Specifications: ACE32X80SBFBT is an AirTAC double-acting cylinder with a 32 mm bore, 80 mm stroke, a magnetic piston, and male-threaded rod end. The FB suffix selects rear flange.
Product Catalog
Download Airtac Product Catalog (PDF)
Download AirTAC 2022 Sensor and Mounting Compatibility Guide (PDF)
Download 2022 mounting brackets (PDF)
Download 2022 rod-end joints and sensor mounts (PDF)
Download 2022 cylinder installation and weight tables (PDF)
For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog.
Model Code Explained
| Code |
Meaning for This Model |
| ACE |
double-acting cylinder |
| 32 |
32 mm bore |
| X80 |
80 mm nominal stroke |
| S after stroke |
Magnetic piston selected |
| B |
male-threaded rod end |
| FB |
rear flange |
| T |
Suffix retained; not defined in this family's reviewed ordering chart |
Configuration Notes
- The T suffix is retained in this product code, but this family's reviewed ordering chart does not define that suffix. The standard catalog port is given as a dimensional reference; the suffix does not prove a different connection standard.
Technical Specifications
| Parameter |
Details |
| Action |
double-acting cylinder |
| Working medium |
Air filtered through a 40 μm filter or finer |
| Operating pressure |
0.15–1 MPa |
| Proof pressure |
1.5 MPa; a proof-test rating, not the continuous operating limit |
| Ambient and fluid temperature |
−20 to 70 °C |
| Piston speed |
30–500 mm/s |
| Stroke tolerance |
+1.0 / 0 mm up to 100 mm stroke; +1.5 / 0 mm above 100 mm |
| Cushioning |
Bumper |
| Air connection |
PT 1/8 (standard catalog reference; suffix is not defined in the order chart) |
| Design standard |
ISO 21287 |
Product Features
- The cylinder body and covers use threaded connections for strength and maintenance access.
- The precision-finished bore is hard anodized for wear resistance.
- The compact double-lip piston seal has an oil-retaining design; the cylinder is prelubricated.
- The compact construction saves installation space compared with the ISO 15552 design cited in the catalog. Three body sides have magnetic-switch grooves.
Dimensions for This Bore and Configuration
Dimensions are in millimeters unless a thread, angle or tolerance is stated. Letter labels follow the 118–125 printed-page drawings in the 2022 Chinese catalog. A base letter value is not automatically an overall length; use its stated stroke relationship.
| Parameter |
Details |
| A |
51 mm |
| AB |
7 mm |
| AC |
44 mm |
| AD |
14 mm |
| B |
49.5 mm |
| D |
12 mm |
| E |
M8 × 1.25 |
| EA |
16 mm |
| H |
10 mm |
| J |
9 mm |
| JA |
4.5 mm |
| JB |
32.5 mm |
| K |
M6 × 1.0 |
| KA |
28.5 mm |
| P |
G1/8 |
| PA |
7.5 mm |
| PB |
3 mm |
| R |
8.5 mm |
| RA |
3.5 mm |
| T |
9 mm |
| TA |
2.1 mm |
| Male rod AB |
26 mm |
| Male rod D |
12 mm |
| Male rod E |
M10 × 1.25 |
| Male rod EA |
17 mm |
| Male rod EB |
19 mm |
| Male rod F |
17 mm |
| Male rod FA |
6 mm |
| Male rod H |
10 mm |
Stroke-dependent Drawing Relationships
| Parameter |
Details |
| Reference drawing overall |
A + stroke |
| AC outline |
AC + stroke |
| Stroke used in the order code |
80 mm |
P is the thread label printed in the dimensional reference drawing. The connection selected by this order code is PT 1/8 (standard catalog reference; suffix is not defined in the order chart). PT, G and NPT threads must not be treated as interchangeable merely because they share a nominal fraction.
A, AB and the body outline are the catalog reference drawing values. The selected male rod uses the separate male-rod dimensions; do not substitute the female rod projection AB for it.
Construction and Materials
| Parameter |
Details |
| 1 Screw |
Carbon steel |
| 2 Rear cover |
Aluminum alloy |
| 3 Bumper |
TPU |
| 4 O-ring |
NBR |
| 5 Wear ring |
Wear-resistant material |
| 6 Magnet |
Plastic magnet |
| 7 Piston seal |
NBR |
| 8 Piston |
Aluminum alloy |
| 9 Piston rod |
S45C steel |
| 10 Body |
Aluminum alloy |
| 11 Front cover |
Aluminum alloy |
| 12 Bushing |
Wear-resistant material |
| 13 Rod seal |
NBR |
Item numbers identify the catalog sectional drawing. They are component references, not spare-part order codes or package quantities.
Matching Accessories and Mounting
| Parameter |
Details |
| F-ACE32LB (LB) |
foot bracket for ACE 32 mm bore |
| F-SI32FA (FA) |
front flange for ACE 32 mm bore |
| F-SI32FA (FB) |
rear flange for ACE 32 mm bore |
| F-SE32CA (CA) |
single rear clevis for ACE 32 mm bore |
| F-SE32CB (CB) |
double rear clevis for ACE 32 mm bore; catalog states the matching pin is included |
| F-SI32CR (CR) |
rear hinge bracket for ACE 32 mm bore; must be paired with F-SE32CB double clevis |
| F-SI32FTC (FTC) |
trunnion mounting for ACE 32 mm bore; requires F-SI32TCM2 support |
| F-SI32TCM2 (TCM2) |
trunnion support for ACE 32 mm bore; pair with F-SI32FTC; mounting position is not freely adjustable |
| F-M10X125I |
I-type rod joint; matches the selected male rod thread only |
| F-M10X125Y |
Y clevis; matches the selected male rod thread only |
| F-M10X125F |
floating joint; matches the selected male rod thread only |
| F-M10X125U |
spherical rod-end joint; matches the selected male rod thread only |
| CMSE / DMSE |
E-profile magnetic switches for this magnetic cylinder; order separately and select the electrical variant for the control system |
Accessory codes are listed for selection. Optional brackets, rod joints and switches are separate items unless the selected code or the stated pin note expressly identifies them. Component item numbers do not specify purchase quantities.
Selected FB Mounting Dimensions
| Parameter |
Details |
| A |
10 mm |
| B |
32 mm |
| C |
47 mm |
| D |
7 mm |
| E |
32.5 mm |
| F |
64 mm |
| G |
80 mm |
| H |
30.5 mm |
| N |
51 mm |
Letters in this table belong to the FB accessory drawing. Stroke-dependent C, D, E, N or A dimensions must be read with the added-stroke callouts and the selected cylinder action; they are not all fixed overall lengths.
Stroke and Option Selection
| Parameter |
Details |
| Standard strokes for this bore/action |
5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 70, 75, 80, 90, 100, 110, 120, 125, 150, 160, 175, 200 mm |
| Intermediate strokes |
The catalog allows a nonstandard intermediate stroke with the outer dimensions of the next larger standard stroke; this does not extend the maximum allowable stroke. |
| Magnetic selection |
Select the magnetic option before ordering a position switch; electrical type, cable and connector are selected separately. |
Selection, Installation and Operation
- Select bore from the required thrust and available pressure; then check stroke, load direction, mounting, cushioning and sensing. The general catalog load-factor references are at most 0.7 for static/slow work and at most 0.5 for 50–500 mm/s motion. They do not replace the load and guide checks for this cylinder.
- Keep the piston rod and load aligned. Support lateral or eccentric loads with an appropriate guide; avoid applying bending force or tightening torque through the rod or guide.
- Use clean filtered air. Prevent freezing, water, dust and corrosive substances from entering the cylinder. The cylinder is prelubricated; if lubrication is introduced, use additive-free ISO VG32 oil and continue that lubrication.
- Start with the speed controller restricted, then open it gradually. Choose the circuit and flow-control direction for the action and load; a double-acting meter-out circuit is a general reference, not a guarantee of equal speed or precise stopping.
- Isolate the air and electrical supplies and release trapped pressure before maintenance. Check the mounting and retained parts before repressurizing. A C-ring must be fully seated before operation.
Circuit Selection Reference at 500 mm/s
| Parameter |
Details |
| Reference bore |
32 mm |
| Effective flow area at the reference speed |
2.1 mm² |
| Tube outside / inside diameter |
6 / 4 mm |
| Example speed controller |
PTLM5 |
| Example silencer |
BSLM5 |
| Example solenoid valves |
5V110M5 / 5V120M5 |
| Example air-piloted valves |
4A110M5 / 4A120M5 |
The general 2022 selection table gives these circuit examples for this bore at a theoretical 500 mm/s reference speed. They are not included accessories, a guaranteed achieved speed, or a statement that every example screws directly into this cylinder. Match the actual port thread, action, tubing, valve capacity and operating conditions.
Weight Reference
Estimated reference weight: 575 g. Based on the same family/bore catalog mass data and the stated configuration; it is not an AirTAC published weight for this exact variant or a measured weight. The selected mounting bracket mass is not separately listed in the cylinder weight table; this reference does not certify a packed assembly weight.
