APT Series Air-Hydro Booster Cylinder

•

  View options

  Airtac APT series: air-oil booster - APT-20TX200-20-20T-S

  Specifications: APT-20TX200-20-20T-S — standard air-oil booster listing with 125 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 20T 125 mm hydraulic bore under the catalog’s bore-code mapping X200 200 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 125 mm Selected boosted stroke 20 mm Total stroke 200 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details A 265 mm B 411 mm C 846 mm D 936 mm E 360 mm Flange width / height 200 / 285 mm Flange fixing pitch 140 × 255 mm Flange holes 4 × Ø25 mm Rod diameter Ø55 mm Rod-end thread M48 × 2P Rear cylinder section 180 mm Gauge port PT1/4 Air-port designation Three PT1/2 ports in the drawing heading Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Theoretical Output Parameter Details Pre-pressure output at 1 kgf/cm² 120 kgf-equivalent Pre-pressure output at 2 kgf/cm² 240 kgf-equivalent Pre-pressure output at 3 kgf/cm² 360 kgf-equivalent Pre-pressure output at 4 kgf/cm² 480 kgf-equivalent Pre-pressure output at 5 kgf/cm² 600 kgf-equivalent Pre-pressure output at 6 kgf/cm² 720 kgf-equivalent Pre-pressure output at 7 kgf/cm² 840 kgf-equivalent Boosted output at 1 kgf/cm² 3500 kgf-equivalent Boosted output at 2 kgf/cm² 7000 kgf-equivalent Boosted output at 3 kgf/cm² 10500 kgf-equivalent Boosted output at 4 kgf/cm² 14000 kgf-equivalent Boosted output at 5 kgf/cm² 17500 kgf-equivalent Boosted output at 6 kgf/cm² 21000 kgf-equivalent Boosted output at 7 kgf/cm² 24500 kgf-equivalent Return pull at 1 kgf/cm² 90 kgf-equivalent Return pull at 2 kgf/cm² 180 kgf-equivalent Return pull at 3 kgf/cm² 270 kgf-equivalent Return pull at 4 kgf/cm² 360 kgf-equivalent Return pull at 5 kgf/cm² 450 kgf-equivalent Return pull at 6 kgf/cm² 540 kgf-equivalent Return pull at 7 kgf/cm² 630 kgf-equivalent Values above follow the printed theoretical table. The 1 kgf/cm² column is a calculation reference below the 0.2 MPa minimum operating pressure; it is not a permitted operating point. Theoretical output is not a guaranteed measured force. The dimension table illustrates the standard cylinder configuration. For horizontal installation, the reservoir is connected vertically to the hydraulic cylinder as stated in the ordering footnote. The standard drawing is a dimensional reference, not a complete final layout for an independently positioned reservoir. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 43215 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 936 × 200 × 285 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework.

  Read more less

  $2,017.46

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-15TX200-20-20T-S

  Specifications: APT-15TX200-20-20T-S — standard air-oil booster listing with 125 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 15T 125 mm hydraulic bore under the catalog’s bore-code mapping X200 200 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 125 mm Selected boosted stroke 20 mm Total stroke 200 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details A 265 mm B 411 mm C 846 mm D 936 mm E 360 mm Flange width / height 200 / 285 mm Flange fixing pitch 140 × 255 mm Flange holes 4 × Ø25 mm Rod diameter Ø55 mm Rod-end thread M48 × 2P Rear cylinder section 180 mm Gauge port PT1/4 Air-port designation Three PT1/2 ports in the drawing heading Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Theoretical Output Parameter Details Pre-pressure output at 1 kgf/cm² 120 kgf-equivalent Pre-pressure output at 2 kgf/cm² 240 kgf-equivalent Pre-pressure output at 3 kgf/cm² 360 kgf-equivalent Pre-pressure output at 4 kgf/cm² 480 kgf-equivalent Pre-pressure output at 5 kgf/cm² 600 kgf-equivalent Pre-pressure output at 6 kgf/cm² 720 kgf-equivalent Pre-pressure output at 7 kgf/cm² 840 kgf-equivalent Boosted output at 1 kgf/cm² 3500 kgf-equivalent Boosted output at 2 kgf/cm² 7000 kgf-equivalent Boosted output at 3 kgf/cm² 10500 kgf-equivalent Boosted output at 4 kgf/cm² 14000 kgf-equivalent Boosted output at 5 kgf/cm² 17500 kgf-equivalent Boosted output at 6 kgf/cm² 21000 kgf-equivalent Boosted output at 7 kgf/cm² 24500 kgf-equivalent Return pull at 1 kgf/cm² 90 kgf-equivalent Return pull at 2 kgf/cm² 180 kgf-equivalent Return pull at 3 kgf/cm² 270 kgf-equivalent Return pull at 4 kgf/cm² 360 kgf-equivalent Return pull at 5 kgf/cm² 450 kgf-equivalent Return pull at 6 kgf/cm² 540 kgf-equivalent Return pull at 7 kgf/cm² 630 kgf-equivalent Values above follow the printed theoretical table. The 1 kgf/cm² column is a calculation reference below the 0.2 MPa minimum operating pressure; it is not a permitted operating point. Theoretical output is not a guaranteed measured force. The dimension table illustrates the standard cylinder configuration. For horizontal installation, the reservoir is connected vertically to the hydraulic cylinder as stated in the ordering footnote. The standard drawing is a dimensional reference, not a complete final layout for an independently positioned reservoir. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 43215 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 936 × 200 × 285 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework.

  Read more less

  $2,017.46

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-13TX200-20-20T-S

  Specifications: APT-13TX200-20-20T-S — standard air-oil booster listing with 100 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 13T 100 mm hydraulic bore under the catalog’s bore-code mapping X200 200 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 100 mm Selected boosted stroke 20 mm Total stroke 200 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details Installation dimensions Not assigned: the listed bore-selection and output-selection codes map to different hydraulic bores in the supplied catalog. Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. This listing selects 100 mm hydraulic bore through 13T, but its 20T output class is cataloged with a 125 mm bore. The source does not define this crossed combination. The original model is retained; the series operating ranges above do not validate this combination. Confirm a matching complete order code before ordering. No dimensions or theoretical output from a different bore have been assigned to it. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 23651 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 895 × 145 × 225 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework. This mass estimate uses a supported same-bore reference only and does not validate the crossed ordering combination.

  Read more less

  $843.10

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-10TX200-20-20T-S

  Specifications: APT-10TX200-20-20T-S — standard air-oil booster listing with 100 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 10T 100 mm hydraulic bore under the catalog’s bore-code mapping X200 200 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 100 mm Selected boosted stroke 20 mm Total stroke 200 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details Installation dimensions Not assigned: the listed bore-selection and output-selection codes map to different hydraulic bores in the supplied catalog. Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. This listing selects 100 mm hydraulic bore through 10T, but its 20T output class is cataloged with a 125 mm bore. The source does not define this crossed combination. The original model is retained; the series operating ranges above do not validate this combination. Confirm a matching complete order code before ordering. No dimensions or theoretical output from a different bore have been assigned to it. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 21537 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 815 × 145 × 225 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework. This mass estimate uses a supported same-bore reference only and does not validate the crossed ordering combination.

  Read more less

  $843.10

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-5TX200-20-20T-S

  Specifications: APT-5TX200-20-20T-S — standard air-oil booster listing with 80 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 5T 80 mm hydraulic bore under the catalog’s bore-code mapping X200 200 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 80 mm Selected boosted stroke 20 mm Total stroke 200 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details Installation dimensions Not assigned: the listed bore-selection and output-selection codes map to different hydraulic bores in the supplied catalog. Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. This listing selects 80 mm hydraulic bore through 5T, but its 20T output class is cataloged with a 125 mm bore. The source does not define this crossed combination. The original model is retained; the series operating ranges above do not validate this combination. Confirm a matching complete order code before ordering. No dimensions or theoretical output from a different bore have been assigned to it. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 13523 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 786 × 118 × 180 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework. This mass estimate uses a supported same-bore reference only and does not validate the crossed ordering combination.

  Read more less

  $564.30

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-3TX200-20-20T-S

  Specifications: APT-3TX200-20-20T-S — standard air-oil booster listing with 63 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 3T 63 mm hydraulic bore under the catalog’s bore-code mapping X200 200 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 63 mm Selected boosted stroke 20 mm Total stroke 200 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details Installation dimensions Not assigned: the listed bore-selection and output-selection codes map to different hydraulic bores in the supplied catalog. Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. This listing selects 63 mm hydraulic bore through 3T, but its 20T output class is cataloged with a 125 mm bore. The source does not define this crossed combination. The original model is retained; the series operating ranges above do not validate this combination. Confirm a matching complete order code before ordering. No dimensions or theoretical output from a different bore have been assigned to it. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 9396 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 725 × 100 × 160 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework. This mass estimate uses a supported same-bore reference only and does not validate the crossed ordering combination.

  Read more less

  $402.78

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-1TX200-20-20T-S

  Specifications: APT-1TX200-20-20T-S — standard air-oil booster listing with 63 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 1T 63 mm hydraulic bore under the catalog’s bore-code mapping X200 200 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 63 mm Selected boosted stroke 20 mm Total stroke 200 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details Installation dimensions Not assigned: the listed bore-selection and output-selection codes map to different hydraulic bores in the supplied catalog. Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. This listing selects 63 mm hydraulic bore through 1T, but its 20T output class is cataloged with a 125 mm bore. The source does not define this crossed combination. The original model is retained; the series operating ranges above do not validate this combination. Confirm a matching complete order code before ordering. No dimensions or theoretical output from a different bore have been assigned to it. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 9266 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 715 × 100 × 160 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework. This mass estimate uses a supported same-bore reference only and does not validate the crossed ordering combination.

  Read more less

  $402.78

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-20TX150-20-20T-S

  Specifications: APT-20TX150-20-20T-S — standard air-oil booster listing with 125 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 20T 125 mm hydraulic bore under the catalog’s bore-code mapping X150 150 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 125 mm Selected boosted stroke 20 mm Total stroke 150 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details A 215 mm B 411 mm C 796 mm D 886 mm E 320 mm Flange width / height 200 / 285 mm Flange fixing pitch 140 × 255 mm Flange holes 4 × Ø25 mm Rod diameter Ø55 mm Rod-end thread M48 × 2P Rear cylinder section 180 mm Gauge port PT1/4 Air-port designation Three PT1/2 ports in the drawing heading Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Theoretical Output Parameter Details Pre-pressure output at 1 kgf/cm² 120 kgf-equivalent Pre-pressure output at 2 kgf/cm² 240 kgf-equivalent Pre-pressure output at 3 kgf/cm² 360 kgf-equivalent Pre-pressure output at 4 kgf/cm² 480 kgf-equivalent Pre-pressure output at 5 kgf/cm² 600 kgf-equivalent Pre-pressure output at 6 kgf/cm² 720 kgf-equivalent Pre-pressure output at 7 kgf/cm² 840 kgf-equivalent Boosted output at 1 kgf/cm² 3500 kgf-equivalent Boosted output at 2 kgf/cm² 7000 kgf-equivalent Boosted output at 3 kgf/cm² 10500 kgf-equivalent Boosted output at 4 kgf/cm² 14000 kgf-equivalent Boosted output at 5 kgf/cm² 17500 kgf-equivalent Boosted output at 6 kgf/cm² 21000 kgf-equivalent Boosted output at 7 kgf/cm² 24500 kgf-equivalent Return pull at 1 kgf/cm² 90 kgf-equivalent Return pull at 2 kgf/cm² 180 kgf-equivalent Return pull at 3 kgf/cm² 270 kgf-equivalent Return pull at 4 kgf/cm² 360 kgf-equivalent Return pull at 5 kgf/cm² 450 kgf-equivalent Return pull at 6 kgf/cm² 540 kgf-equivalent Return pull at 7 kgf/cm² 630 kgf-equivalent Values above follow the printed theoretical table. The 1 kgf/cm² column is a calculation reference below the 0.2 MPa minimum operating pressure; it is not a permitted operating point. Theoretical output is not a guaranteed measured force. The dimension table illustrates the standard cylinder configuration. For horizontal installation, the reservoir is connected vertically to the hydraulic cylinder as stated in the ordering footnote. The standard drawing is a dimensional reference, not a complete final layout for an independently positioned reservoir. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 40907 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 886 × 200 × 285 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework.

  Read more less

  $1,988.14

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-15TX150-20-20T-S

  Specifications: APT-15TX150-20-20T-S — standard air-oil booster listing with 125 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 15T 125 mm hydraulic bore under the catalog’s bore-code mapping X150 150 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 125 mm Selected boosted stroke 20 mm Total stroke 150 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details A 215 mm B 411 mm C 796 mm D 886 mm E 320 mm Flange width / height 200 / 285 mm Flange fixing pitch 140 × 255 mm Flange holes 4 × Ø25 mm Rod diameter Ø55 mm Rod-end thread M48 × 2P Rear cylinder section 180 mm Gauge port PT1/4 Air-port designation Three PT1/2 ports in the drawing heading Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Theoretical Output Parameter Details Pre-pressure output at 1 kgf/cm² 120 kgf-equivalent Pre-pressure output at 2 kgf/cm² 240 kgf-equivalent Pre-pressure output at 3 kgf/cm² 360 kgf-equivalent Pre-pressure output at 4 kgf/cm² 480 kgf-equivalent Pre-pressure output at 5 kgf/cm² 600 kgf-equivalent Pre-pressure output at 6 kgf/cm² 720 kgf-equivalent Pre-pressure output at 7 kgf/cm² 840 kgf-equivalent Boosted output at 1 kgf/cm² 3500 kgf-equivalent Boosted output at 2 kgf/cm² 7000 kgf-equivalent Boosted output at 3 kgf/cm² 10500 kgf-equivalent Boosted output at 4 kgf/cm² 14000 kgf-equivalent Boosted output at 5 kgf/cm² 17500 kgf-equivalent Boosted output at 6 kgf/cm² 21000 kgf-equivalent Boosted output at 7 kgf/cm² 24500 kgf-equivalent Return pull at 1 kgf/cm² 90 kgf-equivalent Return pull at 2 kgf/cm² 180 kgf-equivalent Return pull at 3 kgf/cm² 270 kgf-equivalent Return pull at 4 kgf/cm² 360 kgf-equivalent Return pull at 5 kgf/cm² 450 kgf-equivalent Return pull at 6 kgf/cm² 540 kgf-equivalent Return pull at 7 kgf/cm² 630 kgf-equivalent Values above follow the printed theoretical table. The 1 kgf/cm² column is a calculation reference below the 0.2 MPa minimum operating pressure; it is not a permitted operating point. Theoretical output is not a guaranteed measured force. The dimension table illustrates the standard cylinder configuration. For horizontal installation, the reservoir is connected vertically to the hydraulic cylinder as stated in the ordering footnote. The standard drawing is a dimensional reference, not a complete final layout for an independently positioned reservoir. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 40907 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 886 × 200 × 285 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework.

  Read more less

  $1,988.14

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-13TX150-20-20T-S

  Specifications: APT-13TX150-20-20T-S — standard air-oil booster listing with 100 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 13T 100 mm hydraulic bore under the catalog’s bore-code mapping X150 150 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 100 mm Selected boosted stroke 20 mm Total stroke 150 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details Installation dimensions Not assigned: the listed bore-selection and output-selection codes map to different hydraulic bores in the supplied catalog. Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. This listing selects 100 mm hydraulic bore through 13T, but its 20T output class is cataloged with a 125 mm bore. The source does not define this crossed combination. The original model is retained; the series operating ranges above do not validate this combination. Confirm a matching complete order code before ordering. No dimensions or theoretical output from a different bore have been assigned to it. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 22330 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 845 × 145 × 225 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework. This mass estimate uses a supported same-bore reference only and does not validate the crossed ordering combination.

  Read more less

  $813.78

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-10TX150-20-20T-S

  Specifications: APT-10TX150-20-20T-S — standard air-oil booster listing with 100 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 10T 100 mm hydraulic bore under the catalog’s bore-code mapping X150 150 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 100 mm Selected boosted stroke 20 mm Total stroke 150 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details Installation dimensions Not assigned: the listed bore-selection and output-selection codes map to different hydraulic bores in the supplied catalog. Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. This listing selects 100 mm hydraulic bore through 10T, but its 20T output class is cataloged with a 125 mm bore. The source does not define this crossed combination. The original model is retained; the series operating ranges above do not validate this combination. Confirm a matching complete order code before ordering. No dimensions or theoretical output from a different bore have been assigned to it. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 20216 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 765 × 145 × 225 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework. This mass estimate uses a supported same-bore reference only and does not validate the crossed ordering combination.

  Read more less

  $813.78

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-5TX150-20-20T-S

  Specifications: APT-5TX150-20-20T-S — standard air-oil booster listing with 80 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 5T 80 mm hydraulic bore under the catalog’s bore-code mapping X150 150 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 80 mm Selected boosted stroke 20 mm Total stroke 150 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details Installation dimensions Not assigned: the listed bore-selection and output-selection codes map to different hydraulic bores in the supplied catalog. Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. This listing selects 80 mm hydraulic bore through 5T, but its 20T output class is cataloged with a 125 mm bore. The source does not define this crossed combination. The original model is retained; the series operating ranges above do not validate this combination. Confirm a matching complete order code before ordering. No dimensions or theoretical output from a different bore have been assigned to it. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 12662 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 736 × 118 × 180 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework. This mass estimate uses a supported same-bore reference only and does not validate the crossed ordering combination.

  Read more less

  $520.19

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-3TX150-20-20T-S

  Specifications: APT-3TX150-20-20T-S — standard air-oil booster listing with 63 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 3T 63 mm hydraulic bore under the catalog’s bore-code mapping X150 150 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 63 mm Selected boosted stroke 20 mm Total stroke 150 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details Installation dimensions Not assigned: the listed bore-selection and output-selection codes map to different hydraulic bores in the supplied catalog. Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. This listing selects 63 mm hydraulic bore through 3T, but its 20T output class is cataloged with a 125 mm bore. The source does not define this crossed combination. The original model is retained; the series operating ranges above do not validate this combination. Confirm a matching complete order code before ordering. No dimensions or theoretical output from a different bore have been assigned to it. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 8748 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 675 × 100 × 160 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework. This mass estimate uses a supported same-bore reference only and does not validate the crossed ordering combination.

  Read more less

  $388.40

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-1TX150-20-20T-S

  Specifications: APT-1TX150-20-20T-S — standard air-oil booster listing with 63 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 1T 63 mm hydraulic bore under the catalog’s bore-code mapping X150 150 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 63 mm Selected boosted stroke 20 mm Total stroke 150 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details Installation dimensions Not assigned: the listed bore-selection and output-selection codes map to different hydraulic bores in the supplied catalog. Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. This listing selects 63 mm hydraulic bore through 1T, but its 20T output class is cataloged with a 125 mm bore. The source does not define this crossed combination. The original model is retained; the series operating ranges above do not validate this combination. Confirm a matching complete order code before ordering. No dimensions or theoretical output from a different bore have been assigned to it. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 8618 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 665 × 100 × 160 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework. This mass estimate uses a supported same-bore reference only and does not validate the crossed ordering combination.

  Read more less

  $388.40

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-20TX100-20-20T-S

  Specifications: APT-20TX100-20-20T-S — standard air-oil booster listing with 125 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 20T 125 mm hydraulic bore under the catalog’s bore-code mapping X100 100 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 125 mm Selected boosted stroke 20 mm Total stroke 100 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details A 165 mm B 411 mm C 846 mm D 936 mm E 280 mm Flange width / height 200 / 285 mm Flange fixing pitch 140 × 255 mm Flange holes 4 × Ø25 mm Rod diameter Ø55 mm Rod-end thread M48 × 2P Rear cylinder section 180 mm Gauge port PT1/4 Air-port designation Three PT1/2 ports in the drawing heading Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Dimension-table caution: this exact stroke row has non-progressive A/C/D values compared with the neighbouring strokes. The printed values are reproduced above without correcting them; obtain an approved installation drawing for this exact stroke before machining. Theoretical Output Parameter Details Pre-pressure output at 1 kgf/cm² 120 kgf-equivalent Pre-pressure output at 2 kgf/cm² 240 kgf-equivalent Pre-pressure output at 3 kgf/cm² 360 kgf-equivalent Pre-pressure output at 4 kgf/cm² 480 kgf-equivalent Pre-pressure output at 5 kgf/cm² 600 kgf-equivalent Pre-pressure output at 6 kgf/cm² 720 kgf-equivalent Pre-pressure output at 7 kgf/cm² 840 kgf-equivalent Boosted output at 1 kgf/cm² 3500 kgf-equivalent Boosted output at 2 kgf/cm² 7000 kgf-equivalent Boosted output at 3 kgf/cm² 10500 kgf-equivalent Boosted output at 4 kgf/cm² 14000 kgf-equivalent Boosted output at 5 kgf/cm² 17500 kgf-equivalent Boosted output at 6 kgf/cm² 21000 kgf-equivalent Boosted output at 7 kgf/cm² 24500 kgf-equivalent Return pull at 1 kgf/cm² 90 kgf-equivalent Return pull at 2 kgf/cm² 180 kgf-equivalent Return pull at 3 kgf/cm² 270 kgf-equivalent Return pull at 4 kgf/cm² 360 kgf-equivalent Return pull at 5 kgf/cm² 450 kgf-equivalent Return pull at 6 kgf/cm² 540 kgf-equivalent Return pull at 7 kgf/cm² 630 kgf-equivalent Values above follow the printed theoretical table. The 1 kgf/cm² column is a calculation reference below the 0.2 MPa minimum operating pressure; it is not a permitted operating point. Theoretical output is not a guaranteed measured force. The dimension table illustrates the standard cylinder configuration. For horizontal installation, the reservoir is connected vertically to the hydraulic cylinder as stated in the ordering footnote. The standard drawing is a dimensional reference, not a complete final layout for an independently positioned reservoir. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 43215 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 936 × 200 × 285 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework.

  Read more less

  $1,958.69

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-15TX100-20-20T-S

  Specifications: APT-15TX100-20-20T-S — standard air-oil booster listing with 125 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 15T 125 mm hydraulic bore under the catalog’s bore-code mapping X100 100 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 125 mm Selected boosted stroke 20 mm Total stroke 100 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details A 165 mm B 411 mm C 846 mm D 936 mm E 280 mm Flange width / height 200 / 285 mm Flange fixing pitch 140 × 255 mm Flange holes 4 × Ø25 mm Rod diameter Ø55 mm Rod-end thread M48 × 2P Rear cylinder section 180 mm Gauge port PT1/4 Air-port designation Three PT1/2 ports in the drawing heading Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Dimension-table caution: this exact stroke row has non-progressive A/C/D values compared with the neighbouring strokes. The printed values are reproduced above without correcting them; obtain an approved installation drawing for this exact stroke before machining. Theoretical Output Parameter Details Pre-pressure output at 1 kgf/cm² 120 kgf-equivalent Pre-pressure output at 2 kgf/cm² 240 kgf-equivalent Pre-pressure output at 3 kgf/cm² 360 kgf-equivalent Pre-pressure output at 4 kgf/cm² 480 kgf-equivalent Pre-pressure output at 5 kgf/cm² 600 kgf-equivalent Pre-pressure output at 6 kgf/cm² 720 kgf-equivalent Pre-pressure output at 7 kgf/cm² 840 kgf-equivalent Boosted output at 1 kgf/cm² 3500 kgf-equivalent Boosted output at 2 kgf/cm² 7000 kgf-equivalent Boosted output at 3 kgf/cm² 10500 kgf-equivalent Boosted output at 4 kgf/cm² 14000 kgf-equivalent Boosted output at 5 kgf/cm² 17500 kgf-equivalent Boosted output at 6 kgf/cm² 21000 kgf-equivalent Boosted output at 7 kgf/cm² 24500 kgf-equivalent Return pull at 1 kgf/cm² 90 kgf-equivalent Return pull at 2 kgf/cm² 180 kgf-equivalent Return pull at 3 kgf/cm² 270 kgf-equivalent Return pull at 4 kgf/cm² 360 kgf-equivalent Return pull at 5 kgf/cm² 450 kgf-equivalent Return pull at 6 kgf/cm² 540 kgf-equivalent Return pull at 7 kgf/cm² 630 kgf-equivalent Values above follow the printed theoretical table. The 1 kgf/cm² column is a calculation reference below the 0.2 MPa minimum operating pressure; it is not a permitted operating point. Theoretical output is not a guaranteed measured force. The dimension table illustrates the standard cylinder configuration. For horizontal installation, the reservoir is connected vertically to the hydraulic cylinder as stated in the ordering footnote. The standard drawing is a dimensional reference, not a complete final layout for an independently positioned reservoir. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 43215 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 936 × 200 × 285 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework.

  Read more less

  $1,958.69

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-13TX100-20-20T-S

  Specifications: APT-13TX100-20-20T-S — standard air-oil booster listing with 100 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 13T 100 mm hydraulic bore under the catalog’s bore-code mapping X100 100 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 100 mm Selected boosted stroke 20 mm Total stroke 100 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details Installation dimensions Not assigned: the listed bore-selection and output-selection codes map to different hydraulic bores in the supplied catalog. Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. This listing selects 100 mm hydraulic bore through 13T, but its 20T output class is cataloged with a 125 mm bore. The source does not define this crossed combination. The original model is retained; the series operating ranges above do not validate this combination. Confirm a matching complete order code before ordering. No dimensions or theoretical output from a different bore have been assigned to it. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 21009 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 795 × 145 × 225 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework. This mass estimate uses a supported same-bore reference only and does not validate the crossed ordering combination.

  Read more less

  $784.46

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-10TX100-20-20T-S

  Specifications: APT-10TX100-20-20T-S — standard air-oil booster listing with 100 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 10T 100 mm hydraulic bore under the catalog’s bore-code mapping X100 100 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 100 mm Selected boosted stroke 20 mm Total stroke 100 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details Installation dimensions Not assigned: the listed bore-selection and output-selection codes map to different hydraulic bores in the supplied catalog. Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. This listing selects 100 mm hydraulic bore through 10T, but its 20T output class is cataloged with a 125 mm bore. The source does not define this crossed combination. The original model is retained; the series operating ranges above do not validate this combination. Confirm a matching complete order code before ordering. No dimensions or theoretical output from a different bore have been assigned to it. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 18895 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 715 × 145 × 225 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework. This mass estimate uses a supported same-bore reference only and does not validate the crossed ordering combination.

  Read more less

  $784.46

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-5TX100-20-20T-S

  Specifications: APT-5TX100-20-20T-S — standard air-oil booster listing with 80 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 5T 80 mm hydraulic bore under the catalog’s bore-code mapping X100 100 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 80 mm Selected boosted stroke 20 mm Total stroke 100 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details Installation dimensions Not assigned: the listed bore-selection and output-selection codes map to different hydraulic bores in the supplied catalog. Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. This listing selects 80 mm hydraulic bore through 5T, but its 20T output class is cataloged with a 125 mm bore. The source does not define this crossed combination. The original model is retained; the series operating ranges above do not validate this combination. Confirm a matching complete order code before ordering. No dimensions or theoretical output from a different bore have been assigned to it. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 11802 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 686 × 118 × 180 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework. This mass estimate uses a supported same-bore reference only and does not validate the crossed ordering combination.

  Read more less

  $490.87

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-3TX100-20-20T-S

  Specifications: APT-3TX100-20-20T-S — standard air-oil booster listing with 63 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 3T 63 mm hydraulic bore under the catalog’s bore-code mapping X100 100 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 63 mm Selected boosted stroke 20 mm Total stroke 100 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details Installation dimensions Not assigned: the listed bore-selection and output-selection codes map to different hydraulic bores in the supplied catalog. Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. This listing selects 63 mm hydraulic bore through 3T, but its 20T output class is cataloged with a 125 mm bore. The source does not define this crossed combination. The original model is retained; the series operating ranges above do not validate this combination. Confirm a matching complete order code before ordering. No dimensions or theoretical output from a different bore have been assigned to it. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 8100 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 625 × 100 × 160 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework. This mass estimate uses a supported same-bore reference only and does not validate the crossed ordering combination.

  Read more less

  $359.63

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-1TX100-20-20T-S

  Specifications: APT-1TX100-20-20T-S — standard air-oil booster listing with 63 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 1T 63 mm hydraulic bore under the catalog’s bore-code mapping X100 100 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 63 mm Selected boosted stroke 20 mm Total stroke 100 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details Installation dimensions Not assigned: the listed bore-selection and output-selection codes map to different hydraulic bores in the supplied catalog. Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. This listing selects 63 mm hydraulic bore through 1T, but its 20T output class is cataloged with a 125 mm bore. The source does not define this crossed combination. The original model is retained; the series operating ranges above do not validate this combination. Confirm a matching complete order code before ordering. No dimensions or theoretical output from a different bore have been assigned to it. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 7970 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 615 × 100 × 160 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework. This mass estimate uses a supported same-bore reference only and does not validate the crossed ordering combination.

  Read more less

  $359.63

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-20TX50-20-20T-S

  Specifications: APT-20TX50-20-20T-S — standard air-oil booster listing with 125 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 20T 125 mm hydraulic bore under the catalog’s bore-code mapping X50 50 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 125 mm Selected boosted stroke 20 mm Total stroke 50 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details A 165 mm B 411 mm C 846 mm D 936 mm E 220 mm Flange width / height 200 / 285 mm Flange fixing pitch 140 × 255 mm Flange holes 4 × Ø25 mm Rod diameter Ø55 mm Rod-end thread M48 × 2P Rear cylinder section 180 mm Gauge port PT1/4 Air-port designation Three PT1/2 ports in the drawing heading Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Dimension-table caution: this exact stroke row has non-progressive A/C/D values compared with the neighbouring strokes. The printed values are reproduced above without correcting them; obtain an approved installation drawing for this exact stroke before machining. Theoretical Output Parameter Details Pre-pressure output at 1 kgf/cm² 120 kgf-equivalent Pre-pressure output at 2 kgf/cm² 240 kgf-equivalent Pre-pressure output at 3 kgf/cm² 360 kgf-equivalent Pre-pressure output at 4 kgf/cm² 480 kgf-equivalent Pre-pressure output at 5 kgf/cm² 600 kgf-equivalent Pre-pressure output at 6 kgf/cm² 720 kgf-equivalent Pre-pressure output at 7 kgf/cm² 840 kgf-equivalent Boosted output at 1 kgf/cm² 3500 kgf-equivalent Boosted output at 2 kgf/cm² 7000 kgf-equivalent Boosted output at 3 kgf/cm² 10500 kgf-equivalent Boosted output at 4 kgf/cm² 14000 kgf-equivalent Boosted output at 5 kgf/cm² 17500 kgf-equivalent Boosted output at 6 kgf/cm² 21000 kgf-equivalent Boosted output at 7 kgf/cm² 24500 kgf-equivalent Return pull at 1 kgf/cm² 90 kgf-equivalent Return pull at 2 kgf/cm² 180 kgf-equivalent Return pull at 3 kgf/cm² 270 kgf-equivalent Return pull at 4 kgf/cm² 360 kgf-equivalent Return pull at 5 kgf/cm² 450 kgf-equivalent Return pull at 6 kgf/cm² 540 kgf-equivalent Return pull at 7 kgf/cm² 630 kgf-equivalent Values above follow the printed theoretical table. The 1 kgf/cm² column is a calculation reference below the 0.2 MPa minimum operating pressure; it is not a permitted operating point. Theoretical output is not a guaranteed measured force. The dimension table illustrates the standard cylinder configuration. For horizontal installation, the reservoir is connected vertically to the hydraulic cylinder as stated in the ordering footnote. The standard drawing is a dimensional reference, not a complete final layout for an independently positioned reservoir. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 43215 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 936 × 200 × 285 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework.

  Read more less

  $1,929.37

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-15TX50-20-20T-S

  Specifications: APT-15TX50-20-20T-S — standard air-oil booster listing with 125 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 15T 125 mm hydraulic bore under the catalog’s bore-code mapping X50 50 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 125 mm Selected boosted stroke 20 mm Total stroke 50 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details A 165 mm B 411 mm C 846 mm D 936 mm E 220 mm Flange width / height 200 / 285 mm Flange fixing pitch 140 × 255 mm Flange holes 4 × Ø25 mm Rod diameter Ø55 mm Rod-end thread M48 × 2P Rear cylinder section 180 mm Gauge port PT1/4 Air-port designation Three PT1/2 ports in the drawing heading Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. Dimension-table caution: this exact stroke row has non-progressive A/C/D values compared with the neighbouring strokes. The printed values are reproduced above without correcting them; obtain an approved installation drawing for this exact stroke before machining. Theoretical Output Parameter Details Pre-pressure output at 1 kgf/cm² 120 kgf-equivalent Pre-pressure output at 2 kgf/cm² 240 kgf-equivalent Pre-pressure output at 3 kgf/cm² 360 kgf-equivalent Pre-pressure output at 4 kgf/cm² 480 kgf-equivalent Pre-pressure output at 5 kgf/cm² 600 kgf-equivalent Pre-pressure output at 6 kgf/cm² 720 kgf-equivalent Pre-pressure output at 7 kgf/cm² 840 kgf-equivalent Boosted output at 1 kgf/cm² 3500 kgf-equivalent Boosted output at 2 kgf/cm² 7000 kgf-equivalent Boosted output at 3 kgf/cm² 10500 kgf-equivalent Boosted output at 4 kgf/cm² 14000 kgf-equivalent Boosted output at 5 kgf/cm² 17500 kgf-equivalent Boosted output at 6 kgf/cm² 21000 kgf-equivalent Boosted output at 7 kgf/cm² 24500 kgf-equivalent Return pull at 1 kgf/cm² 90 kgf-equivalent Return pull at 2 kgf/cm² 180 kgf-equivalent Return pull at 3 kgf/cm² 270 kgf-equivalent Return pull at 4 kgf/cm² 360 kgf-equivalent Return pull at 5 kgf/cm² 450 kgf-equivalent Return pull at 6 kgf/cm² 540 kgf-equivalent Return pull at 7 kgf/cm² 630 kgf-equivalent Values above follow the printed theoretical table. The 1 kgf/cm² column is a calculation reference below the 0.2 MPa minimum operating pressure; it is not a permitted operating point. Theoretical output is not a guaranteed measured force. The dimension table illustrates the standard cylinder configuration. For horizontal installation, the reservoir is connected vertically to the hydraulic cylinder as stated in the ordering footnote. The standard drawing is a dimensional reference, not a complete final layout for an independently positioned reservoir. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 43215 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 936 × 200 × 285 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework.

  Read more less

  $1,929.37

  View options

•

  View options

  Airtac APT series: air-oil booster - APT-13TX50-20-20T-S

  Specifications: APT-13TX50-20-20T-S — standard air-oil booster listing with 100 mm selected hydraulic bore, 20 mm boosted stroke and 20 tonne output-class selection. Product Catalog Download Airtac Product Catalog (PDF) For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. This Ordering Code Code Meaning APT Standard air-oil booster 13T 100 mm hydraulic bore under the catalog’s bore-code mapping X50 50 mm total stroke 20 20 mm boosted stroke 20T 20 tonne theoretical output class S Horizontal arrangement Technical Specifications Parameter Details Selected hydraulic bore 100 mm Selected boosted stroke 20 mm Total stroke 50 mm Selected output class 20 tonne Air pressure, series range 0.2–0.7 MPa, filtered dry air Oil grade ISO VG68 Working temperature, series range −5 to +60°C Hydraulic proof pressure, series 30 MPa Pneumatic proof pressure, series 1.5 MPa Stroke tolerance +1.0 / 0 mm Working frequency, series 10 cycles/min Dimensions and Installation Parameter Details Installation dimensions Not assigned: the listed bore-selection and output-selection codes map to different hydraulic bores in the supplied catalog. Dimensions are in millimetres unless a different unit is shown. Lettered dimensions refer to the matching drawing in the catalog; check that drawing before machining or installing the product. This listing selects 100 mm hydraulic bore through 13T, but its 20T output class is cataloged with a 125 mm bore. The source does not define this crossed combination. The original model is retained; the series operating ranges above do not validate this combination. Confirm a matching complete order code before ordering. No dimensions or theoretical output from a different bore have been assigned to it. System Installation Use filtered, dry compressed air within the stated pressure range. A receiver between the air-preparation assembly and booster is recommended to stabilise the pressure supply. An automatic-drain air-preparation assembly is recommended for the supply. Use the oil grade specified for this series; the overview mentions ISO VG32 and VG68 for different products, so do not interchange them without the series requirement. A regulator with reverse-flow function before the high-pressure-stage air inlet allows the minimum required working force to be set, reducing tooling load and air consumption. Normal mounting is by flange with the output rod pointing down. For horizontal mounting, arrange the air-oil converter upright as illustrated. Inverted or inclined installation cannot use the standard arrangement directly; the converter must be arranged upright as shown for the modified layout. Mount the intensifier above the hydraulic cylinder where possible; a different orientation requires the specified alternative design. The recommended circuit shows two 5/2 solenoid valves, speed-control valves, an air receiver and air preparation; these are circuit components, not an automatic list of items supplied with this cylinder. For detailed product dimensions and mounting drawings, please download and refer to the PDF catalog. Estimated Weight 19688 g. This is a calculated reference estimate for this product, not a manufacturer-published or measured product weight. Packaging is excluded. Approximate matching-bore reference envelope 745 × 145 × 225 mm × assumed aluminium-equivalent density 2.7 g/cm³ × 30% solid fill; excludes operating oil and remote pipework. This mass estimate uses a supported same-bore reference only and does not validate the crossed ordering combination.

  Read more less

  $755.14

  View options
