Pressure Gauge
Product Features
- Responsive, sensitive, and low pressure drop.
- The dial markings are clear, and a variety of pressure units are available for selection.
- A variety of installation accessories are available for selection.
- A variety of connection port sizes are available.
Specifications
| Model | GS-30 | GS-40, GF-40, GU-40 | GS-50, GF-50, GU-50 | GF-60, GU-60 | |
|---|---|---|---|---|---|
| Working Medium | Air | ||||
| Port Size | PT1/16 | PT1/8 | PT1/4 | PT1/4 | |
| Operating Temperature Range | -40–70°C | ||||
| Accuracy Class | 2.5 grade | ||||
| Pressure Unit & Indication Range | M | 0–1.0MPa (Standard); 0–0.4MPa (Low Pressure) | |||
| B | 0–10 bar (Standard); 0–4 bar (Low Pressure) | ||||
| P | 0–140psi (Standard); 0–60psi (Low Pressure) | ||||
| Z | 0–10kgf/cm² and 0–140psi (Dual scale display) (Standard) 0–4kgf/cm² and 0–60psi (Dual scale display) (Low Pressure) |
||||
| Main Component Material | Casing: SPCC; Dial: Brass | ||||
| Model | GP-30 | GP-40 | |
|---|---|---|---|
| Working Medium | Air | ||
| Port Size | PT1/8 | PT1/8 | |
| Operating Temperature Range | -40–70°C | ||
| Accuracy Class | 2.5 grade | ||
| Pressure Unit & Indication Range | P | 0–1.0MPa & 0–140psi (Standard) 0–0.4MPa & 0–60psi (Medium Pressure) 0–0.2MPa & 0–30psi (Low Pressure) |
|
| G | 0–10bar & 0–1.0MPa (Standard) 0–4bar & 0–0.4MPa (Medium Pressure) 0–2bar & 0–0.2MPa (Low Pressure) |
||
| T | 0–10bar & 0–140psi (Standard) 0–4bar & 0–60psi (Medium Pressure) 0–2bar & 0–30psi (Low Pressure) |
||
| Main Component Material | Casing: Stainless Steel; Dial: Aluminum | ||
Product Ordering Code
GS/GF/GU Series
| Position | Description | Options & Values |
|---|---|---|
| 1 | Accessory Code |
|
| 2 | Series Code |
|
| 3 | Mounting Style Code |
|
| 4 | Dial Specification Code |
|
| 5 | Max Display Pressure Value |
|
| 6 | Pressure Scale Unit and Thread |
|
GP Series
| Position | Description | Options & Values |
|---|---|---|
| 1 | Accessory Code |
|
| 2 | Series Code |
|
| 3 | Mounting Style Code |
|
| 4 | Dial Specification Code |
|
| 5 | Max Display Pressure Value |
|
| 6 | Pressure Scale Unit and Thread |
|
