Airtac GR series: pressure regulator - GR60020NK

Photos are for reference only. Not all models have pictures.

Description

Specifications: GR60020NK is an AirTAC pressure regulator with PT 3/4 inlet and outlet connections. It provides 0.05–0.9 MPa adjustable pressure and is supplied without a pressure gauge.

Product Catalog

Download Airtac Product Catalog (PDF)

For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

Model Code Explained

Code Meaning for This Product
GR600 G600 pressure regulator
20 PT 3/4
Blank type code Standard type, maximum adjustable pressure 0.9 MPa
Blank bracket code Bracket included
N No pressure gauge
Blank thread code PT 3/4 main connections
K Reverse-flow valve included

Product Features

  • The pressure-adjustment mechanism uses a balanced design for stable regulation and low drift.
  • The push-in self-locking knob helps prevent accidental changes to the setting.

Technical Specifications

Parameter Details
Current model GR60020NK
Product function pressure regulator
Working medium Air
Main inlet and outlet PT 3/4
Adjustable pressure range 0.05–0.9 MPa
Proof pressure 1.5 MPa
Maximum inlet pressure 1.0 MPa
Temperature range −20 to 70 °C
Pressure gauge Not included
Mounting bracket Included: blank bracket code
Reverse-flow option Included: K code

Weight Reference

Catalog reference weight: 1700 g for the GR600 body family. The catalog does not assign a separate weight to every gauge, bracket, drain or thread option. Actual weight is subject to the supplied product; this is not an individual weighing or a packed shipping weight.

Included Configuration and Compatible Connections

Parameter Details
Supplied functional product Pressure regulator. This listing does not include a separate lubricator or a multi-unit air-preparation set.
Pressure gauge Not supplied for this N configuration; a gauge in the drawing is a dimensional reference.
Mounting bracket Supplied under the blank bracket option.
Replacement bowl, filter and service parts Use parts explicitly selected for this body family, size, bowl material and drain type. The construction numbers identify internal parts; they do not establish standalone ordering codes, service-kit contents or package quantities.
Application connection Match the inlet and outlet thread standard and nominal size to the pneumatic circuit. The catalog does not restrict this air-preparation product to one named directional-valve or cylinder family.

Internal Construction and Materials

The following numbered references follow the catalog construction drawing. They identify components, not separately supplied spare-part quantities.

Drawing Reference Component / Material
1. Valve cap POM
2. O-ring NBR
3. Regulator body Aluminum alloy
4. Regulating piston Brass
5. O-ring NBR
6. Main diaphragm Rubber-coated SUS304
7. Fixed ring cap Aluminum alloy
8. Adjusting spindle 08A
9. Adjusting hex nut 08A
10. Pressure knob POM
11. Spring SWC
12. Adjusting seat Aluminum alloy
13. Feedback tube POM
14. Regulating plug Rubber-coated free-cutting steel
15. O-ring NBR
16. Spring Stainless steel

Dimensions and Mounting

Drawing dimensions are in millimeters unless a thread or another unit is stated. Each local callout retains its original view and datum; separate values must not be added to create an unpublished overall size. Gauge and bracket geometry is shown only as reference when those items are omitted by the current code.

Parameter Details
Main connection PT 3/4 at inlet and outlet
Front horizontal references 99; 90; 66; 13 (mm unless a thread is stated)
Knob diameter Ø64 (mm unless a thread is stated)
Front vertical references 191.5; 73.5; 11 (mm unless a thread is stated)
Side horizontal references 118; 70; 48 (mm unless a thread is stated)
Mounting thread M68×1.5 (mm unless a thread is stated)

For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.

Pressure and Flow Characteristics

Parameter Details
Applicable graph GR600
Flow graph Flow in L/min versus secondary/outlet pressure in MPa; printed flow labels extend through 15000 L/min and pressure labels through 0.6 MPa.
Flow-graph condition Inlet pressure 0.7 MPa
Pressure-characteristic graph Inlet-pressure scale 0–1.0 MPa; secondary-pressure scale 0.18–0.22 MPa, around the illustrated 0.20 MPa setting.
Reading the curves The graph axes and endpoints are plotting references, not rated flow claims. Read the actual curve at the required operating condition in the PDF.

Other Series Ordering Choices

These are catalog alternatives. They do not change the selected configuration identified above and are not additional supplied parts.

Parameter Details
Body and port choices 200: 1/8 and 1/4 inch; 300: 1/4, 3/8 and 1/2 inch; 400: 3/8 and 1/2 inch; 600: 3/4 and 1 inch.
Thread choices Blank: PT; G: G thread; T: NPT.
Gauge options Blank supply code includes a gauge; N omits it. F specifies square and C circular; scales 1/2/3 specify MPa/psi/bar.
Reverse-flow option Blank omits the reverse-flow valve; K includes it.
Pressure type Standard: maximum adjustable pressure 0.9 MPa; L: maximum 0.4 MPa. The lower limit depends on the current product and drain arrangement.
Bracket supply J means no bracket; blank means bracket supplied.

Installation and Catalog Notes

  • The push-in lock is part of the pressure-adjustment mechanism; lock the setting after adjustment. The plotted regulation characteristic is shown around the catalog setpoint and does not replace the selected pressure-range limit.
  • Select fittings, gauges and replacement parts for the stated version and interfaces. A matching nominal port size alone does not establish interchangeability with a different body series or catalog edition.

Source: the linked G Series catalog, PDF pages 1–2, printed pages 245–246.
