Airtac ASL series: elbow one-way speed controller - ASL10-02B

Photos are for reference only. Not all models have pictures.

Description

Specifications: AirTAC ASL10-02B is an elbow one-way speed controller. 10 mm × 1 tube connection(s); PT 1/4 (catalogue PT designation).

Product Catalog

Download Airtac Product Catalog (PDF)

For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

Model code explained

Code Meaning
ASL Elbow one-way speed controller
10 Tube outside diameter 10 mm
02 Fluid-port thread PT 1/4
B Meter-in (inlet throttling)

Technical specifications

Parameter Details
Series / form Elbow one-way speed controller
Working medium Air
Operating pressure 0–1.02 MPa (0–145 psi), as printed
Proof pressure 1.53 MPa (218 psi), as printed
Operating temperature −5 to 60 °C
Applicable tubing Nylon or polyurethane (PU), at the specified outside diameter
Control direction Meter-in: inlet throttling

Connections and drawing dimensions

Parameter Details
Tube outside diameter ØD 10 mm × 1 tube connection(s)
Male fluid-port thread PT 1/4 (catalogue PT designation)

These are the dimensions actually tabulated for this model in the supplied catalogue. The page does not provide numerical overall length, height, wrench size, installation clearance, or a dimensioned internal section. Those values have not been inferred from the photograph.

For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

Function and application

  • The one-way throttling circuit combines adjustable restriction in the selected direction with reverse flow. Select the current meter-in or meter-out version according to the circuit; the linked page does not give a rated flow curve or adjustment-turn data.
  • The supplied material does not name a dedicated compatible valve, cylinder or machine series for this fitting. Applicability is defined by the listed connections and the confirmed service conditions; no series-wide interchangeability is implied.

Construction and materials

The source shows the external form and connection arrangement but does not publish a numbered internal component list or material grades for this family. The appearance of a part in the photograph is not used to assign a metal, plastic or seal specification.

Series selection reference

The following family forms are listed in the same supplied PDF. Their connection matrices and options are separate; this list is not a compatibility declaration.

Series Published form
ASA In-line one-way speed controller
ASL Elbow one-way speed controller
AJSS Universal one-way speed controller
APA Tube-to-tube one-way speed controller
APAM Bulkhead tube-to-tube one-way speed controller

Reference weight

Estimated product weight: 35 g. This is a reference estimate, not an official AirTAC net weight or a measured product weight. Packaging is excluded; it is not the packed shipping weight.

Source details

Product information: linked legacy catalogue PDF page 1, printed page 78. Only the connection dimensions and characteristics printed for this family are represented as product data. The separate modern-series mass reference is used only for the labelled weight estimate.
