2LA / 2KLA Series Stainless Steel Solenoid Valve

Show previous products

•

  View options

  Airtac CDA110 series: replacement solenoid coil - CDA110KEH

  Specifications: CDA110KEH is an AirTAC 110-series solenoid coil, not a complete valve. CD specifies terminal / DIN connection; A110 identifies a 10.0 mm coil bore; E selects AC24V; H selects Class H. K selects a normally-open valve application. This exact order is listed for 2KLA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CDA110KEH: 2KLA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 10.0 mm bore, terminal / DIN entry, AC24V supply and Class H insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2KLA — normally open (NO) 2KLA030, 2KLA150, 2KLA200, 2KLA250 model groups. The K in this coil ordering code selects normally-open (NO) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The final H selects Class H, which the shared selection chart assigns to 2KLA. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 030 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CDA110KEH for the listed valve groups when AC24V, terminal / DIN entry, a 10.0 mm bore and Class H are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses a terminal connection. The new shared coil page does not assign a PL2925 or PL3030 connector code to the 110/160 family; connector compatibility must not be copied from the older 116/170 coils. A Class H coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CDA110KEH Coil-bore code A110 — 10.0 mm bore Electrical entry CD — terminal / DIN Voltage E — AC24V Valve-type position normally open (K code) Insulation suffix H — Class H Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Class H data scope: the ordering and selection charts identify this H-class coil for the valve series listed above. The shared numerical electrical matrix is labeled Class F and does not separately certify power consumption or temperature rise for this H-class order. The numerical entries below are that general catalog reference; confirm the exact H-coil nameplate and the relevant valve-specific data. Parameter Details Voltage tolerance ±15% Frequency 50 or 60 Hz Insulation class for this order H Application selected by code Normally open Power consumption — general Class F reference 15 VA at 50 Hz; 11 VA at 60 Hz Temperature rise — general Class F reference 50°C at 50 Hz; 45°C at 60 Hz These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. The exploded connector illustration identifies the screw, terminal shell, terminal core and terminal washer. The page identifies parts but does not state that a loose coil includes every connector component or provide quantities. Dimensions and Weight Parameter Details Bore diameter 10.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 100 g. The mass reference is the DOLD listing for CDA110EH, which lists an item weight of 100 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The listed normally closed coil with the same size, entry, voltage and insulation selection is used for this K normally open variant; any K-specific construction mass difference is not corrected. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $16.99

  View options

•

  View options

  Airtac CDA110 series: replacement solenoid coil - CDA110KC

  Specifications: CDA110KC is an AirTAC 110-series solenoid coil, not a complete valve. CD specifies terminal / DIN connection; A110 identifies a 10.0 mm coil bore; C selects AC110V; the omitted heat-class suffix selects Class F. K selects a normally-open valve application. This exact order is listed for 2KWA, 2KSA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CDA110KC: 2KWA, 2KSA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 10.0 mm bore, terminal / DIN entry, AC110V supply and Class F insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2KWA — normally open (NO) 2KWA030, 2KWA150, 2KWA200, 2KWA250 model groups. 2KSA — normally open (NO) 2KSA030, 2KSA150, 2KSA200, 2KSA250 model groups. The K in this coil ordering code selects normally-open (NO) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The omitted final insulation suffix selects Class F. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 030 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CDA110KC for the listed valve groups when AC110V, terminal / DIN entry, a 10.0 mm bore and Class F are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses a terminal connection. The new shared coil page does not assign a PL2925 or PL3030 connector code to the 110/160 family; connector compatibility must not be copied from the older 116/170 coils. A Class F coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CDA110KC Coil-bore code A110 — 10.0 mm bore Electrical entry CD — terminal / DIN Voltage C — AC110V Valve-type position normally open (K code) Insulation suffix Omitted — Class F Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Parameter Details Voltage tolerance ±15% Frequency 50 or 60 Hz Insulation class for this order F Application selected by code Normally open Power consumption 15 VA at 50 Hz; 11 VA at 60 Hz Catalog temperature rise 50°C at 50 Hz; 45°C at 60 Hz These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. The exploded connector illustration identifies the screw, terminal shell, terminal core and terminal washer. The page identifies parts but does not state that a loose coil includes every connector component or provide quantities. Dimensions and Weight Parameter Details Bore diameter 10.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 100 g. The mass reference is the DOLD listing for CDA110C, which lists an item weight of 100 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The listed normally closed coil with the same size, entry, voltage and insulation selection is used for this K normally open variant; any K-specific construction mass difference is not corrected. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $20.96

  View options

•

  View options

  Airtac CLA160 series: replacement solenoid coil - CLA160KEH

  Specifications: CLA160KEH is an AirTAC 160-series solenoid coil, not a complete valve. CL specifies grommet / flying-lead connection; A160 identifies a 16.0 mm coil bore; E selects AC24V; H selects Class H. K selects a normally-open valve application. This exact order is listed for 2KLA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CLA160KEH: 2KLA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 16.0 mm bore, grommet / flying-lead entry, AC24V supply and Class H insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2KLA — normally open (NO) 2KLA050, 2KLA320, 2KLA400, 2KLA500 model groups. The K in this coil ordering code selects normally-open (NO) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The final H selects Class H, which the shared selection chart assigns to 2KLA. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 050 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CLA160KEH for the listed valve groups when AC24V, grommet / flying-lead entry, a 16.0 mm bore and Class H are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses flying leads (grommet entry). The PL2925/PL3030 terminal-connector assignments are not the wiring arrangement for this CLA coil. A Class H coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CLA160KEH Coil-bore code A160 — 16.0 mm bore Electrical entry CL — grommet / flying lead Voltage E — AC24V Valve-type position normally open (K code) Insulation suffix H — Class H Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Class H data scope: the ordering and selection charts identify this H-class coil for the valve series listed above. The shared numerical electrical matrix is labeled Class F and does not separately certify power consumption or temperature rise for this H-class order. The numerical entries below are that general catalog reference; confirm the exact H-coil nameplate and the relevant valve-specific data. Parameter Details Voltage tolerance ±15% Frequency 50 or 60 Hz Insulation class for this order H Application selected by code Normally open Power consumption — general Class F reference 35 VA at 50 Hz; 30 VA at 60 Hz Temperature rise — general Class F reference 65°C at 50 Hz; 60°C at 60 Hz These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. This is the grommet / flying-lead entry. The independent coil page does not separately specify its loose-coil lead length; do not automatically transfer a complete-valve cable specification. Dimensions and Weight Parameter Details Bore diameter 16.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 260 g. The mass reference is the DOLD listing for CLA160EH, which lists an item weight of 260 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The listed normally closed coil with the same size, entry, voltage and insulation selection is used for this K normally open variant; any K-specific construction mass difference is not corrected. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $26.17

  View options

•

  View options

  Airtac CLA110 series: replacement solenoid coil - CLA110KCH

  Specifications: CLA110KCH is an AirTAC 110-series solenoid coil, not a complete valve. CL specifies grommet / flying-lead connection; A110 identifies a 10.0 mm coil bore; C selects AC110V; H selects Class H. K selects a normally-open valve application. This exact order is listed for 2KLA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CLA110KCH: 2KLA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 10.0 mm bore, grommet / flying-lead entry, AC110V supply and Class H insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2KLA — normally open (NO) 2KLA030, 2KLA150, 2KLA200, 2KLA250 model groups. The K in this coil ordering code selects normally-open (NO) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The final H selects Class H, which the shared selection chart assigns to 2KLA. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 030 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CLA110KCH for the listed valve groups when AC110V, grommet / flying-lead entry, a 10.0 mm bore and Class H are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses flying leads (grommet entry). The PL2925/PL3030 terminal-connector assignments are not the wiring arrangement for this CLA coil. A Class H coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CLA110KCH Coil-bore code A110 — 10.0 mm bore Electrical entry CL — grommet / flying lead Voltage C — AC110V Valve-type position normally open (K code) Insulation suffix H — Class H Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Class H data scope: the ordering and selection charts identify this H-class coil for the valve series listed above. The shared numerical electrical matrix is labeled Class F and does not separately certify power consumption or temperature rise for this H-class order. The numerical entries below are that general catalog reference; confirm the exact H-coil nameplate and the relevant valve-specific data. Parameter Details Voltage tolerance ±15% Frequency 50 or 60 Hz Insulation class for this order H Application selected by code Normally open Power consumption — general Class F reference 15 VA at 50 Hz; 11 VA at 60 Hz Temperature rise — general Class F reference 50°C at 50 Hz; 45°C at 60 Hz These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. This is the grommet / flying-lead entry. The independent coil page does not separately specify its loose-coil lead length; do not automatically transfer a complete-valve cable specification. Dimensions and Weight Parameter Details Bore diameter 10.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 110 g. The mass reference is the DOLD listing for CLA110CH, which lists an item weight of 110 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The listed normally closed coil with the same size, entry, voltage and insulation selection is used for this K normally open variant; any K-specific construction mass difference is not corrected. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $16.99

  View options

•

  View options

  Airtac CDA160 series: replacement solenoid coil - CDA160KA

  Specifications: CDA160KA is an AirTAC 160-series solenoid coil, not a complete valve. CD specifies terminal / DIN connection; A160 identifies a 16.0 mm coil bore; A selects AC220V; the omitted heat-class suffix selects Class F. K selects a normally-open valve application. This exact order is listed for 2KWA, 2KSA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CDA160KA: 2KWA, 2KSA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 16.0 mm bore, terminal / DIN entry, AC220V supply and Class F insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2KWA — normally open (NO) 2KWA050 model groups. 2KSA — normally open (NO) 2KSA050, 2KSA320, 2KSA400, 2KSA500 model groups. The K in this coil ordering code selects normally-open (NO) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The omitted final insulation suffix selects Class F. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 050 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CDA160KA for the listed valve groups when AC220V, terminal / DIN entry, a 16.0 mm bore and Class F are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses a terminal connection. The new shared coil page does not assign a PL2925 or PL3030 connector code to the 110/160 family; connector compatibility must not be copied from the older 116/170 coils. A Class F coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CDA160KA Coil-bore code A160 — 16.0 mm bore Electrical entry CD — terminal / DIN Voltage A — AC220V Valve-type position normally open (K code) Insulation suffix Omitted — Class F Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Parameter Details Voltage tolerance ±15% Frequency 50 or 60 Hz Insulation class for this order F Application selected by code Normally open Power consumption 35 VA at 50 Hz; 30 VA at 60 Hz Catalog temperature rise 65°C at 50 Hz; 60°C at 60 Hz These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. The exploded connector illustration identifies the screw, terminal shell, terminal core and terminal washer. The page identifies parts but does not state that a loose coil includes every connector component or provide quantities. Dimensions and Weight Parameter Details Bore diameter 16.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 250 g. The mass reference is the DOLD listing for CDA160A, which lists an item weight of 250 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The listed normally closed coil with the same size, entry, voltage and insulation selection is used for this K normally open variant; any K-specific construction mass difference is not corrected. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $28.36

  View options

•

  View options

  Airtac CLA160 series: replacement solenoid coil - CLA160KC

  Specifications: CLA160KC is an AirTAC 160-series solenoid coil, not a complete valve. CL specifies grommet / flying-lead connection; A160 identifies a 16.0 mm coil bore; C selects AC110V; the omitted heat-class suffix selects Class F. K selects a normally-open valve application. This exact order is listed for 2KWA, 2KSA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CLA160KC: 2KWA, 2KSA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 16.0 mm bore, grommet / flying-lead entry, AC110V supply and Class F insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2KWA — normally open (NO) 2KWA050 model groups. 2KSA — normally open (NO) 2KSA050, 2KSA320, 2KSA400, 2KSA500 model groups. The K in this coil ordering code selects normally-open (NO) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The omitted final insulation suffix selects Class F. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 050 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CLA160KC for the listed valve groups when AC110V, grommet / flying-lead entry, a 16.0 mm bore and Class F are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses flying leads (grommet entry). The PL2925/PL3030 terminal-connector assignments are not the wiring arrangement for this CLA coil. A Class F coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CLA160KC Coil-bore code A160 — 16.0 mm bore Electrical entry CL — grommet / flying lead Voltage C — AC110V Valve-type position normally open (K code) Insulation suffix Omitted — Class F Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Parameter Details Voltage tolerance ±15% Frequency 50 or 60 Hz Insulation class for this order F Application selected by code Normally open Power consumption 35 VA at 50 Hz; 30 VA at 60 Hz Catalog temperature rise 65°C at 50 Hz; 60°C at 60 Hz These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. This is the grommet / flying-lead entry. The independent coil page does not separately specify its loose-coil lead length; do not automatically transfer a complete-valve cable specification. Dimensions and Weight Parameter Details Bore diameter 16.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 260 g. The mass reference is the DOLD listing for CLA160C, which lists an item weight of 260 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The listed normally closed coil with the same size, entry, voltage and insulation selection is used for this K normally open variant; any K-specific construction mass difference is not corrected. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $29.59

  View options

•

  View options

  Airtac CLA110 series: replacement solenoid coil - CLA110KBH

  Specifications: CLA110KBH is an AirTAC 110-series solenoid coil, not a complete valve. CL specifies grommet / flying-lead connection; A110 identifies a 10.0 mm coil bore; B selects DC24V; H selects Class H. K selects a normally-open valve application. This exact order is listed for 2KLA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CLA110KBH: 2KLA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 10.0 mm bore, grommet / flying-lead entry, DC24V supply and Class H insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2KLA — normally open (NO) 2KLA030, 2KLA150, 2KLA200, 2KLA250 model groups. The K in this coil ordering code selects normally-open (NO) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The final H selects Class H, which the shared selection chart assigns to 2KLA. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 030 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CLA110KBH for the listed valve groups when DC24V, grommet / flying-lead entry, a 10.0 mm bore and Class H are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses flying leads (grommet entry). The PL2925/PL3030 terminal-connector assignments are not the wiring arrangement for this CLA coil. A Class H coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CLA110KBH Coil-bore code A110 — 10.0 mm bore Electrical entry CL — grommet / flying lead Voltage B — DC24V Valve-type position normally open (K code) Insulation suffix H — Class H Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Class H data scope: the ordering and selection charts identify this H-class coil for the valve series listed above. The shared numerical electrical matrix is labeled Class F and does not separately certify power consumption or temperature rise for this H-class order. The numerical entries below are that general catalog reference; confirm the exact H-coil nameplate and the relevant valve-specific data. Parameter Details Voltage tolerance ±10% Frequency DC; not applicable Insulation class for this order H Application selected by code Normally open Power consumption — general Class F reference 6.5 W Temperature rise — general Class F reference 50°C These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. This is the grommet / flying-lead entry. The independent coil page does not separately specify its loose-coil lead length; do not automatically transfer a complete-valve cable specification. Dimensions and Weight Parameter Details Bore diameter 10.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 110 g. The mass reference is the DOLD listing for CLA110BH, which lists an item weight of 110 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The listed normally closed coil with the same size, entry, voltage and insulation selection is used for this K normally open variant; any K-specific construction mass difference is not corrected. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $16.99

  View options

•

  View options

  Airtac CDA160 series: replacement solenoid coil - CDA160KF

  Specifications: CDA160KF is an AirTAC 160-series solenoid coil, not a complete valve. CD specifies terminal / DIN connection; A160 identifies a 16.0 mm coil bore; F selects DC12V; the omitted heat-class suffix selects Class F. K selects a normally-open valve application. This exact order is listed for 2KWA, 2KSA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CDA160KF: 2KWA, 2KSA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 16.0 mm bore, terminal / DIN entry, DC12V supply and Class F insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2KWA — normally open (NO) 2KWA050 model groups. 2KSA — normally open (NO) 2KSA050, 2KSA320, 2KSA400, 2KSA500 model groups. The K in this coil ordering code selects normally-open (NO) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The omitted final insulation suffix selects Class F. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 050 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CDA160KF for the listed valve groups when DC12V, terminal / DIN entry, a 16.0 mm bore and Class F are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses a terminal connection. The new shared coil page does not assign a PL2925 or PL3030 connector code to the 110/160 family; connector compatibility must not be copied from the older 116/170 coils. A Class F coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CDA160KF Coil-bore code A160 — 16.0 mm bore Electrical entry CD — terminal / DIN Voltage F — DC12V Valve-type position normally open (K code) Insulation suffix Omitted — Class F Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Parameter Details Voltage tolerance ±10% Frequency DC; not applicable Insulation class for this order F Application selected by code Normally open Power consumption 12 W Catalog temperature rise 50°C These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. The exploded connector illustration identifies the screw, terminal shell, terminal core and terminal washer. The page identifies parts but does not state that a loose coil includes every connector component or provide quantities. Dimensions and Weight Parameter Details Bore diameter 16.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 250 g. The mass reference is the DOLD listing for CDA160F, which lists an item weight of 250 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The listed normally closed coil with the same size, entry, voltage and insulation selection is used for this K normally open variant; any K-specific construction mass difference is not corrected. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $28.36

  View options

•

  View options

  Airtac CDA110 series: replacement solenoid coil - CDA110KF

  Specifications: CDA110KF is an AirTAC 110-series solenoid coil, not a complete valve. CD specifies terminal / DIN connection; A110 identifies a 10.0 mm coil bore; F selects DC12V; the omitted heat-class suffix selects Class F. K selects a normally-open valve application. This exact order is listed for 2KWA, 2KSA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CDA110KF: 2KWA, 2KSA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 10.0 mm bore, terminal / DIN entry, DC12V supply and Class F insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2KWA — normally open (NO) 2KWA030, 2KWA150, 2KWA200, 2KWA250 model groups. 2KSA — normally open (NO) 2KSA030, 2KSA150, 2KSA200, 2KSA250 model groups. The K in this coil ordering code selects normally-open (NO) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The omitted final insulation suffix selects Class F. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 030 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CDA110KF for the listed valve groups when DC12V, terminal / DIN entry, a 10.0 mm bore and Class F are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses a terminal connection. The new shared coil page does not assign a PL2925 or PL3030 connector code to the 110/160 family; connector compatibility must not be copied from the older 116/170 coils. A Class F coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CDA110KF Coil-bore code A110 — 10.0 mm bore Electrical entry CD — terminal / DIN Voltage F — DC12V Valve-type position normally open (K code) Insulation suffix Omitted — Class F Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Parameter Details Voltage tolerance ±10% Frequency DC; not applicable Insulation class for this order F Application selected by code Normally open Power consumption 6.5 W Catalog temperature rise 50°C These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. The exploded connector illustration identifies the screw, terminal shell, terminal core and terminal washer. The page identifies parts but does not state that a loose coil includes every connector component or provide quantities. Dimensions and Weight Parameter Details Bore diameter 10.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 100 g. The mass reference is the DOLD listing for CDA110F, which lists an item weight of 100 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The listed normally closed coil with the same size, entry, voltage and insulation selection is used for this K normally open variant; any K-specific construction mass difference is not corrected. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $20.96

  View options

•

  View options

  Airtac CLA110 series: replacement solenoid coil - CLA110KE

  Specifications: CLA110KE is an AirTAC 110-series solenoid coil, not a complete valve. CL specifies grommet / flying-lead connection; A110 identifies a 10.0 mm coil bore; E selects AC24V; the omitted heat-class suffix selects Class F. K selects a normally-open valve application. This exact order is listed for 2KWA, 2KSA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CLA110KE: 2KWA, 2KSA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 10.0 mm bore, grommet / flying-lead entry, AC24V supply and Class F insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2KWA — normally open (NO) 2KWA030, 2KWA150, 2KWA200, 2KWA250 model groups. 2KSA — normally open (NO) 2KSA030, 2KSA150, 2KSA200, 2KSA250 model groups. The K in this coil ordering code selects normally-open (NO) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The omitted final insulation suffix selects Class F. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 030 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CLA110KE for the listed valve groups when AC24V, grommet / flying-lead entry, a 10.0 mm bore and Class F are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses flying leads (grommet entry). The PL2925/PL3030 terminal-connector assignments are not the wiring arrangement for this CLA coil. A Class F coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CLA110KE Coil-bore code A110 — 10.0 mm bore Electrical entry CL — grommet / flying lead Voltage E — AC24V Valve-type position normally open (K code) Insulation suffix Omitted — Class F Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Parameter Details Voltage tolerance ±15% Frequency 50 or 60 Hz Insulation class for this order F Application selected by code Normally open Power consumption 15 VA at 50 Hz; 11 VA at 60 Hz Catalog temperature rise 50°C at 50 Hz; 45°C at 60 Hz These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. This is the grommet / flying-lead entry. The independent coil page does not separately specify its loose-coil lead length; do not automatically transfer a complete-valve cable specification. Dimensions and Weight Parameter Details Bore diameter 10.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 110 g. The mass reference is the DOLD listing for CLA110E, which lists an item weight of 110 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The listed normally closed coil with the same size, entry, voltage and insulation selection is used for this K normally open variant; any K-specific construction mass difference is not corrected. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $20.96

  View options

•

  View options

  Airtac CDA160 series: replacement solenoid coil - CDA160KEH

  Specifications: CDA160KEH is an AirTAC 160-series solenoid coil, not a complete valve. CD specifies terminal / DIN connection; A160 identifies a 16.0 mm coil bore; E selects AC24V; H selects Class H. K selects a normally-open valve application. This exact order is listed for 2KLA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CDA160KEH: 2KLA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 16.0 mm bore, terminal / DIN entry, AC24V supply and Class H insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2KLA — normally open (NO) 2KLA050, 2KLA320, 2KLA400, 2KLA500 model groups. The K in this coil ordering code selects normally-open (NO) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The final H selects Class H, which the shared selection chart assigns to 2KLA. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 050 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CDA160KEH for the listed valve groups when AC24V, terminal / DIN entry, a 16.0 mm bore and Class H are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses a terminal connection. The new shared coil page does not assign a PL2925 or PL3030 connector code to the 110/160 family; connector compatibility must not be copied from the older 116/170 coils. A Class H coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CDA160KEH Coil-bore code A160 — 16.0 mm bore Electrical entry CD — terminal / DIN Voltage E — AC24V Valve-type position normally open (K code) Insulation suffix H — Class H Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Class H data scope: the ordering and selection charts identify this H-class coil for the valve series listed above. The shared numerical electrical matrix is labeled Class F and does not separately certify power consumption or temperature rise for this H-class order. The numerical entries below are that general catalog reference; confirm the exact H-coil nameplate and the relevant valve-specific data. Parameter Details Voltage tolerance ±15% Frequency 50 or 60 Hz Insulation class for this order H Application selected by code Normally open Power consumption — general Class F reference 35 VA at 50 Hz; 30 VA at 60 Hz Temperature rise — general Class F reference 65°C at 50 Hz; 60°C at 60 Hz These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. The exploded connector illustration identifies the screw, terminal shell, terminal core and terminal washer. The page identifies parts but does not state that a loose coil includes every connector component or provide quantities. Dimensions and Weight Parameter Details Bore diameter 16.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 250 g. The mass reference is the DOLD listing for CDA160EH, which lists an item weight of 250 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The listed normally closed coil with the same size, entry, voltage and insulation selection is used for this K normally open variant; any K-specific construction mass difference is not corrected. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $24.93

  View options

•

  View options

  Airtac CDA160 series: replacement solenoid coil - CDA160KBH

  Specifications: CDA160KBH is an AirTAC 160-series solenoid coil, not a complete valve. CD specifies terminal / DIN connection; A160 identifies a 16.0 mm coil bore; B selects DC24V; H selects Class H. K selects a normally-open valve application. This exact order is listed for 2KLA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CDA160KBH: 2KLA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 16.0 mm bore, terminal / DIN entry, DC24V supply and Class H insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2KLA — normally open (NO) 2KLA050, 2KLA320, 2KLA400, 2KLA500 model groups. The K in this coil ordering code selects normally-open (NO) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The final H selects Class H, which the shared selection chart assigns to 2KLA. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 050 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CDA160KBH for the listed valve groups when DC24V, terminal / DIN entry, a 16.0 mm bore and Class H are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses a terminal connection. The new shared coil page does not assign a PL2925 or PL3030 connector code to the 110/160 family; connector compatibility must not be copied from the older 116/170 coils. A Class H coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CDA160KBH Coil-bore code A160 — 16.0 mm bore Electrical entry CD — terminal / DIN Voltage B — DC24V Valve-type position normally open (K code) Insulation suffix H — Class H Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Class H data scope: the ordering and selection charts identify this H-class coil for the valve series listed above. The shared numerical electrical matrix is labeled Class F and does not separately certify power consumption or temperature rise for this H-class order. The numerical entries below are that general catalog reference; confirm the exact H-coil nameplate and the relevant valve-specific data. Parameter Details Voltage tolerance ±10% Frequency DC; not applicable Insulation class for this order H Application selected by code Normally open Power consumption — general Class F reference 12 W Temperature rise — general Class F reference 50°C These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. The exploded connector illustration identifies the screw, terminal shell, terminal core and terminal washer. The page identifies parts but does not state that a loose coil includes every connector component or provide quantities. Dimensions and Weight Parameter Details Bore diameter 16.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 250 g. The mass reference is the DOLD listing for CDA160BH, which lists an item weight of 250 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The listed normally closed coil with the same size, entry, voltage and insulation selection is used for this K normally open variant; any K-specific construction mass difference is not corrected. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $24.93

  View options

•

  View options

  Airtac CDA160 series: replacement solenoid coil - CDA160KCH

  Specifications: CDA160KCH is an AirTAC 160-series solenoid coil, not a complete valve. CD specifies terminal / DIN connection; A160 identifies a 16.0 mm coil bore; C selects AC110V; H selects Class H. K selects a normally-open valve application. This exact order is listed for 2KLA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CDA160KCH: 2KLA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 16.0 mm bore, terminal / DIN entry, AC110V supply and Class H insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2KLA — normally open (NO) 2KLA050, 2KLA320, 2KLA400, 2KLA500 model groups. The K in this coil ordering code selects normally-open (NO) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The final H selects Class H, which the shared selection chart assigns to 2KLA. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 050 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CDA160KCH for the listed valve groups when AC110V, terminal / DIN entry, a 16.0 mm bore and Class H are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses a terminal connection. The new shared coil page does not assign a PL2925 or PL3030 connector code to the 110/160 family; connector compatibility must not be copied from the older 116/170 coils. A Class H coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CDA160KCH Coil-bore code A160 — 16.0 mm bore Electrical entry CD — terminal / DIN Voltage C — AC110V Valve-type position normally open (K code) Insulation suffix H — Class H Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Class H data scope: the ordering and selection charts identify this H-class coil for the valve series listed above. The shared numerical electrical matrix is labeled Class F and does not separately certify power consumption or temperature rise for this H-class order. The numerical entries below are that general catalog reference; confirm the exact H-coil nameplate and the relevant valve-specific data. Parameter Details Voltage tolerance ±15% Frequency 50 or 60 Hz Insulation class for this order H Application selected by code Normally open Power consumption — general Class F reference 35 VA at 50 Hz; 30 VA at 60 Hz Temperature rise — general Class F reference 65°C at 50 Hz; 60°C at 60 Hz These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. The exploded connector illustration identifies the screw, terminal shell, terminal core and terminal washer. The page identifies parts but does not state that a loose coil includes every connector component or provide quantities. Dimensions and Weight Parameter Details Bore diameter 16.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 250 g. The mass reference is the DOLD listing for CDA160CH, which lists an item weight of 250 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The listed normally closed coil with the same size, entry, voltage and insulation selection is used for this K normally open variant; any K-specific construction mass difference is not corrected. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $24.93

  View options

•

  View options

  Airtac CDA110 series: replacement solenoid coil - CDA110KA

  Specifications: CDA110KA is an AirTAC 110-series solenoid coil, not a complete valve. CD specifies terminal / DIN connection; A110 identifies a 10.0 mm coil bore; A selects AC220V; the omitted heat-class suffix selects Class F. K selects a normally-open valve application. This exact order is listed for 2KWA, 2KSA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CDA110KA: 2KWA, 2KSA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 10.0 mm bore, terminal / DIN entry, AC220V supply and Class F insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2KWA — normally open (NO) 2KWA030, 2KWA150, 2KWA200, 2KWA250 model groups. 2KSA — normally open (NO) 2KSA030, 2KSA150, 2KSA200, 2KSA250 model groups. The K in this coil ordering code selects normally-open (NO) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The omitted final insulation suffix selects Class F. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 030 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CDA110KA for the listed valve groups when AC220V, terminal / DIN entry, a 10.0 mm bore and Class F are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses a terminal connection. The new shared coil page does not assign a PL2925 or PL3030 connector code to the 110/160 family; connector compatibility must not be copied from the older 116/170 coils. A Class F coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CDA110KA Coil-bore code A110 — 10.0 mm bore Electrical entry CD — terminal / DIN Voltage A — AC220V Valve-type position normally open (K code) Insulation suffix Omitted — Class F Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Parameter Details Voltage tolerance ±15% Frequency 50 or 60 Hz Insulation class for this order F Application selected by code Normally open Power consumption 15 VA at 50 Hz; 11 VA at 60 Hz Catalog temperature rise 50°C at 50 Hz; 45°C at 60 Hz These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. The exploded connector illustration identifies the screw, terminal shell, terminal core and terminal washer. The page identifies parts but does not state that a loose coil includes every connector component or provide quantities. Dimensions and Weight Parameter Details Bore diameter 10.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 100 g. The mass reference is the DOLD listing for CDA110A, which lists an item weight of 100 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The listed normally closed coil with the same size, entry, voltage and insulation selection is used for this K normally open variant; any K-specific construction mass difference is not corrected. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $20.96

  View options

•

  View options

  Airtac CDA160 series: replacement solenoid coil - CDA160KB

  Specifications: CDA160KB is an AirTAC 160-series solenoid coil, not a complete valve. CD specifies terminal / DIN connection; A160 identifies a 16.0 mm coil bore; B selects DC24V; the omitted heat-class suffix selects Class F. K selects a normally-open valve application. This exact order is listed for 2KWA, 2KSA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CDA160KB: 2KWA, 2KSA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 16.0 mm bore, terminal / DIN entry, DC24V supply and Class F insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2KWA — normally open (NO) 2KWA050 model groups. 2KSA — normally open (NO) 2KSA050, 2KSA320, 2KSA400, 2KSA500 model groups. The K in this coil ordering code selects normally-open (NO) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The omitted final insulation suffix selects Class F. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 050 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CDA160KB for the listed valve groups when DC24V, terminal / DIN entry, a 16.0 mm bore and Class F are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses a terminal connection. The new shared coil page does not assign a PL2925 or PL3030 connector code to the 110/160 family; connector compatibility must not be copied from the older 116/170 coils. A Class F coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CDA160KB Coil-bore code A160 — 16.0 mm bore Electrical entry CD — terminal / DIN Voltage B — DC24V Valve-type position normally open (K code) Insulation suffix Omitted — Class F Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Parameter Details Voltage tolerance ±10% Frequency DC; not applicable Insulation class for this order F Application selected by code Normally open Power consumption 12 W Catalog temperature rise 50°C These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. The exploded connector illustration identifies the screw, terminal shell, terminal core and terminal washer. The page identifies parts but does not state that a loose coil includes every connector component or provide quantities. Dimensions and Weight Parameter Details Bore diameter 16.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 250 g. The mass reference is the DOLD listing for CDA160B, which lists an item weight of 250 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The listed normally closed coil with the same size, entry, voltage and insulation selection is used for this K normally open variant; any K-specific construction mass difference is not corrected. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $28.36

  View options

•

  View options

  Airtac CDA110 series: replacement solenoid coil - CDA110KAH

  Specifications: CDA110KAH is an AirTAC 110-series solenoid coil, not a complete valve. CD specifies terminal / DIN connection; A110 identifies a 10.0 mm coil bore; A selects AC220V; H selects Class H. K selects a normally-open valve application. This exact order is listed for 2KLA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CDA110KAH: 2KLA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 10.0 mm bore, terminal / DIN entry, AC220V supply and Class H insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2KLA — normally open (NO) 2KLA030, 2KLA150, 2KLA200, 2KLA250 model groups. The K in this coil ordering code selects normally-open (NO) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The final H selects Class H, which the shared selection chart assigns to 2KLA. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 030 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CDA110KAH for the listed valve groups when AC220V, terminal / DIN entry, a 10.0 mm bore and Class H are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses a terminal connection. The new shared coil page does not assign a PL2925 or PL3030 connector code to the 110/160 family; connector compatibility must not be copied from the older 116/170 coils. A Class H coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CDA110KAH Coil-bore code A110 — 10.0 mm bore Electrical entry CD — terminal / DIN Voltage A — AC220V Valve-type position normally open (K code) Insulation suffix H — Class H Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Class H data scope: the ordering and selection charts identify this H-class coil for the valve series listed above. The shared numerical electrical matrix is labeled Class F and does not separately certify power consumption or temperature rise for this H-class order. The numerical entries below are that general catalog reference; confirm the exact H-coil nameplate and the relevant valve-specific data. Parameter Details Voltage tolerance ±15% Frequency 50 or 60 Hz Insulation class for this order H Application selected by code Normally open Power consumption — general Class F reference 15 VA at 50 Hz; 11 VA at 60 Hz Temperature rise — general Class F reference 50°C at 50 Hz; 45°C at 60 Hz These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. The exploded connector illustration identifies the screw, terminal shell, terminal core and terminal washer. The page identifies parts but does not state that a loose coil includes every connector component or provide quantities. Dimensions and Weight Parameter Details Bore diameter 10.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 100 g. The mass reference is the DOLD listing for CDA110AH, which lists an item weight of 100 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The listed normally closed coil with the same size, entry, voltage and insulation selection is used for this K normally open variant; any K-specific construction mass difference is not corrected. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $16.99

  View options

•

  View options

  Airtac CDA110 series: replacement solenoid coil - CDA110KB

  Specifications: CDA110KB is an AirTAC 110-series solenoid coil, not a complete valve. CD specifies terminal / DIN connection; A110 identifies a 10.0 mm coil bore; B selects DC24V; the omitted heat-class suffix selects Class F. K selects a normally-open valve application. This exact order is listed for 2KWA, 2KSA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CDA110KB: 2KWA, 2KSA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 10.0 mm bore, terminal / DIN entry, DC24V supply and Class F insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2KWA — normally open (NO) 2KWA030, 2KWA150, 2KWA200, 2KWA250 model groups. 2KSA — normally open (NO) 2KSA030, 2KSA150, 2KSA200, 2KSA250 model groups. The K in this coil ordering code selects normally-open (NO) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The omitted final insulation suffix selects Class F. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 030 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CDA110KB for the listed valve groups when DC24V, terminal / DIN entry, a 10.0 mm bore and Class F are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses a terminal connection. The new shared coil page does not assign a PL2925 or PL3030 connector code to the 110/160 family; connector compatibility must not be copied from the older 116/170 coils. A Class F coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CDA110KB Coil-bore code A110 — 10.0 mm bore Electrical entry CD — terminal / DIN Voltage B — DC24V Valve-type position normally open (K code) Insulation suffix Omitted — Class F Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Parameter Details Voltage tolerance ±10% Frequency DC; not applicable Insulation class for this order F Application selected by code Normally open Power consumption 6.5 W Catalog temperature rise 50°C These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. The exploded connector illustration identifies the screw, terminal shell, terminal core and terminal washer. The page identifies parts but does not state that a loose coil includes every connector component or provide quantities. Dimensions and Weight Parameter Details Bore diameter 10.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 100 g. The mass reference is the DOLD listing for CDA110B, which lists an item weight of 100 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The listed normally closed coil with the same size, entry, voltage and insulation selection is used for this K normally open variant; any K-specific construction mass difference is not corrected. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $20.96

  View options

•

  View options

  Airtac CLA160 series: replacement solenoid coil - CLA160FH

  Specifications: CLA160FH is an AirTAC 160-series solenoid coil, not a complete valve. CL specifies grommet / flying-lead connection; A160 identifies a 16.0 mm coil bore; F selects DC12V; H selects Class H. The omitted valve-type code selects a normally-closed valve application. This exact order is listed for 2LA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CLA160FH: 2LA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 16.0 mm bore, grommet / flying-lead entry, DC12V supply and Class H insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2LA — normally closed (NC) 2LA050, 2LA320, 2LA400, 2LA500 model groups. The valve-type position in this coil ordering code is blank, selecting normally-closed (NC) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The final H selects Class H, which the shared selection chart assigns to 2LA. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 050 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CLA160FH for the listed valve groups when DC12V, grommet / flying-lead entry, a 16.0 mm bore and Class H are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses flying leads (grommet entry). The PL2925/PL3030 terminal-connector assignments are not the wiring arrangement for this CLA coil. A Class H coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CLA160FH Coil-bore code A160 — 16.0 mm bore Electrical entry CL — grommet / flying lead Voltage F — DC12V Valve-type position normally closed (omitted valve-type code) Insulation suffix H — Class H Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Class H data scope: the ordering and selection charts identify this H-class coil for the valve series listed above. The shared numerical electrical matrix is labeled Class F and does not separately certify power consumption or temperature rise for this H-class order. The numerical entries below are that general catalog reference; confirm the exact H-coil nameplate and the relevant valve-specific data. Parameter Details Voltage tolerance ±10% Frequency DC; not applicable Insulation class for this order H Application selected by code Normally closed Power consumption — general Class F reference 12 W Temperature rise — general Class F reference 50°C These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. This is the grommet / flying-lead entry. The independent coil page does not separately specify its loose-coil lead length; do not automatically transfer a complete-valve cable specification. Dimensions and Weight Parameter Details Bore diameter 16.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 260 g. The mass reference is the DOLD listing for CLA160FH, which lists an item weight of 260 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The selected complete SKU matches the supplier record. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $26.17

  View options

•

  View options

  Airtac CLA160 series: replacement solenoid coil - CLA160EH

  Specifications: CLA160EH is an AirTAC 160-series solenoid coil, not a complete valve. CL specifies grommet / flying-lead connection; A160 identifies a 16.0 mm coil bore; E selects AC24V; H selects Class H. The omitted valve-type code selects a normally-closed valve application. This exact order is listed for 2LA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CLA160EH: 2LA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 16.0 mm bore, grommet / flying-lead entry, AC24V supply and Class H insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2LA — normally closed (NC) 2LA050, 2LA320, 2LA400, 2LA500 model groups. The valve-type position in this coil ordering code is blank, selecting normally-closed (NC) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The final H selects Class H, which the shared selection chart assigns to 2LA. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 050 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CLA160EH for the listed valve groups when AC24V, grommet / flying-lead entry, a 16.0 mm bore and Class H are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses flying leads (grommet entry). The PL2925/PL3030 terminal-connector assignments are not the wiring arrangement for this CLA coil. A Class H coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CLA160EH Coil-bore code A160 — 16.0 mm bore Electrical entry CL — grommet / flying lead Voltage E — AC24V Valve-type position normally closed (omitted valve-type code) Insulation suffix H — Class H Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Class H data scope: the ordering and selection charts identify this H-class coil for the valve series listed above. The shared numerical electrical matrix is labeled Class F and does not separately certify power consumption or temperature rise for this H-class order. The numerical entries below are that general catalog reference; confirm the exact H-coil nameplate and the relevant valve-specific data. Parameter Details Voltage tolerance ±15% Frequency 50 or 60 Hz Insulation class for this order H Application selected by code Normally closed Power consumption — general Class F reference 25 VA at 50 Hz; 22 VA at 60 Hz Temperature rise — general Class F reference 65°C at 50 Hz; 60°C at 60 Hz These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. This is the grommet / flying-lead entry. The independent coil page does not separately specify its loose-coil lead length; do not automatically transfer a complete-valve cable specification. Dimensions and Weight Parameter Details Bore diameter 16.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 260 g. The mass reference is the DOLD listing for CLA160EH, which lists an item weight of 260 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The selected complete SKU matches the supplier record. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $26.17

  View options

•

  View options

  Airtac CLA160 series: replacement solenoid coil - CLA160CH

  Specifications: CLA160CH is an AirTAC 160-series solenoid coil, not a complete valve. CL specifies grommet / flying-lead connection; A160 identifies a 16.0 mm coil bore; C selects AC110V; H selects Class H. The omitted valve-type code selects a normally-closed valve application. This exact order is listed for 2LA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CLA160CH: 2LA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 16.0 mm bore, grommet / flying-lead entry, AC110V supply and Class H insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2LA — normally closed (NC) 2LA050, 2LA320, 2LA400, 2LA500 model groups. The valve-type position in this coil ordering code is blank, selecting normally-closed (NC) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The final H selects Class H, which the shared selection chart assigns to 2LA. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 050 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CLA160CH for the listed valve groups when AC110V, grommet / flying-lead entry, a 16.0 mm bore and Class H are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses flying leads (grommet entry). The PL2925/PL3030 terminal-connector assignments are not the wiring arrangement for this CLA coil. A Class H coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CLA160CH Coil-bore code A160 — 16.0 mm bore Electrical entry CL — grommet / flying lead Voltage C — AC110V Valve-type position normally closed (omitted valve-type code) Insulation suffix H — Class H Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Class H data scope: the ordering and selection charts identify this H-class coil for the valve series listed above. The shared numerical electrical matrix is labeled Class F and does not separately certify power consumption or temperature rise for this H-class order. The numerical entries below are that general catalog reference; confirm the exact H-coil nameplate and the relevant valve-specific data. Parameter Details Voltage tolerance ±15% Frequency 50 or 60 Hz Insulation class for this order H Application selected by code Normally closed Power consumption — general Class F reference 25 VA at 50 Hz; 22 VA at 60 Hz Temperature rise — general Class F reference 65°C at 50 Hz; 60°C at 60 Hz These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. This is the grommet / flying-lead entry. The independent coil page does not separately specify its loose-coil lead length; do not automatically transfer a complete-valve cable specification. Dimensions and Weight Parameter Details Bore diameter 16.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 260 g. The mass reference is the DOLD listing for CLA160CH, which lists an item weight of 260 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The selected complete SKU matches the supplier record. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $26.17

  View options

•

  View options

  Airtac CLA160 series: replacement solenoid coil - CLA160BH

  Specifications: CLA160BH is an AirTAC 160-series solenoid coil, not a complete valve. CL specifies grommet / flying-lead connection; A160 identifies a 16.0 mm coil bore; B selects DC24V; H selects Class H. The omitted valve-type code selects a normally-closed valve application. This exact order is listed for 2LA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CLA160BH: 2LA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 16.0 mm bore, grommet / flying-lead entry, DC24V supply and Class H insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2LA — normally closed (NC) 2LA050, 2LA320, 2LA400, 2LA500 model groups. The valve-type position in this coil ordering code is blank, selecting normally-closed (NC) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The final H selects Class H, which the shared selection chart assigns to 2LA. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 050 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CLA160BH for the listed valve groups when DC24V, grommet / flying-lead entry, a 16.0 mm bore and Class H are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses flying leads (grommet entry). The PL2925/PL3030 terminal-connector assignments are not the wiring arrangement for this CLA coil. A Class H coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CLA160BH Coil-bore code A160 — 16.0 mm bore Electrical entry CL — grommet / flying lead Voltage B — DC24V Valve-type position normally closed (omitted valve-type code) Insulation suffix H — Class H Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Class H data scope: the ordering and selection charts identify this H-class coil for the valve series listed above. The shared numerical electrical matrix is labeled Class F and does not separately certify power consumption or temperature rise for this H-class order. The numerical entries below are that general catalog reference; confirm the exact H-coil nameplate and the relevant valve-specific data. Parameter Details Voltage tolerance ±10% Frequency DC; not applicable Insulation class for this order H Application selected by code Normally closed Power consumption — general Class F reference 12 W Temperature rise — general Class F reference 50°C These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. This is the grommet / flying-lead entry. The independent coil page does not separately specify its loose-coil lead length; do not automatically transfer a complete-valve cable specification. Dimensions and Weight Parameter Details Bore diameter 16.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 260 g. The mass reference is the DOLD listing for CLA160BH, which lists an item weight of 260 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The selected complete SKU matches the supplier record. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $26.17

  View options

•

  View options

  Airtac CLA160 series: replacement solenoid coil - CLA160AH

  Specifications: CLA160AH is an AirTAC 160-series solenoid coil, not a complete valve. CL specifies grommet / flying-lead connection; A160 identifies a 16.0 mm coil bore; A selects AC220V; H selects Class H. The omitted valve-type code selects a normally-closed valve application. This exact order is listed for 2LA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CLA160AH: 2LA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 16.0 mm bore, grommet / flying-lead entry, AC220V supply and Class H insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2LA — normally closed (NC) 2LA050, 2LA320, 2LA400, 2LA500 model groups. The valve-type position in this coil ordering code is blank, selecting normally-closed (NC) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The final H selects Class H, which the shared selection chart assigns to 2LA. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 050 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CLA160AH for the listed valve groups when AC220V, grommet / flying-lead entry, a 16.0 mm bore and Class H are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses flying leads (grommet entry). The PL2925/PL3030 terminal-connector assignments are not the wiring arrangement for this CLA coil. A Class H coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CLA160AH Coil-bore code A160 — 16.0 mm bore Electrical entry CL — grommet / flying lead Voltage A — AC220V Valve-type position normally closed (omitted valve-type code) Insulation suffix H — Class H Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Class H data scope: the ordering and selection charts identify this H-class coil for the valve series listed above. The shared numerical electrical matrix is labeled Class F and does not separately certify power consumption or temperature rise for this H-class order. The numerical entries below are that general catalog reference; confirm the exact H-coil nameplate and the relevant valve-specific data. Parameter Details Voltage tolerance ±15% Frequency 50 or 60 Hz Insulation class for this order H Application selected by code Normally closed Power consumption — general Class F reference 25 VA at 50 Hz; 22 VA at 60 Hz Temperature rise — general Class F reference 65°C at 50 Hz; 60°C at 60 Hz These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. This is the grommet / flying-lead entry. The independent coil page does not separately specify its loose-coil lead length; do not automatically transfer a complete-valve cable specification. Dimensions and Weight Parameter Details Bore diameter 16.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 260 g. The mass reference is the DOLD listing for CLA160AH, which lists an item weight of 260 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The selected complete SKU matches the supplier record. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $26.17

  View options

•

  View options

  Airtac CLA160 series: replacement solenoid coil - CLA160F

  Specifications: CLA160F is an AirTAC 160-series solenoid coil, not a complete valve. CL specifies grommet / flying-lead connection; A160 identifies a 16.0 mm coil bore; F selects DC12V; the omitted heat-class suffix selects Class F. The omitted valve-type code selects a normally-closed valve application. This exact order is listed for 2WA, 2SA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CLA160F: 2WA, 2SA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 16.0 mm bore, grommet / flying-lead entry, DC12V supply and Class F insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2WA — normally closed (NC) 2WA050 model groups. 2SA — normally closed (NC) 2SA050, 2SA320, 2SA400, 2SA500 model groups. The valve-type position in this coil ordering code is blank, selecting normally-closed (NC) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The omitted final insulation suffix selects Class F. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 050 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CLA160F for the listed valve groups when DC12V, grommet / flying-lead entry, a 16.0 mm bore and Class F are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses flying leads (grommet entry). The PL2925/PL3030 terminal-connector assignments are not the wiring arrangement for this CLA coil. A Class F coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CLA160F Coil-bore code A160 — 16.0 mm bore Electrical entry CL — grommet / flying lead Voltage F — DC12V Valve-type position normally closed (omitted valve-type code) Insulation suffix Omitted — Class F Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Parameter Details Voltage tolerance ±10% Frequency DC; not applicable Insulation class for this order F Application selected by code Normally closed Power consumption 12 W Catalog temperature rise 50°C These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. This is the grommet / flying-lead entry. The independent coil page does not separately specify its loose-coil lead length; do not automatically transfer a complete-valve cable specification. Dimensions and Weight Parameter Details Bore diameter 16.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 260 g. The mass reference is the DOLD listing for CLA160F, which lists an item weight of 260 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The selected complete SKU matches the supplier record. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $29.59

  View options

•

  View options

  Airtac CLA160 series: replacement solenoid coil - CLA160E

  Specifications: CLA160E is an AirTAC 160-series solenoid coil, not a complete valve. CL specifies grommet / flying-lead connection; A160 identifies a 16.0 mm coil bore; E selects AC24V; the omitted heat-class suffix selects Class F. The omitted valve-type code selects a normally-closed valve application. This exact order is listed for 2WA, 2SA; applicable size groups and connection conditions are listed below. Product Catalogs and Comparison Guide Download Airtac 2KL Product Catalog (PDF) Download Airtac 2KLA Product Catalog (PDF) Legacy coil and mounting-accessory selection: catalog page 205 (PDF) Download Original Product Reference (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. AirTAC 2KL vs 2KLA: Dimensions and Replacement Guide The valve catalogs and comparison guide provide series background. They do not turn this separately ordered component into a complete valve or establish an automatic component replacement. Applicable Valve Series and Ordering Check Applicable valve series for CLA160E: 2WA, 2SA. Only the model groups in the table below are listed for this exact coil selection. The coil has a 16.0 mm bore, grommet / flying-lead entry, AC24V supply and Class F insulation. Match all four conditions to the valve and existing coil. Valve series and normal state Applicable valve model groups 2WA — normally closed (NC) 2WA050 model groups. 2SA — normally closed (NC) 2SA050, 2SA320, 2SA400, 2SA500 model groups. The valve-type position in this coil ordering code is blank, selecting normally-closed (NC) service. The table above has already been restricted to that normal state and this order's insulation class. Do not treat the combined NC/NO columns in the general selection chart as an interchangeable coil list. The omitted final insulation suffix selects Class F. The reference is the shared "Coil and accessories" page in the supplied 2KLA catalog, PDF page 5, printed page 196; that page explicitly covers multiple valve series. These are model-group names, not complete valve ordering codes. The 050 groups in the selection chart include an intervening pressure-option position. Keep any such pressure option and all port, thread, voltage and electrical-entry suffixes of the actual valve order. The other model groups listed above are discrete catalog codes, not a continuous numerical range. Ordering check: order CLA160E for the listed valve groups when AC24V, grommet / flying-lead entry, a 16.0 mm bore and Class F are required. Confirm the complete valve code, installed coil marking and normal state before replacement. This order uses flying leads (grommet entry). The PL2925/PL3030 terminal-connector assignments are not the wiring arrangement for this CLA coil. A Class F coil is not automatically interchangeable with another insulation class or generation. The older 116/170 bores are 11.6/17.0 mm; the newer 110/160 bores are 10.0/16.0 mm. These physical differences prevent a simple “add A” coil substitution. Component Identity and Ordering Parameter Details Product type Separately ordered solenoid coil Current ordering code CLA160E Coil-bore code A160 — 16.0 mm bore Electrical entry CL — grommet / flying lead Voltage E — AC24V Valve-type position normally closed (omitted valve-type code) Insulation suffix Omitted — Class F Automatic replacement No automatic A-suffix conversion is established for coils. Confirm the valve, bore, voltage, normal state and insulation class. Coil Electrical Data Parameter Details Voltage tolerance ±15% Frequency 50 or 60 Hz Insulation class for this order F Application selected by code Normally closed Power consumption 25 VA at 50 Hz; 22 VA at 60 Hz Catalog temperature rise 65°C at 50 Hz; 60°C at 60 Hz These are the independent coil-page values, not values copied from a complete valve. Pressure, fluid temperature, valve-body material and valve flow coefficient are not specifications of this loose coil. No separate coil weight is listed. The general coil specification table is headed Class F, while its ordering and selection tables also offer Class H. It does not provide a separate complete power/temperature-rise matrix for H variants. The 2KLA valve-specific pages additionally differ from the general normally-open power table. Confirm the nameplate of the exact coil before substituting it into a valve. Connection and Components The hookup drawing places the coil across numbered terminals 1 and 2 for the shown AC/DC connection. Match the ordered voltage and follow the source diagram. This is the grommet / flying-lead entry. The independent coil page does not separately specify its loose-coil lead length; do not automatically transfer a complete-valve cable specification. Dimensions and Weight Parameter Details Bore diameter 16.0 mm Separate coil envelope dimensions Not listed in this supplied coil page Separate coil weight Not listed; no complete-valve mass is substituted For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Coil Ordering Options Parameter Details Connection CD = terminal; CL = grommet Bore family A110 = Ø10.0 mm; A160 = Ø16.0 mm Valve-type code Omitted = normally closed; K = normally open Voltage A = AC220V; B = DC24V; C = AC110V; E = AC24V; F = DC12V Heat-class code Omitted = Class F; H = Class H Reference Weight Estimated reference weight: 260 g. The mass reference is the DOLD listing for CLA160E, which lists an item weight of 260 g. This is a supplier listing reference, not an AirTAC catalog net-weight specification. The selected complete SKU matches the supplier record. This is a reference estimate, not a manufacturer-published weight for this exact configuration or an individually measured or packaged shipping weight. Actual supplied mass can differ.

  Read more less

  $29.59

  View options

Show more products
