Description
Specifications: double-shaft compound stroke adjustable type (large cylinder diameter) Bore: 250mm Stroke: 336mm Adjusting stroke: 20mm Magnet: no magnet Fixed type: none Seal material: fluorine rubber Tooth type: PT tooth
Click to download Airtac product catalog
Product Features
1.ISO6430 standard cylinder.
2. The piston seal adopts special-shaped two-way sealing structure, compact size and oil storage function.
3. For the tie rod cylinder, the front and rear cover and aluminum tube cylinder with pillar connection, good reliability.
4. Compared with ISO15552 standard cylinders, the length of SC series cylinders with the same bore is small.
5. The cylinder buffer adjustment is stable.
6. Optional induction magnet, easy to install the sensor flexible.
7. Various specifications of the cylinder and installation accessories for selection.
8. Select high temperature resistant sealing material, can ensure the normal operation of the cylinder under the condition of 150°C.
