F will be supplied as 2LA20020F (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L20020F in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 200 — 20 mm orifice Port-size code 20 — PT3/4 Voltage code F — DC12V Electrical-entry code Omitted — terminal Thread code Omitted — PT Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 20 mm Flow coefficient Cv 9.50 Effective flow area 170 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 875 g; terminal version. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage DC12V Electrical entry terminal connector Coil family listed for this valve CDA116 Supply tolerance ±10% Supply frequency DC; frequency is not applicable. Power consumption 6.5 W Catalog temperature rise 30°C Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L terminal drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 78.5 mm AB — body span AB 82 mm B — drawing width B 53 mm BA — port-side span BA 33.5 mm C — drawing height C 115.5 mm D — drawing dimension D 90 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 75 mm EC — drawing dimension EC 40 mm F — drawing dimension F 34 mm P — fluid port thread P PT3/4 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. Drawing check required: the source table lists A=78.5 mm and AB=82 mm for this terminal version. These values are reproduced exactly, although the drawing makes their relationship unclear. Confirm the approved drawing before using this combination for installation or interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 20 mm orifice, Cv 9.50 and 170 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S200LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $122.07

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L20020FG

  Specifications: 2L20020FG is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 200 identifies the orifice-size branch; port code 20 selects G3/4; voltage code F selects DC12V; electrical entry is terminal connector. Thread suffix G selects G threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L20020FG will be supplied as 2LA20020FG (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L20020FG in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 200 — 20 mm orifice Port-size code 20 — G3/4 Voltage code F — DC12V Electrical-entry code Omitted — terminal Thread code G — G Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 20 mm Flow coefficient Cv 9.50 Effective flow area 170 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 875 g; terminal version. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage DC12V Electrical entry terminal connector Coil family listed for this valve CDA116 Supply tolerance ±10% Supply frequency DC; frequency is not applicable. Power consumption 6.5 W Catalog temperature rise 30°C Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L terminal drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 78.5 mm AB — body span AB 82 mm B — drawing width B 53 mm BA — port-side span BA 33.5 mm C — drawing height C 115.5 mm D — drawing dimension D 90 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 75 mm EC — drawing dimension EC 40 mm F — drawing dimension F 34 mm P — fluid port thread P G3/4 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. Drawing check required: the source table lists A=78.5 mm and AB=82 mm for this terminal version. These values are reproduced exactly, although the drawing makes their relationship unclear. Confirm the approved drawing before using this combination for installation or interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 20 mm orifice, Cv 9.50 and 170 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S200LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $122.07

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L20020FI

  Specifications: 2L20020FI is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 200 identifies the orifice-size branch; port code 20 selects PT3/4; voltage code F selects DC12V; electrical entry is grommet / flying lead with a 0.5 m lead. The omitted thread suffix selects PT threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L20020FI will be supplied as 2LA20020FI (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L20020FI in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 200 — 20 mm orifice Port-size code 20 — PT3/4 Voltage code F — DC12V Electrical-entry code I — grommet / flying lead, 0.5 m Thread code Omitted — PT Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 20 mm Flow coefficient Cv 9.50 Effective flow area 170 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 865 g = 875 g terminal value − 10 g grommet reduction. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage DC12V Electrical entry grommet / flying lead with a 0.5 m lead Coil family listed for this valve CLA116 Supply tolerance ±10% Supply frequency DC; frequency is not applicable. Power consumption 6.5 W Catalog temperature rise 30°C Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L grommet / flying-lead drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 82 mm B — drawing width B 53 mm BA — port-side span BA 33.5 mm C — drawing height C 115.5 mm D — drawing dimension D 90 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 75 mm EC — drawing dimension EC 40 mm F — drawing dimension F 34 mm P — fluid port thread P PT3/4 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 20 mm orifice, Cv 9.50 and 170 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S200LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $122.07

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L20020FIG

  Specifications: 2L20020FIG is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 200 identifies the orifice-size branch; port code 20 selects G3/4; voltage code F selects DC12V; electrical entry is grommet / flying lead with a 0.5 m lead. Thread suffix G selects G threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L20020FIG will be supplied as 2LA20020FIG (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L20020FIG in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 200 — 20 mm orifice Port-size code 20 — G3/4 Voltage code F — DC12V Electrical-entry code I — grommet / flying lead, 0.5 m Thread code G — G Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 20 mm Flow coefficient Cv 9.50 Effective flow area 170 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 865 g = 875 g terminal value − 10 g grommet reduction. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage DC12V Electrical entry grommet / flying lead with a 0.5 m lead Coil family listed for this valve CLA116 Supply tolerance ±10% Supply frequency DC; frequency is not applicable. Power consumption 6.5 W Catalog temperature rise 30°C Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L grommet / flying-lead drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 82 mm B — drawing width B 53 mm BA — port-side span BA 33.5 mm C — drawing height C 115.5 mm D — drawing dimension D 90 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 75 mm EC — drawing dimension EC 40 mm F — drawing dimension F 34 mm P — fluid port thread P G3/4 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 20 mm orifice, Cv 9.50 and 170 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S200LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $122.07

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L20020FIT

  Specifications: 2L20020FIT is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 200 identifies the orifice-size branch; port code 20 selects NPT3/4; voltage code F selects DC12V; electrical entry is grommet / flying lead with a 0.5 m lead. Thread suffix T selects NPT threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L20020FIT will be supplied as 2LA20020FIT (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L20020FIT in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 200 — 20 mm orifice Port-size code 20 — NPT3/4 Voltage code F — DC12V Electrical-entry code I — grommet / flying lead, 0.5 m Thread code T — NPT Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 20 mm Flow coefficient Cv 9.50 Effective flow area 170 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 865 g = 875 g terminal value − 10 g grommet reduction. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage DC12V Electrical entry grommet / flying lead with a 0.5 m lead Coil family listed for this valve CLA116 Supply tolerance ±10% Supply frequency DC; frequency is not applicable. Power consumption 6.5 W Catalog temperature rise 30°C Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L grommet / flying-lead drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 82 mm B — drawing width B 53 mm BA — port-side span BA 33.5 mm C — drawing height C 115.5 mm D — drawing dimension D 90 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 75 mm EC — drawing dimension EC 40 mm F — drawing dimension F 34 mm P — fluid port thread P NPT3/4 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 20 mm orifice, Cv 9.50 and 170 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S200LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $122.07

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L20020FT

  Specifications: 2L20020FT is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 200 identifies the orifice-size branch; port code 20 selects NPT3/4; voltage code F selects DC12V; electrical entry is terminal connector. Thread suffix T selects NPT threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L20020FT will be supplied as 2LA20020FT (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L20020FT in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 200 — 20 mm orifice Port-size code 20 — NPT3/4 Voltage code F — DC12V Electrical-entry code Omitted — terminal Thread code T — NPT Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 20 mm Flow coefficient Cv 9.50 Effective flow area 170 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 875 g; terminal version. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage DC12V Electrical entry terminal connector Coil family listed for this valve CDA116 Supply tolerance ±10% Supply frequency DC; frequency is not applicable. Power consumption 6.5 W Catalog temperature rise 30°C Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L terminal drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 78.5 mm AB — body span AB 82 mm B — drawing width B 53 mm BA — port-side span BA 33.5 mm C — drawing height C 115.5 mm D — drawing dimension D 90 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 75 mm EC — drawing dimension EC 40 mm F — drawing dimension F 34 mm P — fluid port thread P NPT3/4 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. Drawing check required: the source table lists A=78.5 mm and AB=82 mm for this terminal version. These values are reproduced exactly, although the drawing makes their relationship unclear. Confirm the approved drawing before using this combination for installation or interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 20 mm orifice, Cv 9.50 and 170 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S200LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $122.07

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L25025A

  Specifications: 2L25025A is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 250 identifies the orifice-size branch; port code 25 selects PT1; voltage code A selects AC220V; electrical entry is terminal connector. The omitted thread suffix selects PT threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L25025A will be supplied as 2LA25025A (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L25025A in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 250 — 25 mm orifice Port-size code 25 — PT1 Voltage code A — AC220V Electrical-entry code Omitted — terminal Thread code Omitted — PT Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 25 mm Flow coefficient Cv 12.50 Effective flow area 220 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 1120 g; terminal version. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage AC220V Electrical entry terminal connector Coil family listed for this valve CDA116 Supply tolerance ±15% Supply frequency 50 or 60 Hz; consumption differs with frequency. Power consumption 10 VA at 50 Hz; 8 VA at 60 Hz Catalog temperature rise 35°C at 50 Hz; 30°C at 60 Hz Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L terminal drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 81 mm AB — body span AB 92 mm B — drawing width B 59 mm BA — port-side span BA 40.5 mm C — drawing height C 124 mm D — drawing dimension D 95 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 80 mm EC — drawing dimension EC 44.5 mm F — drawing dimension F 36 mm P — fluid port thread P PT1 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. Drawing check required: the source table lists A=81 mm and AB=92 mm for this terminal version. These values are reproduced exactly, although the drawing makes their relationship unclear. Confirm the approved drawing before using this combination for installation or interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 25 mm orifice, Cv 12.50 and 220 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S250LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $154.40

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L25025AG

  Specifications: 2L25025AG is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 250 identifies the orifice-size branch; port code 25 selects G1; voltage code A selects AC220V; electrical entry is terminal connector. Thread suffix G selects G threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L25025AG will be supplied as 2LA25025AG (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L25025AG in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 250 — 25 mm orifice Port-size code 25 — G1 Voltage code A — AC220V Electrical-entry code Omitted — terminal Thread code G — G Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 25 mm Flow coefficient Cv 12.50 Effective flow area 220 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 1120 g; terminal version. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage AC220V Electrical entry terminal connector Coil family listed for this valve CDA116 Supply tolerance ±15% Supply frequency 50 or 60 Hz; consumption differs with frequency. Power consumption 10 VA at 50 Hz; 8 VA at 60 Hz Catalog temperature rise 35°C at 50 Hz; 30°C at 60 Hz Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L terminal drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 81 mm AB — body span AB 92 mm B — drawing width B 59 mm BA — port-side span BA 40.5 mm C — drawing height C 124 mm D — drawing dimension D 95 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 80 mm EC — drawing dimension EC 44.5 mm F — drawing dimension F 36 mm P — fluid port thread P G1 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. Drawing check required: the source table lists A=81 mm and AB=92 mm for this terminal version. These values are reproduced exactly, although the drawing makes their relationship unclear. Confirm the approved drawing before using this combination for installation or interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 25 mm orifice, Cv 12.50 and 220 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S250LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $154.40

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L25025AI

  Specifications: 2L25025AI is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 250 identifies the orifice-size branch; port code 25 selects PT1; voltage code A selects AC220V; electrical entry is grommet / flying lead with a 0.5 m lead. The omitted thread suffix selects PT threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L25025AI will be supplied as 2LA25025AI (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L25025AI in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 250 — 25 mm orifice Port-size code 25 — PT1 Voltage code A — AC220V Electrical-entry code I — grommet / flying lead, 0.5 m Thread code Omitted — PT Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 25 mm Flow coefficient Cv 12.50 Effective flow area 220 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 1110 g = 1120 g terminal value − 10 g grommet reduction. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage AC220V Electrical entry grommet / flying lead with a 0.5 m lead Coil family listed for this valve CLA116 Supply tolerance ±15% Supply frequency 50 or 60 Hz; consumption differs with frequency. Power consumption 10 VA at 50 Hz; 8 VA at 60 Hz Catalog temperature rise 35°C at 50 Hz; 30°C at 60 Hz Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L grommet / flying-lead drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 92 mm B — drawing width B 59 mm BA — port-side span BA 40.5 mm C — drawing height C 124 mm D — drawing dimension D 95 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 80 mm EC — drawing dimension EC 44.5 mm F — drawing dimension F 36 mm P — fluid port thread P PT1 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 25 mm orifice, Cv 12.50 and 220 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S250LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $154.40

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L25025AIG

  Specifications: 2L25025AIG is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 250 identifies the orifice-size branch; port code 25 selects G1; voltage code A selects AC220V; electrical entry is grommet / flying lead with a 0.5 m lead. Thread suffix G selects G threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L25025AIG will be supplied as 2LA25025AIG (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L25025AIG in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 250 — 25 mm orifice Port-size code 25 — G1 Voltage code A — AC220V Electrical-entry code I — grommet / flying lead, 0.5 m Thread code G — G Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 25 mm Flow coefficient Cv 12.50 Effective flow area 220 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 1110 g = 1120 g terminal value − 10 g grommet reduction. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage AC220V Electrical entry grommet / flying lead with a 0.5 m lead Coil family listed for this valve CLA116 Supply tolerance ±15% Supply frequency 50 or 60 Hz; consumption differs with frequency. Power consumption 10 VA at 50 Hz; 8 VA at 60 Hz Catalog temperature rise 35°C at 50 Hz; 30°C at 60 Hz Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L grommet / flying-lead drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 92 mm B — drawing width B 59 mm BA — port-side span BA 40.5 mm C — drawing height C 124 mm D — drawing dimension D 95 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 80 mm EC — drawing dimension EC 44.5 mm F — drawing dimension F 36 mm P — fluid port thread P G1 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 25 mm orifice, Cv 12.50 and 220 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S250LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $154.40

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L25025AIT

  Specifications: 2L25025AIT is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 250 identifies the orifice-size branch; port code 25 selects NPT1; voltage code A selects AC220V; electrical entry is grommet / flying lead with a 0.5 m lead. Thread suffix T selects NPT threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L25025AIT will be supplied as 2LA25025AIT (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L25025AIT in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 250 — 25 mm orifice Port-size code 25 — NPT1 Voltage code A — AC220V Electrical-entry code I — grommet / flying lead, 0.5 m Thread code T — NPT Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 25 mm Flow coefficient Cv 12.50 Effective flow area 220 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 1110 g = 1120 g terminal value − 10 g grommet reduction. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage AC220V Electrical entry grommet / flying lead with a 0.5 m lead Coil family listed for this valve CLA116 Supply tolerance ±15% Supply frequency 50 or 60 Hz; consumption differs with frequency. Power consumption 10 VA at 50 Hz; 8 VA at 60 Hz Catalog temperature rise 35°C at 50 Hz; 30°C at 60 Hz Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L grommet / flying-lead drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 92 mm B — drawing width B 59 mm BA — port-side span BA 40.5 mm C — drawing height C 124 mm D — drawing dimension D 95 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 80 mm EC — drawing dimension EC 44.5 mm F — drawing dimension F 36 mm P — fluid port thread P NPT1 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 25 mm orifice, Cv 12.50 and 220 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S250LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $154.40

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L25025AT

  Specifications: 2L25025AT is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 250 identifies the orifice-size branch; port code 25 selects NPT1; voltage code A selects AC220V; electrical entry is terminal connector. Thread suffix T selects NPT threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L25025AT will be supplied as 2LA25025AT (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L25025AT in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 250 — 25 mm orifice Port-size code 25 — NPT1 Voltage code A — AC220V Electrical-entry code Omitted — terminal Thread code T — NPT Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 25 mm Flow coefficient Cv 12.50 Effective flow area 220 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 1120 g; terminal version. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage AC220V Electrical entry terminal connector Coil family listed for this valve CDA116 Supply tolerance ±15% Supply frequency 50 or 60 Hz; consumption differs with frequency. Power consumption 10 VA at 50 Hz; 8 VA at 60 Hz Catalog temperature rise 35°C at 50 Hz; 30°C at 60 Hz Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L terminal drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 81 mm AB — body span AB 92 mm B — drawing width B 59 mm BA — port-side span BA 40.5 mm C — drawing height C 124 mm D — drawing dimension D 95 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 80 mm EC — drawing dimension EC 44.5 mm F — drawing dimension F 36 mm P — fluid port thread P NPT1 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. Drawing check required: the source table lists A=81 mm and AB=92 mm for this terminal version. These values are reproduced exactly, although the drawing makes their relationship unclear. Confirm the approved drawing before using this combination for installation or interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 25 mm orifice, Cv 12.50 and 220 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S250LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $154.40

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L25025BG

  Specifications: 2L25025BG is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 250 identifies the orifice-size branch; port code 25 selects G1; voltage code B selects DC24V; electrical entry is terminal connector. Thread suffix G selects G threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L25025BG will be supplied as 2LA25025BG (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L25025BG in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 250 — 25 mm orifice Port-size code 25 — G1 Voltage code B — DC24V Electrical-entry code Omitted — terminal Thread code G — G Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 25 mm Flow coefficient Cv 12.50 Effective flow area 220 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 1120 g; terminal version. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage DC24V Electrical entry terminal connector Coil family listed for this valve CDA116 Supply tolerance ±10% Supply frequency DC; frequency is not applicable. Power consumption 6.5 W Catalog temperature rise 30°C Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L terminal drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 81 mm AB — body span AB 92 mm B — drawing width B 59 mm BA — port-side span BA 40.5 mm C — drawing height C 124 mm D — drawing dimension D 95 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 80 mm EC — drawing dimension EC 44.5 mm F — drawing dimension F 36 mm P — fluid port thread P G1 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. Drawing check required: the source table lists A=81 mm and AB=92 mm for this terminal version. These values are reproduced exactly, although the drawing makes their relationship unclear. Confirm the approved drawing before using this combination for installation or interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 25 mm orifice, Cv 12.50 and 220 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S250LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $154.40

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L25025BI

  Specifications: 2L25025BI is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 250 identifies the orifice-size branch; port code 25 selects PT1; voltage code B selects DC24V; electrical entry is grommet / flying lead with a 0.5 m lead. The omitted thread suffix selects PT threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L25025BI will be supplied as 2LA25025BI (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L25025BI in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 250 — 25 mm orifice Port-size code 25 — PT1 Voltage code B — DC24V Electrical-entry code I — grommet / flying lead, 0.5 m Thread code Omitted — PT Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 25 mm Flow coefficient Cv 12.50 Effective flow area 220 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 1110 g = 1120 g terminal value − 10 g grommet reduction. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage DC24V Electrical entry grommet / flying lead with a 0.5 m lead Coil family listed for this valve CLA116 Supply tolerance ±10% Supply frequency DC; frequency is not applicable. Power consumption 6.5 W Catalog temperature rise 30°C Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L grommet / flying-lead drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 92 mm B — drawing width B 59 mm BA — port-side span BA 40.5 mm C — drawing height C 124 mm D — drawing dimension D 95 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 80 mm EC — drawing dimension EC 44.5 mm F — drawing dimension F 36 mm P — fluid port thread P PT1 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 25 mm orifice, Cv 12.50 and 220 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S250LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $154.40

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L25025BIG

  Specifications: 2L25025BIG is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 250 identifies the orifice-size branch; port code 25 selects G1; voltage code B selects DC24V; electrical entry is grommet / flying lead with a 0.5 m lead. Thread suffix G selects G threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L25025BIG will be supplied as 2LA25025BIG (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L25025BIG in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 250 — 25 mm orifice Port-size code 25 — G1 Voltage code B — DC24V Electrical-entry code I — grommet / flying lead, 0.5 m Thread code G — G Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 25 mm Flow coefficient Cv 12.50 Effective flow area 220 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 1110 g = 1120 g terminal value − 10 g grommet reduction. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage DC24V Electrical entry grommet / flying lead with a 0.5 m lead Coil family listed for this valve CLA116 Supply tolerance ±10% Supply frequency DC; frequency is not applicable. Power consumption 6.5 W Catalog temperature rise 30°C Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L grommet / flying-lead drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 92 mm B — drawing width B 59 mm BA — port-side span BA 40.5 mm C — drawing height C 124 mm D — drawing dimension D 95 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 80 mm EC — drawing dimension EC 44.5 mm F — drawing dimension F 36 mm P — fluid port thread P G1 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 25 mm orifice, Cv 12.50 and 220 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S250LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $154.40

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L25025C

  Specifications: 2L25025C is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 250 identifies the orifice-size branch; port code 25 selects PT1; voltage code C selects AC110V; electrical entry is terminal connector. The omitted thread suffix selects PT threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L25025C will be supplied as 2LA25025C (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L25025C in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 250 — 25 mm orifice Port-size code 25 — PT1 Voltage code C — AC110V Electrical-entry code Omitted — terminal Thread code Omitted — PT Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 25 mm Flow coefficient Cv 12.50 Effective flow area 220 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 1120 g; terminal version. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage AC110V Electrical entry terminal connector Coil family listed for this valve CDA116 Supply tolerance ±15% Supply frequency 50 or 60 Hz; consumption differs with frequency. Power consumption 10 VA at 50 Hz; 8 VA at 60 Hz Catalog temperature rise 35°C at 50 Hz; 30°C at 60 Hz Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L terminal drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 81 mm AB — body span AB 92 mm B — drawing width B 59 mm BA — port-side span BA 40.5 mm C — drawing height C 124 mm D — drawing dimension D 95 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 80 mm EC — drawing dimension EC 44.5 mm F — drawing dimension F 36 mm P — fluid port thread P PT1 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. Drawing check required: the source table lists A=81 mm and AB=92 mm for this terminal version. These values are reproduced exactly, although the drawing makes their relationship unclear. Confirm the approved drawing before using this combination for installation or interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 25 mm orifice, Cv 12.50 and 220 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S250LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $154.40

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L25025CG

  Specifications: 2L25025CG is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 250 identifies the orifice-size branch; port code 25 selects G1; voltage code C selects AC110V; electrical entry is terminal connector. Thread suffix G selects G threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L25025CG will be supplied as 2LA25025CG (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L25025CG in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 250 — 25 mm orifice Port-size code 25 — G1 Voltage code C — AC110V Electrical-entry code Omitted — terminal Thread code G — G Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 25 mm Flow coefficient Cv 12.50 Effective flow area 220 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 1120 g; terminal version. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage AC110V Electrical entry terminal connector Coil family listed for this valve CDA116 Supply tolerance ±15% Supply frequency 50 or 60 Hz; consumption differs with frequency. Power consumption 10 VA at 50 Hz; 8 VA at 60 Hz Catalog temperature rise 35°C at 50 Hz; 30°C at 60 Hz Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L terminal drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 81 mm AB — body span AB 92 mm B — drawing width B 59 mm BA — port-side span BA 40.5 mm C — drawing height C 124 mm D — drawing dimension D 95 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 80 mm EC — drawing dimension EC 44.5 mm F — drawing dimension F 36 mm P — fluid port thread P G1 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. Drawing check required: the source table lists A=81 mm and AB=92 mm for this terminal version. These values are reproduced exactly, although the drawing makes their relationship unclear. Confirm the approved drawing before using this combination for installation or interchangeability. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 25 mm orifice, Cv 12.50 and 220 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S250LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $154.40

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L25025CI

  Specifications: 2L25025CI is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 250 identifies the orifice-size branch; port code 25 selects PT1; voltage code C selects AC110V; electrical entry is grommet / flying lead with a 0.5 m lead. The omitted thread suffix selects PT threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L25025CI will be supplied as 2LA25025CI (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L25025CI in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 250 — 25 mm orifice Port-size code 25 — PT1 Voltage code C — AC110V Electrical-entry code I — grommet / flying lead, 0.5 m Thread code Omitted — PT Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 25 mm Flow coefficient Cv 12.50 Effective flow area 220 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 1110 g = 1120 g terminal value − 10 g grommet reduction. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage AC110V Electrical entry grommet / flying lead with a 0.5 m lead Coil family listed for this valve CLA116 Supply tolerance ±15% Supply frequency 50 or 60 Hz; consumption differs with frequency. Power consumption 10 VA at 50 Hz; 8 VA at 60 Hz Catalog temperature rise 35°C at 50 Hz; 30°C at 60 Hz Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L grommet / flying-lead drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 92 mm B — drawing width B 59 mm BA — port-side span BA 40.5 mm C — drawing height C 124 mm D — drawing dimension D 95 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 80 mm EC — drawing dimension EC 44.5 mm F — drawing dimension F 36 mm P — fluid port thread P PT1 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 25 mm orifice, Cv 12.50 and 220 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S250LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $154.40

  View options

•

  View options

  Airtac 2L series: two-way fluid solenoid valve - 2L25025CIG

  Specifications: 2L25025CIG is an AirTAC 2L 2/2-way internally piloted, normally closed solenoid valve. 250 identifies the orifice-size branch; port code 25 selects G1; voltage code C selects AC110V; electrical entry is grommet / flying lead with a 0.5 m lead. Thread suffix G selects G threads. Product Catalogs and Comparison Guide Download Airtac 2L Product Catalog (PDF) Download Airtac 2LA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) New shared coil and mounting-accessory selection: 2KLA PDF page 5 (printed page 196) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2L vs 2LA: Dimensions and Replacement Guide Ordering and Delivery Orders for 2L25025CIG will be supplied as 2LA25025CIG (2LA). This is our ordering and delivery policy. It does not mean that the old and new dimensions, mounting details or electrical data are identical. The technical information below describes 2L25025CIG in the 2L catalog. For the supplied replacement, check the new catalog and comparison guide before installation. Operation and Construction This two-port, two-position valve is normally closed in its unenergized state. The valve uses internal pilot operation and requires the stated pressure differential to operate. The catalog specifies a SUS304 stainless-steel body, a PTFE (Teflon) standard seal, Class H coil insulation and IP65 coil protection. The compact construction is intended to make installation and removal convenient. Model Code Explained Code position Meaning for this model Family 2L — 2/2-way internally piloted, normally closed Size code 250 — 25 mm orifice Port-size code 25 — G1 Voltage code C — AC110V Electrical-entry code I — grommet / flying lead, 0.5 m Thread code G — G Technical Specifications Parameter Details Actuation and normal state Internally piloted; normally closed Suitable fluids Steam, high-temperature water and oil Orifice diameter 25 mm Flow coefficient Cv 12.50 Effective flow area 220 mm² Operating pressure differential 0.05–1 MPa differential (inlet pressure minus outlet pressure). Proof pressure 1.5 MPa Body material SUS304 stainless steel Standard seal PTFE (Teflon) Viscosity limit Under 20 cSt in the general specification; see the separate low-oil-temperature footnote below. Oil temperature −10 to 150°C; the −10°C entry carries a footnote stating 50 cSt or less. Water temperature 1 to 150°C Steam temperature Maximum 183°C; the minimum is not stated. Ambient temperature −20 to 100°C Catalog reference weight 1110 g = 1120 g terminal value − 10 g grommet reduction. Operating differential is the pressure difference across the valve, not an independent flow rating. The general viscosity limit and the oil-temperature footnote are both retained from the source; they must be checked together for the intended fluid. Catalog weight is a reference value; the actual product prevails. Electrical Specifications Parameter Details Rated voltage AC110V Electrical entry grommet / flying lead with a 0.5 m lead Coil family listed for this valve CLA116 Supply tolerance ±15% Supply frequency 50 or 60 Hz; consumption differs with frequency. Power consumption 10 VA at 50 Hz; 8 VA at 60 Hz Catalog temperature rise 35°C at 50 Hz; 30°C at 60 Hz Coil insulation Class H Coil protection IP65 External and Mounting Dimensions The following values are from the 2L grommet / flying-lead drawing, PDF page 4 (printed page 213). Each letter refers to its own dimension line. Values are in millimetres except threads; “—” means that the source does not list a value. Drawing reference Current configuration A — drawing length A 92 mm B — drawing width B 59 mm BA — port-side span BA 40.5 mm C — drawing height C 124 mm D — drawing dimension D 95 mm E — drawing dimension E 6.4 mm EA — drawing dimension EA 8 mm EB — drawing dimension EB 80 mm EC — drawing dimension EC 44.5 mm F — drawing dimension F 36 mm P — fluid port thread P G1 The drawing labels the mounting bracket as optional. D, E, EA, EB, EC and F are separate installation references; do not combine dimension lines into an invented overall measurement. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Flow and Performance Charts This configuration has a 25 mm orifice, Cv 12.50 and 220 mm² effective area. The catalog provides a chart labelled “Fluid: Vacuum” showing P2, upstream-pressure curves P1, a minimum-working-pressure boundary, subsonic/sonic regions and a critical-pressure boundary. Its Q axis is labelled L/min (ANR), with separate scales for Ø15, Ø20, Ø25, Ø35, Ø40 and Ø50 mm. The P2 chart reaches 1.0 MPa. The water chart plots Q in L/min against ΔP=P1−P2 in MPa; marked scales run from 0.02 to 0.5 MPa and 30 to 900 L/min. Its large intermediate curve is labelled Ø32, while the 320 ordering/specification table states a Ø35 mm orifice; retain this source distinction when reading the graph. Read the actual curve for the operating condition in the PDF. Axis maxima, plotted endpoints and other bore-size curves are not guaranteed flow ratings for this model; no interpolated flow claim is added here. Internal Structure Reference The catalog cross-section is labelled 2L150 (grommet). The numbered names below identify that reference drawing; they are not a packing list, individual ordering codes, quantities or a claim that every branch has an identical construction. Drawing item Component name 1 Body 2 Fixed ring 3 Airtight gasket 4 O-ring 5 Wear ring 6 Gasket 7 Screw 8 Spring 9 Cover 10 Spring 11 Screw 12 Spring 13 Spring washer 14 Coil assembly 15 Washer 16 E clip 17 Movable core 18 Fixed plate 19 O-ring 20 Fixed cap 21 Airtight ring 22 Plug 23 Spring 24 Piston 25 Spacer 26 O-ring Mounting Accessories and Selection The catalog accessory selection identifies F-2S250LB as the optional LB mounting bracket for this size branch. The valve drawing shows an optional bracket; the catalog does not identify it as included with the valve or list its packing quantity. Order the bracket separately when required, after confirming the mounting arrangement. Match the full voltage, electrical entry, thread and normal-state configuration. A valve series update does not establish that its old coil, connector or mounting bracket fits the new generation. Follow the flow direction shown on the body and check the exact catalog drawing before installation. Series Ordering Options The following are available choices within 2L. The current model uses only the configuration decoded above; H applies to the direct-acting 030/050 branches. Ordering position Permitted catalog choices Direct-acting branches 030: port codes 06 (1/8) or 08 (1/4); 050: 10 (3/8) or 15 (1/2). Pressure code omitted = standard; H = high pressure. Internally piloted branches 150/15 = Ø15 mm, 1/2; 200/20 = Ø20 mm, 3/4; 250/25 = Ø25 mm, 1; 320/32 = Ø35 mm, 1 1/4; 400/40 = Ø40 mm, 1 1/2; 500/50 = Ø50 mm, 2. Voltage codes A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V. Electrical-entry choices Omitted = terminal; I = grommet / flying lead, length 0.5 m. Thread choices Omitted = PT; G = G thread; T = NPT. These are alternatives, not simultaneous features.

  Read more less

  $154.40

  View options
