ESV

400 products

Show previous products

  • ESV420A

    Airtac ESV420-A: ISO standard solenoid valve - ESV420A

    Specifications: ISO standard solenoid valve,Series: 400 series,Electric control mode: double position double electric control,Standard voltage: AC220V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $147.00

  • ESV410F

    Airtac ESV410-F: ISO standard solenoid valve - ESV410F

    Specifications: ISO standard solenoid valve,Series: 400 series,Electric control mode: double position single electric control,Standard voltage: DC12V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $119.10

  • ESV410E

    Airtac ESV410-E: ISO standard solenoid valve - ESV410E

    Specifications: ISO standard solenoid valve,Series: 400 series,Electric control mode: double position single electric control,Standard voltage: AC24V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $119.10

  • ESV410C

    Airtac ESV410-C: ISO standard solenoid valve - ESV410C

    Specifications: ISO standard solenoid valve,Series: 400 series,Electric control mode: double position single electric control,Standard voltage: AC110V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $119.10

  • ESV410B

    Airtac ESV410-B: ISO standard solenoid valve - ESV410B

    Specifications: ISO standard solenoid valve,Series: 400 series,Electric control mode: double position single electric control,Standard voltage: DC24V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $119.10

  • ESV410A

    Airtac ESV410-A: ISO standard solenoid valve - ESV410A

    Specifications: ISO standard solenoid valve,Series: 400 series,Electric control mode: double position single electric control,Standard voltage: AC220V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $119.10

  • ESV330PF

    Airtac ESV330P-F: ISO standard solenoid valve - ESV330PF

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: three-position double electric control median pressure type,Standard voltage: DC12V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $110.50

  • ESV330PE

    Airtac ESV330P-E: ISO standard solenoid valve - ESV330PE

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: three-position double electric control median pressure type,Standard voltage: AC24V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $110.50

  • ESV330PC

    Airtac ESV330P-C: ISO standard solenoid valve - ESV330PC

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: three-position double electric control median pressure type,Standard voltage: AC110V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $110.50

  • ESV330PB

    Airtac ESV330P-B: ISO standard solenoid valve - ESV330PB

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: three-position double electric control median pressure type,Standard voltage: DC24V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $110.50

  • ESV330PA

    Airtac ESV330P-A: ISO standard solenoid valve - ESV330PA

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: three-position double electric control median pressure type,Standard voltage: AC220V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $110.50

  • ESV330EF

    Airtac ESV330E-F: ISO standard solenoid valve - ESV330EF

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: three-position double electric control median exhaust type,Standard voltage: DC12V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $110.50

  • ESV330EE

    Airtac ESV330E-E: ISO standard solenoid valve - ESV330EE

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: three-position double electric control median exhaust type,Standard voltage: AC24V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $110.50

  • ESV330EC

    Airtac ESV330E-C: ISO standard solenoid valve - ESV330EC

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: three-position double electric control median exhaust type,Standard voltage: AC110V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $110.50

  • ESV330EB

    Airtac ESV330E-B: ISO standard solenoid valve - ESV330EB

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: three-position double electric control median exhaust type,Standard voltage: DC24V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $110.50

  • ESV330EA

    Airtac ESV330E-A: ISO standard solenoid valve - ESV330EA

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: three-position double electric control median exhaust type,Standard voltage: AC220V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $110.50

  • ESV330CF

    Airtac ESV330C-F: ISO standard solenoid valve - ESV330CF

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: three-position double electric control neutral closed type,Standard voltage: DC12V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $110.50

  • ESV330CE

    Airtac ESV330C-E: ISO standard solenoid valve - ESV330CE

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: three-position double electric control neutral closed type,Standard voltage: AC24V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $110.50

  • ESV330CC

    Airtac ESV330C-C: ISO standard solenoid valve - ESV330CC

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: three-position double electric control neutral closed type,Standard voltage: AC110V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $110.50

  • ESV330CB

    Airtac ESV330C-B: ISO standard solenoid valve - ESV330CB

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: three-position double electric control neutral closed type,Standard voltage: DC24V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $110.50

  • ESV330CA

    Airtac ESV330C-A: ISO standard solenoid valve - ESV330CA

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: three-position double electric control neutral closed type,Standard voltage: AC220V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $110.50

  • ESV320F

    Airtac ESV320-F: ISO standard solenoid valve - ESV320F

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: double position double electric control,Standard voltage: DC12V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $95.10

  • ESV320E

    Airtac ESV320-E: ISO standard solenoid valve - ESV320E

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: double position double electric control,Standard voltage: AC24V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $95.10

  • ESV320C

    Airtac ESV320-C: ISO standard solenoid valve - ESV320C

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: double position double electric control,Standard voltage: AC110V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $95.10

  • ESV320A

    Airtac ESV320-A: ISO standard solenoid valve - ESV320A

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: double position double electric control,Standard voltage: AC220V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $95.10

  • ESV310F

    Airtac ESV310-F: ISO standard solenoid valve - ESV310F

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: double position single electric control,Standard voltage: DC12V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $73.70

  • ESV310E

    Airtac ESV310-E: ISO standard solenoid valve - ESV310E

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: double position single electric control,Standard voltage: AC24V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $73.70

  • ESV310C

    Airtac ESV310-C: ISO standard solenoid valve - ESV310C

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: double position single electric control,Standard voltage: AC110V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $73.70

  • ESV310B

    Airtac ESV310-B: ISO standard solenoid valve - ESV310B

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: double position single electric control,Standard voltage: DC24V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $73.70

  • ESV310A

    Airtac ESV310-A: ISO standard solenoid valve - ESV310A

    Specifications: ISO standard solenoid valve,Series: 300 series,Electric control mode: double position single electric control,Standard voltage: AC220V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $73.70

  • ESV230PF

    Airtac ESV230P-F: ISO standard solenoid valve - ESV230PF

    Specifications: ISO standard solenoid valve,Series: 200 series,Electric control mode: three-position double electric control median pressure type,Standard voltage: DC12V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $97.70

  • ESV230PE

    Airtac ESV230P-E: ISO standard solenoid valve - ESV230PE

    Specifications: ISO standard solenoid valve,Series: 200 series,Electric control mode: three-position double electric control median pressure type,Standard voltage: AC24V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $97.70

  • ESV230PC

    Airtac ESV230P-C: ISO standard solenoid valve - ESV230PC

    Specifications: ISO standard solenoid valve,Series: 200 series,Electric control mode: three-position double electric control median pressure type,Standard voltage: AC110V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $97.70

  • ESV230PB

    Airtac ESV230P-B: ISO standard solenoid valve - ESV230PB

    Specifications: ISO standard solenoid valve,Series: 200 series,Electric control mode: three-position double electric control median pressure type,Standard voltage: DC24V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $97.70

  • ESV230PA

    Airtac ESV230P-A: ISO standard solenoid valve - ESV230PA

    Specifications: ISO standard solenoid valve,Series: 200 series,Electric control mode: three-position double electric control median pressure type,Standard voltage: AC220V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $97.70

  • ESV230EF

    Airtac ESV230E-F: ISO standard solenoid valve - ESV230EF

    Specifications: ISO standard solenoid valve,Series: 200 series,Electric control mode: three-position double electric control median exhaust type,Standard voltage: DC12V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $97.70

  • ESV230EE

    Airtac ESV230E-E: ISO standard solenoid valve - ESV230EE

    Specifications: ISO standard solenoid valve,Series: 200 series,Electric control mode: three-position double electric control median exhaust type,Standard voltage: AC24V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $97.70

  • ESV230EC

    Airtac ESV230E-C: ISO standard solenoid valve - ESV230EC

    Specifications: ISO standard solenoid valve,Series: 200 series,Electric control mode: three-position double electric control median exhaust type,Standard voltage: AC110V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $97.70

  • ESV230EB

    Airtac ESV230E-B: ISO standard solenoid valve - ESV230EB

    Specifications: ISO standard solenoid valve,Series: 200 series,Electric control mode: three-position double electric control median exhaust type,Standard voltage: DC24V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $97.70

  • ESV230EA

    Airtac ESV230E-A: ISO standard solenoid valve - ESV230EA

    Specifications: ISO standard solenoid valve,Series: 200 series,Electric control mode: three-position double electric control median exhaust type,Standard voltage: AC220V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $97.70

  • ESV230CF

    Airtac ESV230C-F: ISO standard solenoid valve - ESV230CF

    Specifications: ISO standard solenoid valve,Series: 200 series,Electric control mode: three-position double electric control neutral closed type,Standard voltage: DC12V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $97.70

  • ESV230CE

    Airtac ESV230C-E: ISO standard solenoid valve - ESV230CE

    Specifications: ISO standard solenoid valve,Series: 200 series,Electric control mode: three-position double electric control neutral closed type,Standard voltage: AC24V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $97.70

  • ESV230CC

    Airtac ESV230C-C: ISO standard solenoid valve - ESV230CC

    Specifications: ISO standard solenoid valve,Series: 200 series,Electric control mode: three-position double electric control neutral closed type,Standard voltage: AC110V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $97.70

  • ESV230CB

    Airtac ESV230C-B: ISO standard solenoid valve - ESV230CB

    Specifications: ISO standard solenoid valve,Series: 200 series,Electric control mode: three-position double electric control neutral closed type,Standard voltage: DC24V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $97.70

  • ESV230CA

    Airtac ESV230C-A: ISO standard solenoid valve - ESV230CA

    Specifications: ISO standard solenoid valve,Series: 200 series,Electric control mode: three-position double electric control neutral closed type,Standard voltage: AC220V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $97.70

  • ESV220F

    Airtac ESV220-F: ISO standard solenoid valve - ESV220F

    Specifications: ISO standard solenoid valve,Series: 200 series,Electric control mode: double position double electric control,Standard voltage: DC12V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $82.20

  • ESV220E

    Airtac ESV220-E: ISO standard solenoid valve - ESV220E

    Specifications: ISO standard solenoid valve,Series: 200 series,Electric control mode: double position double electric control,Standard voltage: AC24V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $82.20

  • ESV220C

    Airtac ESV220-C: ISO standard solenoid valve - ESV220C

    Specifications: ISO standard solenoid valve,Series: 200 series,Electric control mode: double position double electric control,Standard voltage: AC110V,Power connection mode: DIN socket type,Guide mode: internal guide,Click to download the Airtac catalogProduct FeaturesESV200, 300, 400, 600 Series1.Succinct appearance and compact conformation.2.The installation size conforms to ISO 5599/1 standard.3.Because of the special seals, the feature are large flow rate and long lifetime.4.For 200\300\400 series you can adjust the installation direction of the gasket to change the acting type: internal pilot, external pilot, or air control.5.You need install the valve together with the sub-base. There are individual and parallel type for manifold sub-base.6.There are various connection and installation method for manifold. It is easy to use.7.The manifold of 200\300\400 series have the function of exhaust throttling, so not need to connect another throttle valve.

    Read more

    $82.20

You have seen 96 out of 400 products

Show more products

Valve Product Information

Valve

  • Product Features
  • Specifications
  • Product Ordering Code

Product Features

  • Simple and compact appearance.
  • The mounting size of the connection plate conforms to the ISO 5599-1 international standard.
  • The product uses special seals, has a large flow rate, and a long service life.
  • For the 200, 300, and 400 series, the pilot valve's action is switched to internal pilot to separate the valve body from the plate type, and external pilot for conversion between air connections.
  • The valve body has various installation and air connection methods for convenient use.
  • The base of the 200, 300, and 400 series integrates an exhaust throttle function, eliminating the need for an external throttle valve during use.

Specifications

Product Series 200 Series 300 Series 400 Series 600 Series
Effective Area (Cv) [mm²] 32 (Cv=1.8) 42 (Cv=2.32) 69 (Cv=3.85) 108 (Cv=6.0)
Working Medium Air filtered by a 40μm or larger filter screen
Actuation Mode Internal or external pilot type
Working Pressure Internal Pilot: 0.2~1.0MPa (2~10bar) (29~145psi)
External Pilot: 0~1.0MPa (0~10bar) (0~145psi) or 0.2~1.0MPa (2~10bar) (29~145psi)
External Pilot Valve Control Pressure 0.2~1.0MPa (2~10bar) (29~145psi)
Proof Pressure 1.5MPa (15bar) (215psi)
Operating Temperature -20~70°C
Valve Body Port Size PT1/4 PT3/8 PT1/2 PT3/4
Response Time (10/20/30 Type) 33/41ms 42/55ms 50/68ms 55/85ms
Response Time (30C/30E/30P Type) 38/50ms 50/62ms 50/68ms 55/85ms
Heat Resistance Class Class B
Protection Class IP65
Note:
• If lubricating, do not stop. It is recommended to use ISO VG32 or equivalent oil.
• G threads and NPT threads are also available for port sizes.
• Protection class IP65 refers to the level after correct installation.

Product Ordering Code

Valve Body

Example: ESV 2 10 A □ □

Item Code Description
Series Code 2 / 3 / 4 / 6 200 / 300 / 400 / 600 Series
Electric Control 10 / 20 / 30C / 30E / 30P Single Solenoid / Double Solenoid / Closed Center / Exhaust Center / Pressure Center
Standard Voltage A / B / C / E / F AC220V / DC24V / AC110V / AC24V / DC12V
Connection Method Blank / I DIN Socket Type / Lead Wire Type
Pilot Type Blank / W Internal Pilot / External Pilot
Note:
• Internal and external pilot types are interchangeable (except for the 600 series).
• The standard length for the lead-wire type is 0.5m.

Base and End Plate Assembly

Example: ESV 20 1M □ □ □

Item Code Description
Series Code 20 / 30 / 40 / 60 200 / 300 / 400 / 600 Series
Model Code 1M / 2M / 3M / 4M Single Base / Manifold Base / Threaded Component / Manifold Conversion Block
Thread Type Blank / G PT Thread / G Thread
External Pilot Port Blank / W Independent / Centralized
Port Orientation Blank / B / L / R Side Port / Bottom Port / Left Port / Right Port

Accessory

Example: P-ESV200M-R2

Item Code Description
Applicable Product ESV200M / 300M / 400M / 600M 200 / 300 / 400 / 600 Series Base
Accessory Category R2 Blanking Plate for Base
