NT-NT-1000L

NT Series Electro-Pneumatic Positioner

Product Features
Specifications
Performance Data
Ordering Code

Features

Precise Control: Receives 4~20mA DC current signal from a controller to precisely control valve position via pneumatic actuator.
Versatile Action: Direct and Reverse action, as well as Single and Double acting modes, can be easily switched without replacing parts.
Economic: Low air consumption design.
Split Range: Supports 1/2 split range control without replacing internal parts.
Compact Design: Small structure suitable for connecting small actuators; features anti-vibration design.

General Specifications

Item	NT-1000R (Rotary)	NT-1000L (Linear)
Input Signal	4 ~ 20mA DC
Impedance	250 ± 15 Ω
Supply Pressure	0.14 ~ 0.7 MPa
Stroke / Angle	0 ~ 90°	10 ~ 150 mm
Air Connection	PT(NPT) 1/4
Gauge Connection	PT(NPT) 1/8
Power Connection	PF1/2 (G1/2)
Explosion Proof	Exd mIIBT5 / Exd mIICT5 / Exia BT6
Protection Class	IP66
Ambient Temp.	Standard: -20 ~ 70°C Explosion Proof: -20 ~ 60°C

Performance Specifications

Item	Single Acting	Double Acting
Linearity	±1% F.S.	±2% F.S.
Hysteresis	±1% F.S.
Sensitivity	±0.2% F.S.	±0.5% F.S.
Repeatability	±0.5% F.S.

Note: Values above are for standard models. Explosion-proof models may vary slightly (e.g., Sensitivity ±0.5% F.S.).

Ordering Code

NT - 1000R S n 5 3 1 S 0

No.	Item	Options / Description
①	Series	NT-1000R: Rotary Positioner (Angle stroke) NT-1000L: Linear Positioner (Straight stroke)
②	Acting Type	S: Single Acting D: Double Acting
③	Explosion Proof	n: None (Standard) m: Exd mIIBT5 c: Exd mIICT5 i: Exia BT6
④	Feedback Lever	For Rotary (NT-1000R): 1: M6×40L, 2: M6×63L, 3: M8×40L, 4: M8×63L, 5: NAMUR Standard For Linear (NT-1000L): 1: 8~35mm, 2: 20~40mm, 3: 30~70mm, 4: 60~100mm, 5: 110~150mm
⑤	Orifice	1: Φ1 2: Φ2 3: None
⑥	Connection	1: PT Thread 2: NPT Thread
⑦	Ambient Temp	S: -20°C ~ 60°C (Standard) H: -20°C ~ 120°C (High Temp) L: -40°C ~ 70°C (Low Temp)
⑧	Accessories	0: None 1: +PTM (Internal) 2: +PTM (External) 3: +L/S (Internal) 4: +L/S (External) 5: +PTM + L/S (Internal)

View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LDn532L

Specifications: NT-1000LDn532L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, double-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner D Double acting n Non-explosion-protected version 5 110–150 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±2% F.S. Hysteresis ±1% F.S. Sensitivity ±0.5% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LSn532L

Specifications: NT-1000LSn532L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, single-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner S Single acting n Non-explosion-protected version 5 110–150 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±1% F.S. Hysteresis ±1% F.S. Sensitivity ±0.2% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LDi532L

Specifications: NT-1000LDi532L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, double-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner D Double acting i Exia BT6, as printed in the ordering table 5 110–150 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±2% F.S. Hysteresis ±1% F.S. Sensitivity ±0.5% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LSi532L

Specifications: NT-1000LSi532L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, single-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner S Single acting i Exia BT6, as printed in the ordering table 5 110–150 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±1% F.S. Hysteresis ±1% F.S. Sensitivity ±0.2% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LDc532L

Specifications: NT-1000LDc532L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, double-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner D Double acting c Exd mIICT5, as printed in the ordering table 5 110–150 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±2% F.S. Hysteresis ±1% F.S. Sensitivity ±0.5% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LSc532L

Specifications: NT-1000LSc532L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, single-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner S Single acting c Exd mIICT5, as printed in the ordering table 5 110–150 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±1% F.S. Hysteresis ±1% F.S. Sensitivity ±0.2% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LDm532L

Specifications: NT-1000LDm532L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, double-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner D Double acting m Exd mIIBT5, as printed in the ordering table 5 110–150 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±2% F.S. Hysteresis ±1% F.S. Sensitivity ±0.5% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LSm532L

Specifications: NT-1000LSm532L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, single-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner S Single acting m Exd mIIBT5, as printed in the ordering table 5 110–150 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±1% F.S. Hysteresis ±1% F.S. Sensitivity ±0.2% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LDn432L

Specifications: NT-1000LDn432L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, double-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner D Double acting n Non-explosion-protected version 4 60–100 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±2% F.S. Hysteresis ±1% F.S. Sensitivity ±0.5% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LSn432L

Specifications: NT-1000LSn432L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, single-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner S Single acting n Non-explosion-protected version 4 60–100 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±1% F.S. Hysteresis ±1% F.S. Sensitivity ±0.2% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LDi432L

Specifications: NT-1000LDi432L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, double-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner D Double acting i Exia BT6, as printed in the ordering table 4 60–100 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±2% F.S. Hysteresis ±1% F.S. Sensitivity ±0.5% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LSi432L

Specifications: NT-1000LSi432L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, single-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner S Single acting i Exia BT6, as printed in the ordering table 4 60–100 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±1% F.S. Hysteresis ±1% F.S. Sensitivity ±0.2% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LDc432L

Specifications: NT-1000LDc432L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, double-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner D Double acting c Exd mIICT5, as printed in the ordering table 4 60–100 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±2% F.S. Hysteresis ±1% F.S. Sensitivity ±0.5% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LSc432L

Specifications: NT-1000LSc432L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, single-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner S Single acting c Exd mIICT5, as printed in the ordering table 4 60–100 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±1% F.S. Hysteresis ±1% F.S. Sensitivity ±0.2% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LDm432L

Specifications: NT-1000LDm432L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, double-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner D Double acting m Exd mIIBT5, as printed in the ordering table 4 60–100 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±2% F.S. Hysteresis ±1% F.S. Sensitivity ±0.5% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LSm432L

Specifications: NT-1000LSm432L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, single-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner S Single acting m Exd mIIBT5, as printed in the ordering table 4 60–100 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±1% F.S. Hysteresis ±1% F.S. Sensitivity ±0.2% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LDn332L

Specifications: NT-1000LDn332L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, double-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner D Double acting n Non-explosion-protected version 3 30–70 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±2% F.S. Hysteresis ±1% F.S. Sensitivity ±0.5% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LSn332L

Specifications: NT-1000LSn332L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, single-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner S Single acting n Non-explosion-protected version 3 30–70 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±1% F.S. Hysteresis ±1% F.S. Sensitivity ±0.2% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LDi332L

Specifications: NT-1000LDi332L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, double-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner D Double acting i Exia BT6, as printed in the ordering table 3 30–70 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±2% F.S. Hysteresis ±1% F.S. Sensitivity ±0.5% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LSi332L

Specifications: NT-1000LSi332L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, single-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner S Single acting i Exia BT6, as printed in the ordering table 3 30–70 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±1% F.S. Hysteresis ±1% F.S. Sensitivity ±0.2% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LDc332L

Specifications: NT-1000LDc332L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, double-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner D Double acting c Exd mIICT5, as printed in the ordering table 3 30–70 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±2% F.S. Hysteresis ±1% F.S. Sensitivity ±0.5% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LSc332L

Specifications: NT-1000LSc332L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, single-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner S Single acting c Exd mIICT5, as printed in the ordering table 3 30–70 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±1% F.S. Hysteresis ±1% F.S. Sensitivity ±0.2% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LDm332L

Specifications: NT-1000LDm332L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, double-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner D Double acting m Exd mIIBT5, as printed in the ordering table 3 30–70 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±2% F.S. Hysteresis ±1% F.S. Sensitivity ±0.5% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
View options

Airtac NT series: linear electro-pneumatic valve positioner - NT-1000LSm332L

Specifications: NT-1000LSm332L — linear electro-pneumatic valve positioner with a 4–20 mA DC input, single-acting control and the specific feedback / protection options decoded below. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning NT-1000L Linear positioner S Single acting m Exd mIIBT5, as printed in the ordering table 3 30–70 mm feedback range 3 No restriction 2 NPT threaded connection L −40 to +70°C ordering temperature option Technical Specifications Parameter Details Input signal 4–20 mA DC Impedance 250 ±15 Ω Supply pressure 0.14–0.7 MPa Nominal travel 10–150 mm Air connection NPT 1/4 Gauge connection NPT 1/8 Electrical entry PF1/2 Protection IP66 Linearity ±1% F.S. Hysteresis ±1% F.S. Sensitivity ±0.2% F.S. Repeatability ±0.5% F.S. Selected temperature option −40 to +70°C General specification-table temperature Operating −20 to +70°C; explosion-protected ambient −20 to +60°C Features and Application Direct/reverse action and single/double action can be converted as described in the catalog. Low air consumption. Half-range split control is possible without replacing parts. For small actuators, reducing the restriction opening helps suppress oscillation. Accessory Ordering Scope This catalog shows the PTM and L/S accessory-code field for NT-1000R and marks NT-1000L as having no such code. Those rotary-series option codes are not part of this linear positioner's ordering code. Dimensions and Installation Parameter Details Overall drawing length 218.3 mm Overall drawing height 166.5 mm Main enclosure height 122 mm Main enclosure length 132.3 mm Rear body width 91.8 mm Bracket width / height 45 / 70 mm Bracket hole pitch 50 mm Bracket fasteners M8 × 1.25P Rear mounting holes 4 × M8 × 1.25P Drawing depth 117.5 mm Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Selection and Installation This positioner converts the electrical control signal into pneumatic output for a matching actuator. Select the feedback geometry, travel and single- or double-acting arrangement to match the actuator; a shared thread alone does not establish compatibility. The ordering table lists temperature variants separately from the general specification table. The selected option is shown above; explosion-protected operation must also remain within the applicable marked ambient rating. Check the delivered nameplate and required approval for the installation. PTM and limit-switch options are identified by the catalog, but separate electrical ratings for these accessories are not provided on this page. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 2306 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Main drawing envelope × assumed aluminium density 2.7 g/cm³ × 20% equivalent solid fill. This simplified enclosure estimate includes a general allowance for mechanism and fittings; options are not individually weighed.

Read more less

$2,084.32

View options
