Description
Specifications: Mini cylinder (compound type) Bore: 63mm Travel: 10mm Magnet: with magnet Rear cover type: horizontal tail type Fixed type: axial fixed frame Tooth type: NPT tooth
Specifications
1. Model: MBL63X10SULBT
2. Action type: double action type, working medium: air (filtered by filter screen above 40μm)
3. Use pressure range: 0.15~1.0MPa(22~145psi)(1.5~10.0bar), Guaranteed pressure resistance: 1.5MPa(215psi)(15bar)
4. Working temperature ℃:-20~70, Use speed range mm/s:30~800, Travel tolerance range: 0~150+0/1.0＞150+0/1.5
5. Buffer type: anti-collision pad, nozzle caliber: PT1/4
6. The nozzle tooth type is optional with PT tooth, G tooth and NPT tooth, and the sensor can be selected: DMSG,CMSG
Internal structure and main parts material: 1. Hexagon nut: carbon steel/2. Piston rod: S45C hard chrome abrasive rod/3. Front cover O Order: NBR/4. Front cover nut: carbon steel/5. Front cover: Aluminum alloy/6. Buffer O: TPU/7. Cylinder: Aluminum alloy/8.O-ring: NBR/9. Piston: Aluminum alloy/10. Piston O: NBR/11. Magnet: plastic/12. Wear ring: wear-resistant material/13. Screw: Alloy Steel/14. Rear cover: Aluminum alloy
Installation accessories :F-MA63LB Axial mounting F-MA50FA Flange connecting plate F-MA40SDB Rear Hinge Mount ， Piston rod end joint :F-MAC50I I Connector F-MAC50Y Y connector F-M14X150F Floating joint F-M14X150U fisheye joint
Click to download Airtac product catalog
Product Features
1. Adopt the original imported cylinder of our company.
2. The front and rear covers are connected with the cylinder by riveting structure, which has higher reliability.
3. The piston adopts special-shaped two-way sealing structure, small size, and has the function of oil storage.
4. The rear cover has various forms to make the cylinder installation more convenient.
5. There are a variety of specifications of the cylinder and installation accessories to choose from.
