Specifications: MPG16X15NFA is an AirTAC double-acting cylinder with a 16 mm bore, 15 mm stroke, no magnetic option in the standard suffix position, and smooth rod end. The FA suffix selects front flange.
Product Catalog
Download Airtac Product Catalog (PDF)
Download 2022 mounting brackets (PDF)
Download 2022 cylinder installation and weight tables (PDF)
For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.
Model Code Explained
| Code |
Meaning for This Model |
| MPG |
double-acting cylinder |
| 16 |
16 mm bore |
| X15 |
15 mm nominal stroke |
| Blank magnetic position |
No magnetic piston selected by the standard order-code position |
| N |
smooth rod end |
| FA |
front flange |
Technical Specifications
| Parameter |
Details |
| Action |
double-acting cylinder |
| Working medium |
Air filtered through a 40 μm filter or finer |
| Operating pressure |
0.15–0.7 MPa |
| Proof pressure |
1.2 MPa; a proof-test rating, not the continuous operating limit |
| Ambient and fluid temperature |
−20 to 70 °C |
| Piston speed |
30–500 mm/s |
| Stroke tolerance |
+1.0 / 0 mm |
| Cushioning |
Bumper |
| Air connection |
M5 × 0.8 |
| Maximum panel thickness |
5 mm |
| Body-thread tightening torque |
34 N·m |
| Rod-end tightening torque |
1.6 N·m |
Product Features
- The compact, low-mass cylinder is designed for convenient installation and removal.
- Accurate rod guidance and a rubber-coated rear cover support compact operation without an additional lubricator.
- The magnetic version provides position sensing through the body switch groove.
Dimensions for This Bore and Configuration
Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 164–167 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship.
| Parameter |
Details |
| A |
43.5 mm |
| AB |
24 mm |
| AC |
19.5 mm |
| B |
20 mm |
| C |
24.5 mm |
| CA |
10 mm |
| D |
6 mm |
| DA |
14 mm |
| G |
19 mm |
| GA |
4 mm |
| M |
M14 × 1.0 |
| MA |
10 mm |
| P |
M5 × 0.8 |
| PA |
6.5 mm |
| PB |
7.5 mm |
| R |
3 mm |
| Rod end E |
Smooth; no e × ternal thread |
| Reference male-rod EA |
12 mm |
| Reference male-rod F |
8 mm |
| Reference male-rod FA |
3 mm |
Stroke-dependent Drawing Relationships
| Parameter |
Details |
| A outline |
A + stroke |
| AC outline |
AC + stroke |
| Stroke used in the order code |
15 mm |
N selects an unthreaded rod. EA, F and FA retained from the male-rod reference view describe the thread/nut callouts, not a supplied external thread or rod nut on the N variant.
Construction and Materials
| Parameter |
Details |
| 1 Hex nut |
Stainless steel |
| 2 Piston rod |
Stainless steel |
| 3 Rod seal |
NBR |
| 4 Body nut |
Carbon steel |
| 5 Body |
Aluminum alloy |
| 6 Bumper |
TPU |
| 7 Piston seal |
NBR |
| 8 Piston |
Aluminum alloy |
| 9 Retaining ring |
Spring steel |
| 10 Rear cover |
Rubber-coated aluminum alloy |
| 11 Magnet holder |
Magnetic-option component; not fitted in a non-magnetic configuration |
| 12 Magnet washer |
Magnetic-option component; not fitted in a non-magnetic configuration |
| 13 Magnet |
Magnetic-option component; not fitted in a non-magnetic configuration |
Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities.
Matching Accessories and Mounting
| Parameter |
Details |
| F-MPG16LB |
foot bracket for MPG 16 mm bore |
| F-MPG16FA |
front flange for MPG 16 mm bore |
| F-MPG16FC |
flat-face bumper cap in POM; catalog option for male-threaded rod versions only, not for this smooth-rod N model |
| F-MPG16RC |
spherical-face bumper cap in POM; catalog option for male-threaded rod versions only, not for this smooth-rod N model |
| Magnetic switch condition |
This code does not select a magnetic piston. A magnetic switch cannot provide piston-position sensing on a non-magnetic cylinder. |
Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities.
Selected FA Mounting Dimensions
| Parameter |
Details |
| A |
36 mm |
| B |
49 mm |
| C |
22 mm |
| D |
5.5 mm |
| E |
2.5 mm |
| F |
25.5 mm |
Letters in this table belong to the FA accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths.
Stroke and Option Selection
| Parameter |
Details |
| Standard strokes for this bore/action |
5, 10, 15, 20, 25, 30, 35, 40 mm |
| Intermediate strokes |
Use the listed standard strokes and the dimensions for the selected stroke. |
| Magnetic selection |
Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. |
Selection, Installation and Operation
- Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder.
- Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide.
- Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication.
- Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping.
- Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation.
Circuit Selection Reference at 500 mm/s
| Parameter |
Details |
| Reference bore |
16 mm |
| Effective flow area at the reference speed |
.5 mm² |
| Tube outside / inside diameter |
4 / 2.5 mm |
| Example speed controller |
PTLM5 |
| Example silencer |
BSLM5 |
| Example solenoid valves |
5V110M5 / 5V120M5 |
| Example air-piloted valves |
4A110M5 / 4A120M5 |
The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions.
Side-load Curve
The MPG graph plots allowable side force against stroke: the horizontal axis spans 0–45 mm and the vertical axis 0–1 N. Use the curve for the selected bore. A scale endpoint is not an allowable load for every stroke; the rod must not be used as a general-purpose lateral guide.
Optional circuit connections and complete valve codes
For the existing 4×2.5 mm reference, choose PC4M5 or PTL4M5A-M at each M5 cylinder port; keep the two chamber lines separate. The A-type controller restricts cylinder-to-tube exhaust and allows free charging. Use PC4M5 at the valve A/B ports. Seat the M5 gaskets correctly; 0.05 N·m is the PTL cap-rotation recommendation, not fitting-tightening torque.
-
PC4M5: M5×0.8 male; 4 mm tube OD
Selected valve A/B connection; also M5 cylinder ports if a straight connection is chosen
-
PTL4M5A-M: M5×0.8 male; 4 mm tube OD; mini A-type
Meter-out controller at each M5 cylinder port, instead of a straight fitting
-
PC401: PT1/8 male; 4 mm tube OD
Only the separate 4A pilot connection if that pilot tube is 4 mm OD
-
US98A040025100MBU: Polyester PU; 4×2.5 mm; blue 100 m roll
Optional tube packaging example, cut to installed length
-
UE95A040025100MBU: Polyether PU; 4×2.5 mm; blue 100 m roll
Alternative tube packaging example, cut to installed length
-
5V110M5A050, 5V110M5A200, 5V120M5A050, 5V120M5A200: 5/2 valve; M5×0.8 main/exhaust ports; terminal cable
220 V AC direction control; 050/200 = 0.5/2 m leads
-
5V110M5B050, 5V110M5B200, 5V120M5B050, 5V120M5B200: 5/2 valve; M5×0.8 main/exhaust ports; terminal cable
24 V DC direction control; 050/200 = 0.5/2 m leads
-
5V110M5C050, 5V110M5C200, 5V120M5C050, 5V120M5C200: 5/2 valve; M5×0.8 main/exhaust ports; terminal cable
110 V AC direction control; 050/200 = 0.5/2 m leads
-
5V110M5E050, 5V110M5E200, 5V120M5E050, 5V120M5E200: 5/2 valve; M5×0.8 main/exhaust ports; terminal cable
24 V AC direction control; 050/200 = 0.5/2 m leads
-
5V110M5F050, 5V110M5F200, 5V120M5F050, 5V120M5F200: 5/2 valve; M5×0.8 main/exhaust ports; terminal cable
12 V DC direction control; 050/200 = 0.5/2 m leads
5V110 is single-solenoid spring return; 5V120 is double-solenoid with memory. The final 050/200 selects a 0.5/2 m terminal cable, not a DIN plug. AC tolerance is +15%/−10% (2.0 VA); DC is ±10% (1.6 W). Use the selected electrical or pneumatic control scheme, not both.
The existing 4A110M5/4A120M5 alternatives need one/two external signals through separate PT1/8 pilot ports. PC401 is conditional on 4 mm pilot tubing; seal its tapered thread appropriately. Existing BSLM5 belongs at the M5 valve exhaust ports R/S, not at cylinder working ports.
These gray PC/PTL options take soft nylon/PU tube. Use this branch within 0.15–0.7 MPa and −20 to +70°C, subject to any lower component limit. The two tube codes are alternative 100 m rolls, not required installed lengths. Both are rated 1 MPa at 23°C; derate for temperature and the lowest component limit. Minimum bend radii are 10 mm for US98A and 8 mm for UE95A.
Weight Reference
Estimated reference weight: 46.6 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight.
