Specifications: Magnetic coupling rod-less cylinder Installation type: size F type Cylinder diameter: 40mm Stroke: 100mm Fixed type: foot seat fixed frame Tooth type: NPT tooth
Specifications
1. Model: RMSF40X100LBT
2. Action type: double action type, working medium: air (filtered by filter screen above 40μm)
3. Use pressure range: 0.15~0.7MPa(22~100psi)(1.5~7bar), Guaranteed pressure resistance: 1.2MPa(175psi)(12.0bar)
4. Working temperature ℃ :-20~70, Use speed range mm/s:50~400, Travel tolerance range mm:0~250+0/1.0,251~1000+0/1.5,1001~+0/2.0
5. Buffer type: adjustable buffer + fixed buffer, nozzle diameter: PT1/4, Safety retention force N:880
6. The nozzle type has G teeth and NPT teeth to choose from; When stopping in the middle, the maximum service pressure shall not exceed 0.55MPa, and both ends shall be buffered when stopping.
Internal structure and main parts material: 1. Guide rod end cover: aluminum alloy/2. Piston: Aluminum alloy/3. Piston O: TPU/4. Magnet spacer: fast cutting steel/5. Magnets: rare earth materials/6. Magnet spacer: fast cutting steel/7. Body: aluminum alloy/8. Wear ring: wear resistant material/9. Scraper ring: plastic/10.C-shaped buckle ring: spring steel/11. Stainless steel pipe: stainless steel/12. Buffer O order: TPU/13. Flat washer: Stainless steel/14. End cap: aluminum alloy/15. Magnets: rare earth materials/16. Connecting rod: Stainless steel/17. Wear ring: wear resistant material/18. Anti-collision pad: NBR/19. Nut: Stainless steel
Installation accessories :F-RMSF40LB Axial mounting
Click to download Airtac product catalog
Product Features
1. Magnetic coupling type rod-less cylinder, no mechanical connection between the piston and the slider, excellent sealing performance.
2. The action of the piston is transmitted to the external slider through the magnetic coupling force, without the need for a piston rod, the installation space is less than that of an ordinary cylinder, and the maximum stroke is larger than that of an ordinary cylinder.
3. Both ends of the cylinder with adjustable buffer and fixed buffer device, the reversing action is smooth and no impact, while avoiding mechanical damage.
4. The piston cavity is separated from the slider to prevent dust and dirt from entering the system and extend the service life of the cylinder.
