Description
Series: G200 series pressure regulating filter Nozzle caliber: 1/8" Drainage mode: differential pressure drainage type Type: low voltage type Bracket: attached bracket Pressure gauge: schedule Type of pressure gauge: square gauge Scale unit: MPa Filtration accuracy: 40μm level Tooth type: PT tooth Reverse flow valve: without reverse flow valve
Click to download Airtac product catalog
Product Features
1. Embedded square pressure gauge saves installation space (optional external circular pressure gauge).
2. Push-in self-locking mechanism can prevent the set pressure from being changed by external interference.
3. The balanced design of the pressure adjustment mechanism ensures stable pressure adjustment, minimum drift and excellent pressure characteristics.
4. In addition to standard models, low pressure models (maximum adjustable pressure 0.4MPa) are also available.
5. The unique diversion structure makes the passing gas rotate properly, effectively separating the liquid and reliably filtering the solid particles.
6. Filtration precision is available at 5μm and 40μm.
7. There are three drainage methods: manual, differential pressure and automatic.
8. Optional fixed bracket installation.
